Traffic Analysis Prevention

1
Traffic Analysis Prevention

• Chris Conger
• CIS6935 Cryptographic Protocols
• 11/16/2004

2
Outline

• What is Traffic Analysis Prevention (TAP)?
• Problems, challenges with TAP
• Analysis attacks, typical system vulnerabilities
• Methods of TAP
• Case Study NetCamo
• Conclusion

3
Introduction to TAP

• Traffic Analysis Prevention
• Traffic Analysis - an adversary who monitors or
  compromises parts of a system, in order to match
  message senders with recipients FRAN00
• Network Unobservability - Masking comm. patterns
  which emerge over time
• Achieving network unobservability implies
  ineffective traffic analysis

4
Challenges for TAP

• Loss of efficiency/performance from adding TAP
  mechanisms to a system
• Number of possible senders/recipients bounded

5
Analysis Attacks, cont

• Brute-force
• Following every possible path a message might
  have taken
• Typically results in a list of possible
  sender/recipient pairs
• Node flushing
• A mix node which sends out messages after
  receiving N messages
• Attacker sends N-1 messages to a node, can then
  match his inputs with messages leaving the node
• Encryption, authentication at each mix node
  combats node flushing
• Can be mounted by active adversaries (able to
  manipulate network, as opposed to simply listen)
• Timing attack
• If routes taken by messages have different
  latencies, attacker may use arrival and departure
  times from a network to correlate the path taken

6
Analysis Attacks

• Contextual attack
• Looking at distinguishing features of traffic
  patterns, such as partners taking turns
  communicating, counting numbers of packets in
  arriving and departing messages, etc
• DoS attack
• Destroying some intermediate nodes will affect
  the behavior of some users but not others,
  revealing information about which users take
  which paths
• Exploitation of user reactions
• Intercept a message leaving a mix-node, and
  forward to many recipients
• Users expecting to receive the message will
  behave differently than those not expecting the
  message
• Many others

7
Methods of TAP

• Mixing
• Dummy messages
• Routing

8
Methods of TAP Mixing

• A packet travels from source to destination
  through several intermediate nodes (mix nodes)
• User encrypts the message to be sent
• Each mix node collects packets/messages, releases
  in some different (random) fashion
• The longer a node can hold and collect messages,
  the better the security
• Mixing helps to hide sender-recipient
  relationship by masking the route taken (any one
  node only knows the previous and next hop, not
  entire route)

9
Methods of TAP Dummy Msg.

• Injecting dummy traffic/packets into the network
  (a.k.a. padding)
• Dummy packets should not be distinguishable from
  real packets
• Tradeoff
• Dummy messages may reduce amount of time real
  packets are saved up in mixed nodes, if dummy
  messages are used in conjunction with a mixed
  network
• Dummy messages obviously decrease overall network
  efficiency, increase network overhead

10
Methods of TAP Routing

• Altering routes that packets travel to make
  traffic following difficult
• Varying number of hops
• Onion Routing
• Each intermediate node only knows about previous
  and next node
• As mentioned in mixing, encryption/decryption at
  each node alters messages appearance

11
Case Study NetCamo

• Traffic analysis prevention system developed at
  Texas AM
• Providing traffic security, at the same time as
  QoS guarantees!
• Employs both rerouting and padding (dummy msg.)
• Run by a central Network Controller, makes
  routing and padding decisions based on monitored
  network parameters
• Scalability issues?

12
Conclusions

• Traffic analysis attacks can be mounted from a
  variety of adversaries
• Current methods of TAP reduce the ability of
  adversaries, but fool-proof prevention methods
  are undiscovered or impractical
• TAP methods typically provide security at a
  relatively high cost of added overhead

13
References

• FRAN00 Raymond, J.F., Traffic Analysis
  Protocols, Attacks, Design Issues and Open
  Problems, International Workshop on Designing
  Privacy-enhancing Technologies, 2001, pp. 10-29
• FU03 Fu, X., Bettati, R., and Zhao, W.,
  Analytical and Empirical Analysis of
  Countermeasures to Traffic Analysis Attacks,
  Proceedings of the 32nd International Conference
  on Parallel Processing, October 2003
• NEWM03 Newman, R., Moskowitz, I., and
  Syverson, P., Metrics for Traffic Analysis
  Prevention, Proceedings of the Workshop on
  Privacy-enhancing Technologies, March 2003
• GUAN01 Guan, Y., Fu, X., Xian, D., Shenoy, P.,
  Bettati, R., and Zhao, W., NetCamo
  Camouflaging Network Traffic for QoS-Guaranteed
  Mission Critical Applications, IEEE
  Transactions on Systems, Man, and
  Cybernetics-Part A Systems and Humans, Vol. 31,
  No. 4, July 2001
