WELCOME Mobile Solutions Board of Directors

1
WELCOMEMobile SolutionsBoard of Directors
Jordan Fenton - Scott Westveer - Michael Woolfe
2
Designing Our Network
Michael Woolfe

• Main Building Network Layout
• Remote Networking Structure
• Logical Topology

3
Main Building Network Layout
Michael Woolfe

• Server Room
• Engineering Room
• Management Room
• Local Sales Room
• Purpose To provide a graphical representation
  of the local network.

4
Michael Woolfe
5
Michael Woolfe
6
Michael Woolfe
7
Michael Woolfe
8
Michael Woolfe
9
Remote Networking Structure
Michael Woolfe

• Roaming Sales and Engineers
• Remote Sales Office
• Purpose To provide a graphical representation
  of the remote network.

10
Michael Woolfe
11
Logical Topology
Michael Woolfe

• Main Building Network Layout
• Remote Networking Structure
• Purpose To demonstrate the structure of the
  network.

12
Michael Woolfe
13
Michael Woolfe
14
Top Down Model
Michael Woolfe

• Business Layer (Strategic Planning)
• Handed the project
• Application Layer (Manipulation of Data)
• Outsourced or another group handles
• Data Layer (Transfer, Access, Redundancy)
• Off site redundancy
• Figure a Ethernet based system
• Network Layer (Topologies)
• All Star
• Technology Layer (Physical Aspects)
• Lay of the Cabling Outsourced

15
Staffing
Michael Woolfe

• Manage
• 70 nodes locally
• Possible 20 nodes remotely
• Managers
• WAN
• Local personal computers
• Networking
• Security and head

16
Staffing Allocations
Michael Woolfe

• Security and head manager
• Security
• Physical
• Data
• Transfer
• Server
• WAN Manager
• Partial T1 connection
• Remote sales office
• Roaming engineers and sales personnel

17
Staffing Allocations
Michael Woolfe

• Personal Computers Manager
• Operating System
• Hardware
• Networking Manager
• Cabling
• Data management devices

18
Connectivity Devices

• 100 Cisco
• Quality
• Compatibility
• Many Features
• Interchangeable

19
Cisco 1751 Router

• Selected for both locations
• Firewall Protection
• Voice Integration
• CSU/DSU Port at T1/E1 Speeds
• VPN Support
• VLAN Support

20
3500XL Series Switches

• VLAN Support
• Supports Voice Integration
• Bandwidth Management
• Gigabit Integration

21
3508GXL Switch

• 8 Gigabit Ports
• Location Backbone
• VLAN Support
• Voice Capabilities
• Copper or Fiber Interfaces
• QoSCAR, Policy Routing

22
GBIC Transceivers

• Gigabit Interface Converter (GBIC)
• Copper
• Fiber
• Cascading
• Gigabit Speeds

23
Modem Pool

• Scalable - Up to 128 modems per server slot used.
• Simultaneous 115Kbps each
• Hot Swappable

24
Employee Equipment

• They are 3 different types of users in this
  Network
• sales local sales remote
• engineering management
• field engineers roaming sales force

25
SALES LOCAL SALES REMOTE

• 50 workstations for sales local
• 10 workstations for sales remote
• 60 workstations total

26
GATEWAY 300L Series PC

• This PC offers a low-cost technology solution
  while providing the performance qualities for
  your business needs.

Chart comparing, prices,performance, and
reliability
27
ComparisonGateway 300L

• 1Ghz Intel Celeron chip w/128K cache and
  Integrated 3D Graphics
• 128MB SDRAM and 1 USB port and 1 Parallel port
• A 15 color Monitor (13.8 viewable area)
• 20GB Hard Drive, 48 maximum CD-ROM drive
• Software Included are Windows Suite 2001
  w/Microsoft Word and Encarta
• Windows 2000 Operating System
• Norton Antivirus 2001 and Integrated 10/100
  Ethernet Adapter w/ 2 low profile PCI
• 104 keyboard and Mouse Gateway mouse pad
• Total cost699

