Title: Kinetic Simulation of Sheared Flows in Tokamaks


1
Kinetic Simulation of Sheared Flows in Tokamaks
  • J.A. Heikkinen2, S.J. Janhunen1, T.P. Kiviniemi1,
    S.Leerink1, M. Nora1, and F. Ogando1,3,
  • 1 Teknillinen Korkeakoulu (TKK), Finland
  • 2 Valtion Teknillinen Tutkimuskeskus (VTT),
    Finland
  • 3 Universidad Nacional de Educación a Distancia
    (UNED), Spain

2
Outline
  • Background
  • Gyrokinetic full f approach for toroidal fusion
    plasmas.
  • Examples of Vlasov codes.
  • Description of a PIC full f code.
  • Testing
  • Comparison to neoclassical theory.
  • Linear and nonlinear benchmarks of unstable
    modes.
  • Influence of noise on results.
  • Transport simulations in toroidal plasmas.
  • Future challenges of full f

3
Section IBackground
4
Turbulence and zonal flows
  • Self-organization and zonal flow generation with
    turbulence is important not only in fusion
    plasmas but also in other fluids like planetary
    atmoshpheres and solar plasma
  • Transport transients and related transport
    barriers are important, e.g., for ITER fusion
    reactor design
  • Empirical evidence from a number of tokamak
    facilities indicates a complex scaling law for
    transport transients
  • The scaling laws for transport barriers in
    tokamaks are today to a large extent not
    understood by physics principles

5
Sheared flows and turbulence appear in toroidal
plasma simulation
6
Kinetic simulation required
  • All trials up to date around the world to see the
    spontaneous confinement transition in an
    experimental-like first principles plasma
    simulation have failed so far.
  • Reason to this may be that not all relevant
    physics like kinetic details of particle motion
    have been included in the simulation codes, lack
    of self-consistency with background evolution, or
    model simplifications like using fluid codes have
    been too crude.

7
Section IIGyrokinetic full f approach for
simulation of toroidal plasmas
8
Full f simulation of tokamak plasmas
  • In full f simulation, one solves for the whole
    particle distribution function in phase space and
    in time either non-perturbatively, with
    gyrokinetics or drift-kinetically
  • Pioneering non-perturbative 5D particle-in-cell
    (PIC) simulation of magnetically confined
    toroidal plasmas (unrealistic me/mi)
  • Cheng Okuda, 78 Sydora, 86 LeBrun, 93,
    Kishimoto, 94
  • Eulerian and semi-Lagrangian Vlasov 3D, 4D, and
    5D simulation
  • Cheng Knorr, 76 Manfredi, 96
    Sonnendruecker, 99 Xu, 06 Scott, 05
    Grandgirard, 06
  • Gyrokinetic 5D particle simulation
  • Furnish, 99 Heikkinen, 00, 03 Chang, 03.

9
Calculation flux in particle codes
Calculation of forces from fields and velocity
Acceleration and increment of velocity
Computation of electric field. Magnetic is given.
Initial step with ?0
Displacements and new positions. Boundary
conditions.
Calculation of density. Current profile fixed.
Resolution of Poisson equation for the
electrostatic potential.
10
Delta f vs. full f
  • Delta f calculates perturbations from an assumed
    background distribution f0.
  • Powerful for small f-f0
  • Linear mode analysis
  • Snapshot transport analysis
  • Path-breaking global transport studies for large
    toroidal installations
  • Full f calculates the whole particle
    distribution.
  • Fitting processes that perturbate strongly the
    particle distribution
  • Strong transient or long time scale transport in
    core or edge plasmas
  • Strong particle/energy sources
  • Full neoclassical equilibrium
  • Edge plasma (sheaths, wall losses, recycling,
    separatrix, flows)
  • Large MHD (sawteeth, ELMs)

11
Delta f vs. full f
  • Automatic extension of Delta f to full f
    calculation may be possible
  • Non-conservative effects collisions, sources
  • Loading optimization
  • Automatic increase of the number of markers when
    required
  • Few particles (10-100) per cell are needed for
    good results with small f-f0.
  • Full f can be realized both in PIC and Vlasov
    (Eulerian, semi-Lagrangian)
  • Vlasov simulation is free of noise and has
    controlled numerical resolution in phase space.
  • PIC is numerically flexible and straightforward
    to implement
  • Needs many particles per cell (1000) or fine
    grid discretization of velocity space for an
    acceptable noise level or accuracy.

