Parallel Job Scheduling Algorithms and Interfaces

1
Parallel Job SchedulingAlgorithms and Interfaces

• Research Exam for
• Cynthia Bailey Lee
• Department of Computer Science and Engineering
• University of California, San Diego
• May 27, 2004

2
Outline

• Introduction
• Problem Overview
• Why does this matter?
• Problem Specification
• History
• Early Approaches
• Backfilling
• Priorities
• Evaluation
• Metrics
• Metric Pitfalls
• User Perspectives
• Future Directions

3
What Are We Trying to Do?
Introduction Problem Overview Why
Does This Matter? Problem Specification
Job
System
Blue Horizon
Message-Passing Parallel Scientific Code
System Model
Job Model
Idle space
CFD visualization www.science-computing.de/produc
ts/powerviz.html
4
Why Does This Matter?
Introduction Problem Overview Why
Does This Matter? Problem Specification
Systems in the Top500 typically range in price
from 1 million to 50 million
Top500 data www.top500.org
5
Problem Specification
Introduction Problem Overview Why
Does This Matter? Problem Specification

• Purpose process a workload parallel batch jobs
• Processor Homogeneity machine consists of N
  identical processors
• Job Specification processors by requested runtime
• Exclusivity jobs do not share processors
• Non-Preemption once begun, jobs run to completion
• Online jobs arrive stochastically, no knowledge
  of future
• Accounting there is a scheme to track users'
  resource consumption
• User Independence users are in competition for
  system resources

6
Outline
History

• Introduction
• Problem Overview
• Why does this matter?
• Problem Specification
• History
• Early Approaches
• Backfilling
• Priorities
• Evaluation
• Metrics
• Metric Pitfalls
• User Perspectives
• Future Directions

7
First Come First Serve(FCFS)
History Early Approaches
Backfilling Priorities
Job 1
Processors
Time
Job 4
Job 3
Job 2
Queue
8
Tennis Court SchedulingM93,P04
History Early Approaches
Backfilling Priorities
Job 1
Job 5
Job 2
Job 3
Job 4
Job 6
Processors
Time
Job 7
9
EASY BackfillingSCZL96
History Early Approaches
Backfilling Priorities

• Allow backfills when the projected start of first
  job in the queue is not delayed
• No starvationall jobs will eventually run
• Claim Jobs in the queue are never delayed from
  running by jobs submitted to the queue after
  them.
• Disproved MF01

10
Conservative Backfilling
History Early Approaches
Backfilling Priorities

• Allow backfills when the projected starts of all
  preceding jobs in the queue are not delayed
• Worst-case start time guaranteed at submittal
• Claim guarantees that future arrivals do not
  delay previously queued jobs. MF01
• Disproveddepending on semantics of delay
  JSC01

11
Maui Scheduler JS01
History Early Approaches
Backfilling Priorities

• Prioritiesa function of 20 parameters (dont
  read this chart)

• Parameterized backfills
• Backfilling allowed when the projected starts of
  the N preceding jobs in the queue are not delayed
• lt Maui is deployed on many major systems

12
Microeconomic Scheduler SAWP95
History Early Approaches
Backfilling Priorities

• A Unifying Principle
• Influence user behavior through accounting and
  charges, allow users to influence system behavior
  through payments FR96

Job 1
Processors
Time
13
Outline
Evaluation

• Introduction
• Problem Overview
• Why does this matter?
• Problem Specification
• History
• Early Approaches
• Backfilling
• Priorities
• Evaluation
• Metrics
• Metric Pitfalls
• User Perspectives
• Future Directions

14
Common Metrics
Evaluation Metrics Metric
Pitfalls User Perspectives

• Makespan
• Utilization
• ResponseTime
• Expansion Factor (Slowdown)
• Bounded Slowdown
• Weighted Response Time

15
Metric Pitfallsor 12 Ways to Fool the Masses
When Giving Scheduler Performance Results
(Apologies to B91)
Evaluation Metrics Metric
Pitfalls User Perspectives

• Rely on a single number (e.g. average)
• Dont mention what happens to the unluckiest jobs
  CADV02especially avoid focusing on those
  hard-to-schedule big jobs SKSS02, EHY02
• Use a workload that is unrealistic and shows off
  your schedulers strengths MF01,FN95
• Avoid unpleasant related facts like internal
  fragmentation PJN99
• Dont waste time worrying about user-centric
  aspects of performance such as fairness and
  start-time guarantees MF01
• Focus solely on performance, not user interface
  and implementation issues

Citations noted are exemplary cases of doing
the right thing
16
Scheduling in Context User Utility Functions
FRSSW97
Evaluation Metrics Metric
Pitfalls User Perspectives
8 am 121pm 5 pm-8 am 9 am
17
Outline
Future Directions

• Introduction
• Problem Overview
• Why does this matter?
• Problem Specification
• History
• Early Approaches
• Backfilling
• Priorities
• Evaluation
• Metrics
• Metric Pitfalls
• User Perspectives
• Future Directions

18
Scheduling Explicitly by User Utility Function
L04, FrN95
Future Directions

• If user utility functions can be collected, a
  scheduler can be designed to explicitly optimize
  the global utility
• A survey of users at SDSC demonstrated
  feasibility of collection for crude utility
  functions
• Formulated as a Linear programwith some integer
  constraintsfinding the optimal solution is
  NP-hard
• Commercially available solvers are able to
  produce good solutions in reasonable timeframes
  (lt 1 minute)

19
Empowering the User by Providing More
InformationL04
Future Directions
20
User-Provided InputsMF01, LSHS04
Future Directions

• Users are strongly motivated to overestimate in
  their requested runtimes
• Jobs are killed when the time expires
• Can users be more accurate when not threatened
  with death, and with more tangible rewards?

21
Outline
Conclusion

• Introduction
• Problem Overview
• Why does this matter?
• Problem Specification
• History
• Early Approaches
• Backfilling
• Priorities
• Evaluation
• Metrics
• Metric Pitfalls
• User Perspectives
• Future Directions
