Troubleshooting STOP Errors

1
Troubleshooting STOP Errors

• Amit Marlov, MCSE, MCTWindows Client RD,
  Microsoft Israelv-amitma_at_microsoft.com

2
Troubleshooting STOP Errors

• What is a STOP error?
• Preventing STOP errors
• Analyzing STOP errors
• Resolving STOP errors

3
What is a STOP error?

• A Stop error occurs when Windows stops
  responding. Stop error messages can be caused by
  H/W or S/W malfunctions.The error messages
  appear on a blue or black background, A.K.A Blue
  screen

4
(No Transcript)
5
Understanding STOP Errors

• Each STOP error has a unique identifier code,
  given in Hexadecimal
• Use the error code and search for a relevant KB
  article
• Browse the TechNet site for more information

6
A Few Examples

• http//support.microsoft.com/default.aspx?scidkb
  en-us324103
• http//support.microsoft.com/default.aspx?scidkb
  en-usQ228888

7
Common STOP Errors

• IRQL_NOT_LESS_OR_EQUAL 0x0A
• This is the result of a buggy driver
• The driver attempts to access an illegal memory
  space
• Look for an updated driver
• Check your driver using http//support.microsoft.c
  om/?kbid244617sdRMVP

8
Common STOP Errors Contd

• UNEXPECTED_KERNEL_MODE_TRAP 0x7F
• A driver or subsystem has tried to execute an
  illegal processor instruction
• The cause can be a faulty memory module or a
  driver that has corrupted memory
• Perform a comprehensive memory checkEZ0032

9
Common STOP Errors Contd

• INACCESSIBLE_BOOT_DEVICE 0x7B
• Windows cannot access the disk partition that
  boot.ini
• The cause can be an incompatible driver
• Obtain a different driver, use the Windows
  Recovery Console and replace the driver files

10
Analyzing STOP Errors

• First
• Disable Auto Restart (using F8)
• Disable BIOS memory options such as caching or
  shadowing
• Verify that your H/W device drivers and your
  system BIOS are the latest available versions

11
Analyzing STOP errors Contd

• Second
• Reboot your computer and start Windows(if
  possible)
• Check the System event log for additional error
  details
• If available use ERD Commander and do the same

12
Can I Examine The Dump Files?

• A Dump file is created at every STOP error
• Browse to this site
• Use the following debugging tools to manually
  analyze your memory dump files
• Microsoft Kernel Debugger (Kd.exe)
• Microsoft WinDbg Debugger (Windbg.exe)

13
Preventing STOP Errors

• Check the Microsoft Hardware Compatibility List
  (HCL)
• Verify that all hardware and software drivers are
  compatible with Windows
• Install all available patches and software
  updates from www.windowsupdate.com

14
Whats Next?

• This subject requires additional reading
• We have a Windows Server Troubleshooting Stop
  Errors Guide
• http//www.microsoft.com/downloads/details.aspx?Fa
  milyID859637b4-85f1-4215-b7d0-25f32057921cDispla
  yLangen

15
