Explicit Modelling in Metaheuristic Optimization

1
Explicit Modelling in Metaheuristic Optimization

• Dr Marcus Gallagher
• School of Information Technology and Electrical
  Engineering
• University of Queensland Q. 4072
• marcusg_at_itee.uq.edu.au

2

• Talk outline
• Optimization, heuristics and metaheuristics.
• Estimation of Distribution (optimization)
  algorithms (EDAs) a brief overview.
• A framework for describing EDAs.
• Other modelling approaches in metaheuristics.
• Summary

3
Hard Optimization Problems

• Goal Find
• where S is often multi-dimensional real-valued
  or binary
• Many classes of optimization problems (and
  algorithms) exist.
• When might it be worthwhile to consider
  metaheuristic or machine learning approaches?

4

• Finding an exact solution is intractable.
• Limited knowledge of f()
• No derivative information.
• May be discontinuous, noisy,
• Evaluating f() is expensive in terms of time or
  cost.
• f() is known or suspected to contain nasty
  features
• Many local minima, plateaus, ravines.
• The search space is high-dimensional.

5

• What is the practical goal of (global)
  optimization?
• There exists a goal (e.g. to find as small a
  value of f() as possible), there exist resources
  (e.g. some number of trials), and the problem is
  how to use these resources in an optimal way.
• A. Torn and A. Zilinskas, Global Optimisation.
  Springer-Verlag, 1989. Lecture Notes in Computer
  Science, Vol. 350.

6
Heuristics

• Heuristic (or approximate) algorithms aim to find
  a good solution to a problem in a reasonable
  amount of computation time but with no
  guarantee of goodness or efficiency (cf.
  exact or complete algorithms).
• Broad classes of heuristics
• Constructive methods
• Local search methods

7
Metaheuristics

• Metaheuristics are (roughly) high-level
  strategies that combinine lower-level techniques
  for exploration and exploitation of the search
  space.
• An overarching term to refer to algorithms
  including Evolutionary Algorithms, Simulated
  Annealing, Tabu Search, Ant Colony, Particle
  Swarm, Cross-Entropy,
• C. Blum and A. Roli. Metaheuristics in
  Combinatorial Optimization Overview and
  Conceptual Comparison. ACM Computing Surveys,
  35(3), 2003, pp. 268-308.

8
Learning/Modelling for Optimization

• Most optimization algorithms make some (explicit
  or implicit) assumptions about the nature of f().
• Many algorithms vary their behaviour during
  execution (e.g. simulated annealing).
• In some optimization algorithms the search is
  adaptive
• Future search points evaluated depend on previous
  points searched (and/or their f() values,
  derivatives of f() etc).
• Learning/modelling can be implicit (e.g, adapting
  the step-size in gradient descent, population in
  an EA).
• or explicit examples from optimization
  literature
• Nelder-Mead simplex algorithm.
• Response surfaces (metamodelling, surrogate
  function).

9
EDAs Probabilistic Modelling for Optimization

• Based on the use of (unsupervised) density
  estimators/generative statistical models.
• Idea is to convert the optimization problem into
  a search over probability distributions.
• P. Larranaga and J. A. Lozano (eds.). Estimation
  of Distribution Algorithms a new tool for
  evolutionary computation. Kluwer Academic
  Publishers, 2002.
• The probabilistic model is in some sense an
  explicit model of (currently) promising regions
  of the search space.

10
EDAs toy example
11
EDAs toy example
12
GAs and EDAs compared

• GA pseudocode
• Initialize the population, X(t)
• Evaluate the objective function for each point
• Selection()
• Crossover()
• Mutation()
• ? Form new population X(t1)
• While !(terminate()) Goto 2

13
GAs and EDAs compared

• EDA pseudocode
• Initialize a probability model, Q(x)
• Create a population of points by sampling from
  Q(x)
• Evaluate the objective function for each point
• Update Q(x) using selected population and f()
  values
• While !(terminate()) Goto 2

14
EDA Example 1

• Population-based Incremental Learning (PBIL)
• S. Baluja, R. Caruana. Removing the Genetics from
  the Standard Genetic Algorithm. ICML95.

p1 Pr(x11)
p2 Pr(x21)
pn Pr(xn1)
15
EDA Example 2

• Mutual Information Maximization for Input
  Clustering (MIMIC)
• J. De Bonet, C. Isbell and P. Viola. MIMIC
  Finding optima by estimating probability
  densities. Advances in Neural Information
  Processing Systems, vol.9, 1997.