28
ComparisonDell

• 800 MHz Intel Celeron chip w/32 KB cache, 810
  chipset and Integrated Intel 3D AGP Graphics
• 128MD SDRAM and 10/100 PCI
• 2 USB ports, 1 serial port, and 1 parallel port
  w/ECP
• 20GB Hard Drive, 48 Maximum CD-ROM drive
• Backup battery 3.0 V CR2032 lithium magnesium
  oxide coin cell
• A 15 E551 Monitor (13.8 viewable)
• PC speakers w/SoundBlaster 64V PCI Sound Card
• Dell keyboard and 2 button standard mouse
• Microsoft Windows 2000 Pro Operating System and
  Microsoft Office XP small Business software
• Total cost1,046.99

29
Comparison Hewlett Packard

• 800MHz Celeron chip w/64MB of memory
• 20GB Hard Drive
• Windows NT Operating System
• 3com 10/100 integrated Ethernet adapter
• Hewlett Packard Mouse and Keyboard
• 19 Color Monitor(19.8 viewable)
• Total cost1,015.99

30
(No Transcript)
31
Part 2 Engineering Management

• This segment consist of 30 PCs
• 10 Management
• 20 Engineering

32
Gateway 700L Entry Level

• Managers and Engineers need the best technology
  solution for their business needs(security,
  reliability, and performance)

33
Gateway 700L Specs.

• 1.8GHz Pentium 4 chip
• 256MB RDRAM PC800
• EV700 17 color (15.9 viewable)
• 40GB Hard Drive and 48 maximum CD-Rom Drive
• 32MD Geforce2 MX200 AGP Graphics
• Software Included are Windows Suite 2001
  w/Microsoft Word and Encarta
• Microsoft XP Home Edition Operating System
• Total cost1,199

34
This segment consist of 10 Laptops.

• 5 Field Engineers
• 5 Roaming Sales

35
Gateway Solo 3350

• Field engineers and Outside Sales needs something
  that is thin and light because they perform many
  task at a very rapid pace, such as updating
  databases, configuring Routers, checking mail,
  etc.

36
Gateway Solo 3350Specs.

• 700MHz Intel Pentium III Processor
• 256MD SDRAM
• 10 GB Ultra ATA Hard drive, 24 maximum external
  CD-ROM drive, and a External Floppy Diskette
  Media Bay
• ATI rage Graphic Accelerator w/4MB SDRAM
• Integrated 16-bit Sound, Speakers, Internal
  Microphone, Headphone/ Speaker jack(package)
• EZ Pad Pointing Device
• One Type II PC Card slot
• Microsoft Windows 2000 Professional Series
• Norton Anti-Virus Software
• Integrated V.90 56K Modem and Integrated 10/100
  Ethernet
• Solo Ultra Port Replicator II with AC adapter

37
Dell Power Edge 2400 Server

• 220-3086 - POWEREDGE 6300 SERVER
• - 4X-P3-500MHZ-4G RAM
• 6 DELL-HD-3 - DELL 36.4G HARD DRIVE
• 2 DELL-NET - DELL NETWORK CARD
• DELL-SCSI - SCSI PORT - 4-PORT
• DELL-SCSI - SCSI PORT
• Quad P3 500 MHZ CPUs 4 GB RAM
• 733mhz CPU on board
• 256MB ECC SDRAM
• 2 X 9 gig 10K IBM hard drives and 40X CD-ROM
• Dual power supply
• 1,029.00

38
TYPES OF CABLES
39
Estimated Capital Required
40
Works Cited

• Goldman, J. E. , P. T. Rawles. Applied Data
  Communications A Business-Oriented Approach.
  New York John Wiley Sons, 2001.
• http//www.warehouse.com
• http//www.blackbox.com
• http//www.pricewatch.com
• http //www.cisco.com
• http//www.gateway.com
• http//www.cyclade.com
• http//www.gocables.com
• http//www.ebay.com
• http//www.dell.com
• http//www.hp.com
• http//www.equinox.com
