On the Shoulders of Giants

1
On the Shoulders of Giants

• An Introduction to Classical Mechanics

2

• If I have seen further it is by standing on the
  shoulders of giants.
• Isaac Newton, Letter to Robert Hooke, February 5,
  1675English mathematician physicist (1642 -
  1727)

3

• Quantum Mechanics (QM) is based on classical
  mechanics. It combines classical mechanics with
  statistics and statistical mechanics.
• For native English-speakers, it is somewhat
  unfortunate that it uses the word quantum. A
  better English word which describes the thrust of
  this approach would be pixel.

4
Lights! Camera! Action!

• 2nd Century BC
• Hero of Alexandria found that light, traveling
  from one point to another by a reflection from a
  plane mirror, always takes the shortest possible
  path.
• 1657
• Pierre de Fermat reformulates the principle by
  postulating that the light travels in a path that
  takes the least time!
• In hindsight, if c is constant then Hero and
  Fermat are in complete agreement.
• Based on his reasoning, he is able to deduce both
  the law of reflection and Snells law (nsinQ n
  sinQ)

5
An Aside

• Fermat is most famous for his last theorem
• Xn Yn Zn where n2 and
• On his deathbed, he wrote
• And n arrgh! Im having a heartattack!
• His last theorem was only solved by computer in
  the last 10 years

6
Now we wait for the Math

• 1686
• The calculus of variations is begun by Isaac
  Newton
• 1696
• Johann and Jakob Bernoulli extend Newtons ideas

7
Now we can get back

• 1747
• Pierre-Louise-Moreau de Maupertuis asserts a
  Principle of Least Action
• More Theological than Scientific
• Action is minimized through the Wisdom of God
• His idea of action is also kind of vague
• Action (todays definition)
• Has dimensions of length x momentum or energy x
  time
• Hmm p x or Et seems familiar

8
To the Physics

• 1760
• Joseph Lagrange reformulates the principle of
  least action
• The Lagrangian, L, is defined as LT-V where T
  kinetic energy of a system and Vpotential energy
  of a system

9
Hamiltons Principle

• 1834-1835
• William Rowan Hamiltons publishes two papers on
  which it is possible to base all of mechanics and
  most of classical physics.
• Hamiltons Principle is that a particle follows a
  path that minimizes L over a specific time
  interval (and consistent with any constraints).
• A constraint, for example, may be that the
  particle is moving along a surface.

10
Lagranges Equations
11
Lagranges Equations
And I can add zero to anything and not change the
result
12
Expanding to 3 Dimensions

• Since x, y, and z are orthogonal and linearly
  independent, I can write a Lagranges EOM for
  each. In order to conserve space, I call x, y,
  and z to be dimensions 1, 2, and 3.
• So
• Amusingly enough, 1, 2, 3, could represent r, q,
  f (spherical coordinates) or r, q, z
  (cylindrical) or any other 3-dimensional
  coordinate system.

13
Example Simple Harmonic Oscillator

• Recall for SHO V(x) ½ kx2 and let T1/2 mv2
• Hookes Law F-kx

14
Tip

• The trick in the Lagrangian Formalism of
  mechanics is not the math but the proper choice
  of coordinate system.
• The strength of this approach is that
• Energy is a scalar and so is the Lagrangian
• The Lagrangian is invariant with respect to
  coordinate transformations

15
Two Conditions Required for Lagranges Equations

• The forces acting on the system (apart from the
  forces of constraint) must be derivable from a
  potential i.e. F-dU/dx or some similar type of
  function
• The equations of constraint must be relations
  that connect the coordinates of the particles and
  may be functions of time.

16
Your Turn

• Projectile
• Go to the board and work a simple projectile
  problem in cartesian coordinates. Dont worry
  about initial conditions yet.

• Now do the same in polar coordinates.
• Hint

17
Introducing the Hamiltonian

• First, any Lagrangian which describes a uniform
  force field is independent of time i.e. dL/dt0.

18
Introducing the Hamiltonian

• Hmmm H for Hornblower or Hamilton?

19
Introducing the Hamiltonian
20
H is only E when

• It is important to note that H is equal to E only
  if the following conditions are met
• The kinetic energy must be a homogeneous
  quadratic function of velocity
• The potential energy must be velocity independent
• While it is important to note that there is an
  association of H with E, it is equally important
  to note that these two are not necessarily the
  same value or even the same type of quantity!

21
Making Simple Problems Difficult with the
Hamiltonian

• Most students find that the Lagrangian formalism
  is much easier than the Hamiltonian formalism
• So why bother?

22
Making Simple Problems Difficult with the
Hamiltonian

• First, we need to define one more quantity
  generalized momenta, pj

23
SHO with the Hamiltonian

• Big deal, right?
• But look what we did
• Lf(q,dq/dt,t)
• Hf(q,p,t)
• So our mechanics all depend on momentum but not
  velocity
• Recall light has constant velocity, c, but a
  momentum which is phc/l !

24
The Big Deal

• So if we are going to define mechanics for light,
  it does not make any sense to use the Lagrangian
  formulation, only the Hamiltonian!

25
That Feynman Guy!

• Richard Feynman thought that Lagrangian mechanics
  was too powerful a tool to ignore.
• Feynman developed the path integral formalism of
  quantum mechanics which is equivalent to the
  picture of Schroedinger and Dirac.
• So which is better? Both and Neither
• There seems to be no undergraduate treatment of
  path integral formalism.

26
Hamiltons Equations of Motion

• Just like Lagrangian formalism, the Hamiltonian
  formalism has equations of motion. There are
  two equations for every degree of freedom
• They are

27
Finishing the SHO
Hookes Law again!
28
Symmetry

• Note that Hamiltons EOM are symmetric in
  appearance i.e. that q and p can almost be
  interchanged!
• Because of this symmetry, q and p are said to be
  conjugate

29
Definition of Cyclic

• Consider a Hamiltonian of a free particle i.e.
  Hf(p) then dp/dt0 i.e. momentum is a
  constant of the motion
• Now in the projectile problem, U-mgy and for
  x-component, Hf(px) only!
• Thus, px constant and the horizontal variable, x
  is said to cyclic!
• A more practical definition of cyclic is
  ignorable and modern texts sometimes use this
  term.

30
Definition of canonical

• Canonical is used to describe a simple, general
  set of something such as equations or
  variables.
• It was first introduced by Jacobi and rapidly
  gained common usuage but the reason for its
  introduction remained obscured even to
  contemporaries
• Lord Kelvin was quoted as saying Why it has been
  so called would be hard to say

31
Poisson Brackets
32
Kronecker Delta

• di,k1 if ik
• di,k0 if i?k

33
Back to Fish

• Consider two continuous functions g(q,p) and
  h(q,p)
• If g,h0 then h and g are said to commute In
  other words, the order of operations does not
  matter
• If g,h1 then quantities are canonically
  conjugate
• A look ahead we will find that canonically
  conjugate quantities obey the Uncertainty
  principle

34
Properties of Fish
35
Levi-Civita Notation
36
Levi-Civita Notation
