Title: Physics in Action


1
Physics in Action
2
Electronic systems
Electronic systems are made up of 3 parts
  • An INPUT SENSOR these detect changes in the
    environment
  • Examples

2) A PROCESSOR these decide what action is
needed Examples
3) An OUTPUT DEVICE these are controlled by
the processor Examples
3
Logic gates
NOT gate the output is NOT what the input is
Logic gates are the basics behind any kind of
processor. There are 3 that you need to know for
GCSE
AND the output is on if A AND B are both on
OR the output is on if A OR B are on
4
Logic gate symbols
NOT gate
AND gate
OR gate
5
Some problems to solve
  • The pump on a central heating system is switched
    on at room temperature if the system is switched
    on (with the slide switch). When the temperature
    rises the pump needs to be switched off.
  • Design a circuit that will sound a buzzer if the
    temperature of a hot radiator falls during the
    day ONLY. Include a test switch to check the
    operation of the buzzer.
  • Design a circuit for a gardener that will warn
    them of cold conditions at night. The alarm
    should be able to be switched off.

6
Relays
Circuits such as those containing logic gates
only take very ______ currents. These circuits
may be needed to operate a device that takes a
much _____ current, e.g. a _________. To do this
the circuit would need a RELAY switch, a device
made of an _______ that can operate a switch. A
relay switch is activated by the small current
and the switch part is placed in the circuit
needing a large current
Words motor, larger, electromagnet, small
7
The Resistor Colour Code
We would use this to determine the value (in ?)
of a resistor
E.g this resistor would have a value of 42 x 10
420? and a tolerance of 5
8
Drawing electronic circuits
12V
0V
9
Drawing electronic circuits
1) Two resistors in series
2) Two resistors in series with one bulb in
parallel
4) An ammeter measuring the current through a
resistor
3) A voltmeter measuring the voltage across two
bulbs in series
10
Potential Dividers
VIN x
(R1 R2)
11
Some example questions
12
Practical applications
Heres a potential divider that is used to
control light-activated switches
When the light intensity on the LDR decreases its
resistance will ________. This causes VOUT to
_______ so the processor and output will probably
turn _____. The variable resistor can be
adjusted to change the ________ of the whole
device.
Words decrease, sensitivity, increase, off
13
Transistors
A transistor acts like a switch
Collector
When a SMALL current flows through the
base-emitter part of the transistor a different
current is switched on through the
collector-emitter part.
Base
Emitter
14
A light dependent switch
15
A light dependent switch
  • When the light on the LDR decreases its
    resistance _________, which will decrease the
    ________ across the variable resistor
  • This will cause VOUT to ____. The____ gate will
    recognise this as a 0 and convert it into a
    1, i.e. a current will flow into the resistor
  • The resistor limits the amount of current flowing
    into the transistor, to avoid __________ it
  • When the transistor detects the current at its
    _____ it will switch __ the collector-emitter
    current
  • A small current will then flow through the
    _______
  • The relay will then switch on a _____ current in
    the output circuit
  • The reversed biased diode is also placed in the
    circuit to act as a _______ to prevent current
    flowing back into the transistor when the relay
    is switched _____

Words base, buffer, on, increases, damaging,
relay, off, larger, voltage, drop, NOT
16
A light dependent switch
We could modify this circuit (if we wanted to)
17
The Capacitor
A capacitor is a device that can store charge (it
has a capacity). It is basically made of two
plates
Charge builds up on these plates and the voltage
between them increases until it reaches the
supply voltage.
18
Charging and discharging a capacitor
P.d.
Time
P.d.
Time
Time
19
Time delay circuits
20
Time delay circuits
R
21
Time delay circuits
  • When the switch is closed the capacitor is being
    short circuited so no charge builds up on it
  • This means that the input to the NOT gate is __,
    so the output is 1 and the output device is ___
  • When the switch is released the capacitor starts
    to ________ up
  • When the voltage across the capacitor reaches a
    certain level the input to the NOT gate becomes
    __ so its output is 0
  • This means that the output device is now switched
    ___
  • To INCREASE the amount of time taken to switch
    the device off you could
  • Increase the _________ of the capacitor
  • _________ the resistance of the resistor R

Words charge, 1, capacitance, increase, 0, off,
on
22
Electronic systems
23
Lenses
Lenses use the idea of refraction
24
Another example
The lens in the eye is used to focus what we see
25
Converging and diverging lenses
CONVERGING (Convex) Thickest at the centre
DIVERGING (Concave) Thinnest at the centre
26
Ray diagrams
The rays of light are refracted INWARDS and meet
at the focus, F. The image formed is REAL in
other words, it can be seen on a screen
F
The rays of light are refracted OUTWARDS. A
VIRTUAL image is formed in other words, the
image doesnt actually exist
F
27
Using lenses to correct vision
Short
Long
28
Ray diagrams
To draw ray diagrams follow these two rules
1) Draw a ray from the TOP of the object
PARALLEL to the axis and then going through F
F
2) Draw a ray from the TOP of the object going
through the CENTRE of the lens (which will be
undeviated)
29
(No Transcript)
30
Practical uses of lenses