12
Section IIIExamples of full f Vlasov codes
13
Full f 5D gyrokinetic code GYSELA Grandgirard,
06 (CEA, LPMIA-Univ, IRMA-Univ, LSIIT-Illkirch)
  • Semi-Lagrangian GYSELA code
  • - fixed grid, follows trajectories backwards,
  • - global code
  • - 5D GAM and ITG Cyclone tests successful

14
Full f 5D gyrokinetic code TEMPEST Xu 06 (LLNL,
Calif-Univ, GA, LBNL, PPPL)
  • - Based on modified gyrokinetics valid for large
    long-wavelength and small short-wavelength
    variations (Qin, 06)
  • - Fixed grid, equations solved via a
    Method-of-Lines approach and an implicit
    backward-differencing scheme using iteration
    advances the system in time
  • - Developed for circular core or divertor edge
    geometry
  • - 4D neoclassical tests successful. 5D drift wave
    and ITG benchmarking ongoing

15
Section IVThe ELMFIRE code an example of a full
f PIC code
16
The ELMFIRE group
Founded in 2000 at Euratom-Tekes Contributors
from Finland Spain Holland Main
affiliations VTT TKK ... but also ... CSC Åbo
Akademi UNED (Spain)
17
ELMFIRE code
  • Full f nonlinear gyrokinetic particle-in-cell
    approach for global plasma simulation (present
    version electrostatic).
  • Magnetic coordinates (?,?,?) Boozer 81.
  • Guiding-center Hamiltonian White Chance, 84.
  • Gyrokinetics is based on Krylov-Boholiubov
    averaging method in description of FLR effects
    (P. Sosenko, 01).
  • Adiabatic or kinetic electrons with impurities.
  • Parallelized using MPI with very good
    scalability.
  • Based on free software PETSc and GSL for math
    calc.

18
ELMFIRE full f features
  • An initial canonical distribution function avoids
    the onset of unphysical large scale ExB flows
    (Heikkinen, 01)
  • Direct implicit ion polarization (DIP) and
    electron acceleration (DEP) sampling of
    coefficients in the gyrokinetic equation
  • Quasi-ballooning coordinates to solve the
    gyrokinetic Poisson equation
  • Versatile heat (RF, NBI, Ohmic) sources and
    particle sources/ recycling
  • Full binary collision operator

19
Poisson equation
  • W.W. Lee proposed standard model with
    polarization drift included in equation operator.
  • Ion density evaluated from ion motion without
    polarization drift
  • P. Sosenko proposes including polarization in the
    ion density.
  • Ion density evaluated from ion motion with
    polarization drift. Circular gyro-orbits.

20
Implementation into ELMFIRE
  • Solve ? by isolating ion polarization drift
    contribution to density.
  • That contribution is calculated implicitely every
    timestep using also previous values of ?.
  • The gyroaveraged electric field is interpolated
    from grid potential values for the ion
    polarization drift.

Larmor circle
ith subparticle cloud
y
k
i
?py
?px0
xp,yp
?px-
?px
?py0
ds
k
?py-
x
pth point on the Larmor orbit of the kth ion
gyro-center of the kth ion
21
Section VBenchmarking of ELMFIRE
22
Testing ELMFIRE
  • Comparison to neoclassical theory in the presence
    of turbulence.
  • Frequency of GAM and Rosenbluth residual.
  • Neoclassical radial electric field.
  • Comparison to other codes has been done in the
    Cyclone Base cases.
  • Linear growth of unstable modes and their phase.
  • Nonlinear saturation of transport in both
    adiabatic and kinetic-electron case.
  • Comparison to experimental results.
  • Collaboration with IOFFE Institute and St.
    Petersburg Polytechnic working with the FT-2
    tokamak.