16
EDA Example 3

• Combining Optimizers with Mutual Information
  Trees (COMIT)
• S. Baluja and S. Davies. Using optimal
  dependency-trees for combinatorial optimization
  learning the structure of the search space.
  Proc. ICML97.
• Uses a tree-structured graphical model
• Model can be constructed in O(n2) time using a
  variant of the minimum spanning tree algorithm.
• Model is optimal, given the restrictions, in the
  sense that the Kullback-Liebler divergence
  between the model and a full joint distribution
  is minimized.

17
EDA Example 4

• Bayesian Optimization Algorithm (BOA)
• M. Pelikan, D. Goldberg and E. Cantu-Paz. BOA
  The Bayesian optimization algorithm. In Proc.
  GECCO99.
• Bayesian network model where nodes can have at
  most k parents.
• Greedy search over the Bayesian Dirichlet
  equivalence metric to find the network structure.

18
Further work on EDAs

• EDAs have also been developed
• For problems with continuous and mixed variables.
• That use mixture models and kernel estimators -
  allowing for the modelling of multi-modal
  distributions.
• and more!

19
A framework to describe building and adapting a
probabilistic model for optimization

• See
• M. Gallagher and M. Frean. Population-Based
  Continuous Optimization, Probabilistic Modelling
  and Mean Shift. To appear, Evolutionary
  Computation, 2005.
• Consider a continuous EDA with model
• Consider a Boltzmann distribution over f(x)

20

• As T?0, P(x) tends towards a set of impulse
  spikes over the global optima.
• Now, we have a probability distribution that we
  know the form of, Q(x) and we would like to
  modify it to be close to P(x). KL divergence
• Let Q(x) be a Gaussian try and minimize K via
  gradient descent with respect to the mean
  parameter of Q(x).

21

• The gradient becomes
• An approximation to the integral is to use a
  sample of x from Q(x)

22

• The algorithm update rule is then
• Similar ideas can be found in
• A. Berny. Statistical Machine Learning and
  Combinatorial Optimization. In L. Kallel et al.
  eds, Theoretical Aspects of Evolutionary
  Computation, pp. 287-306. Springer. 2001.
• M. Toussaint. On the evolution of phenotypic
  exploration distributions. In C. Cotta et al.
  eds, Foundations of Genetic Algorithms (FOGA
  VII), pp. 169-182. Morgan Kaufmann. 2003.

23
Some insights

• The derived update rule is closely related to
  those found in Evolution Strategies and a version
  of PBIL for continuous spaces.
• It is possible to view these existing algorithms
  as approximately doing KL minimization.
• The objective function appears explicitly in this
  update rule (no selection).

24
Other Research in Learning/Modelling for
Optimization

• J. A. Boyan and A. W. Moore. Learning Evaluation
  Functions to Improve Optimization by Local
  Search. Journal of Machine Learning Research 12,
  2000.
• B. Anderson, A. Moore and D. Cohn. A
  Nonparametric Approach to Noisy and Costly
  Optimization. International Conference on
  Machine Learning, 2000.
• D. R. Jones. A Taxonomy of Global Optimization
  Methods Based on Response Surfaces. Journal of
  Global Optimization 21(4)345-383, 2001.
• Reinforcement learning
• R. J. Williams (1992). Simple statistical
  gradient-following algorithms for connectionist
  reinforcement learning. Machine Learning,
  8229-256.
• V. V. Miagkikh and W. F. Punch III, An Approach
  to Solving Combinatorial Optimization Problems
  Using a Population of Reinforcement Learning
  Agents, Genetic and Evolutionary Computation
  Conf.(GECCO-99), p.1358-1365, 1999.

25
Summary

• The field of metaheuristics (including
  Evolutionary Computation) has produced
• A large variety of optimization algorithms
• Demonstrated good performance on a range of
  real-world problems.
• Metaheuristics are considerably more general
• can even be applied when there isnt a true
  objective function (coevolution).
• Can evolve non-numerical objects.

26
Summary

• EDAs take an explicit modelling approach to
  optimization.
• Existing statistical models and model-fitting
  algorithms can be employed.
• Potential for solving challenging problems.
• Model can be more easily visualized/interpreted
  than a dynamic population in a conventional EA.
• Although the field is highly active, it is still
  relatively immature
• Improve quality of experimental results.
• Make sure research goals are well-defined.
• Lots of preliminary ideas, but lack of
  comparative/followup research.
• Difficult to keep up with the literature and see
  connections with other fields.

27
The End!

• Questions?
