SPECIAL WASTE MANAGEMENT FOR LANDFILLS AND MONTANA COMMUNITIES

1
SPECIAL WASTE MANAGEMENT FOR LANDFILLS AND
MONTANA COMMUNITIES November 12 13, 2008
2
INDUSTRIAL WASTESNONHAZARDOUS SUBTITLE D
REGULATORY INTRODUCTION

• Tim Stepp
• Solid Waste Program
• Waste Underground Tank Management Bureau

3
EPA SPECIAL WASTE EXCLUSIONS

• EPA allows some industrial wastes to be
  temporarily managed for disposal under approved
  Montana Solid Waste authority
• Final EPA rulemaking based on process, volume,
  waste characterization stability (C2P2 Coal
  Combustion Products Partnership)
• TCLP leachate levels (acidic solvent) or separate
  extraction in alkaline leachate (As, Sb)
• Evaluation of risks based on several factors,
  including improved operational practices

4
EPA SUBTITLE-D REGULATION

• New EPA OSW definition of solid waste allows
  certain sub-C exemptions for beneficial uses of
  special wastes
• Economic marketability or benefits of products
  (BUDs) determines level of regulation
• Coal combustion waste (CCW)
• EPA 2002 CCW finding 2007 NODA (new rules in
  process)
• Montana exclusion for on-site disposal at
  coal-fired power plants
• Cement kiln dust (CKD)
• EPA 1999-2002 NODA (new rules in draft)

5
CCW CKD GENERATIONWASTE CHARACTERISTICS

• Fly ash byproduct forms during burning of finely
  pulverized coal (pc) in boiler
• Siliceous (Class F) to calcic (Class C) silt- to
  clay-sized, sorted glassy spherules resembling
  pumice
• Pozzolan-type reaction with lime (Class F) or
  simple hydration by water (Class C) triggers
  rapid set-up into cementitious block
• Bottom ash or slag (wet) byproduct forms at base
  during firing of pulverized coal furnaces
• Porous or glassy agglomerate of well-graded ash
  residues

6
CCW CKD GENERATIONWASTE CHARACTERISTICS

• Flue Gas Desulfurization (FGD) byproduct from wet
  or dry scrubbers leading to stack
• Calcium-sulfate (gypsum) and -sulfite material
• Alkaline CKD byproduct generated in cement kilns
  during calcination for cement
• CCW CKD contain antimony, arsenic, barium,
  boron, beryllium, cadmium, chromium, lead,
  mercury, selenium, thalliumoften detected in
  groundwater via release at unlined facilities

7
CCW CKD LANDFILLSMONTANA CLASS II LICENSE

• CCW ash and CKD clinker are defined under
  leachable Montana Group II waste
• Requirements exceed EPA recommendations for sub-D
  regulations in draft
• Program allows flexibility for alternative liners
  covers, and groundwater protection standards or
  monitoring waivers
• Location, design, operation, closure more
  similar to Class IV monofills (see CD)
• CCW and CKD can be easily stabilized during
  set-up like concrete upon disposal

8
CCW CKD LANDFILLSCLASS-IV UNIT OPERATIONS

• Uniquely minimal infiltration due to exothermic
  set-up during on-site blending/watering of lifts
• Low leachate and methane production
• Less erosion control needed within unit
• Dust control on entry roads
• Walking-floor trailers for transport containment
• Cover side slopes as fill reaches ultimate grade
• Likely approval for alternative final cover

9
CCW CKD BENEFICIAL USESSTABILIZED PRODUCTS
(CCP)

• Porous bottom ash provides CCP baseline
• Mine and subgrade fills structural embankments
• Road base high-wear pavements
• Raw material for concrete products
• Feed stock for cement production (kilns)
• Siliceous fly ash has additional uses
• Raw material for grout flowable fill products
• Ingredient for waste stabilization or soil
  additive
• FGD gypsum has same uses as fly ash
• Boiler slag grit used for sand blasting roofing

10
CCW CKD BENEFICIAL USESSTABILIZED PRODUCTS
(CCP)

• Leachability of toxic metals can be stabilized
• Sulfates react with silica to set-up like
  concrete
• Used to stabilize other initially hazardous
  wastes
• Case-by-case Beneficial Use Demonstration (BUD)
  approval required for RRF license
• Deleterious ammonia can be removed from CCW
• Lot of research on CCW use in concrete, mine
  flowable fills, mortars, stuccos, and cement
• Wide possibilities for CCW as mineral fill in
  asphalt for durable road surfaces

11
POTENTIAL BUD PROBLEMSCLEAN AIR ACT TITLE-V
HAPs

• Implementation of EPA 2005 CAMR requires
  reduction of mercury emissions to meet CAIR
  levels
• Causes potential increase in mercury captured by
  CCW byproducts
• May affect CCP quality potential for demos of
  beneficial utilization
• Impacts on soil, cement, concrete, grout, and
  fill applications unknown
• Possible ban on use as cement kiln feedstock

12
(No Transcript)
13
CLASS II CCW Working face over MSW lift
14
CLASS II CCW Erosion outer slope
15
CLASS II CCW Rapid setup after watering
16
CLASS II CCW Setup after water truck pass