23
Available resources
  • Gyrokinetic full f computation is very demanding
    computationally. Parallel computation is a need.
  • CSC (The Finnish IT Center for Science) provides
    shared use of high-end parallel computers.
  • IBM eServer cluster 1600. 512 processors with
    2.2TFlops, 384GB RAM and High Performance Switch
    communication.
  • Cluster of 768 AMD OpteronTM processors up to
    3.2TFlops, 1600GB RAM, Infiniband network.
  • Cray XT4 (Hood) 70TFlop, 70TB RAM HP ProLiant
    Supercluster, 10.6 Tflop, 100 TB

24
Geodesic Acoustic Modes
  • Neoclassical theory predicts GAM frequency and
    Rosenbluth residual.
  • Results show good wide agreement with theory.
  • Simulations done on a plasma annulus.
  • R0.3-0.9 m, a0.08 m, B0.6-2.45 T, q1.28-2.91,
    Ti90-360 eV, ni5.11019m-3 (r/a0.75)

25
Neoclassical radial electric field
  • Neoclassical radial electric field is well
    followed in conventional (L-mode) turbulent
    simulations both in radius and in time
  • R1.1 m, a0.08 m, B2.1 T, I22 kA, parabolic
    ion heated n,Ti,e profiles (r0.04m).

26
Neoclassical benchmarking
  • Parameters and boundary conditions
  • FT-2 like parameters, R00.55 m and a0.08 m,
  • Itot 55 kA, T,n,j (1-(r/a)2)? ,
  • n051019 1/m3
  • T0300 eV in high T case, T0120 eV in low T
  • no heating, no loop voltage
  • relaxing profiles, cooling by recycling on
    outer radius

27
Neoclassical benchmarking
Number of particles must be sufficient as Er may
depend on noise Er radial dependence fairly well
predicted by standard neoclassical theory.
However, Reynolds stress and poloidal Mach number
can be important.
28
Linear growth of unstable modes
  • Test based on adiabatic Cyclone Base Case (Dimits
    PoP '00)
  • Red points from ELMFIRE, blue line fit from
    article.
  • Figures show growth rates and typical time
    evolution for a mode with k??i0.3

29
Linear growth of unstable modes
  • Test based on adiabatic Cyclone Base Case (Dimits
    PoP '00)
  • Red points from ELMFIRE, blue line fit from
    article.
  • Figures show growth rates and typical time
    evolution for a mode with k ?? i0.3

Region of linear growth
30
Linear growth of unstable modes
  • Test based on kinetic Cyclone Base Case (Chen NF
    '03)
  • Filled circles and squares from ELMFIRE
  • Dashed line fit for the growth rate ? from Chen
    NF 03.

31
Evolution of thermal conductivity
  • Evolution of ?i is studied with nonlinear runs of
    Cyclone Base.
  • Measured at ra/2 (q1.4). Using kinetic
    electrons. R/LT10. Weak collisionality
    T(a/2)2000 eV, n51017 m-3.
  • Convergence requires a large number of particles
    per cell.

32
Section VIInfluence of noise on results
33
Influence of noise on results
  • Particle simulation not only covers physical
    density fluctuations, but it produces undesirable
    noise with fluxes that perturbate the solution.
  • Associated diffusivity can be estimated from the
    radial particle shift during decorrelation time.
  • Physical radial ion heat conductivity can be
    estimated from mixing-length estimate of the
    physical level of fluctuations, being also
    proportional to T3/2.

34
Effects on calculated conductivity
  • Image shows influence of strong collisionality
    and potential averaging on ion radial heat
    conductivity.
  • Collisionless cases show residual noise
    conductivity.
  • Noise is filtered out by averaging potential over
    flux surface.
  • So far noise is reduced by brute force ...
    higher N!

Scaled Cyclone Base Case with kinetic electrons
T100 eV, n4.51019 m-3
35
Contribution of noise to the heat flux
The convective noise flux prediction gives a
fairly good estimate of the unphysical ion heat
conductivity in the simulations
36
From noise to turbulence spectrum
Wave number spectrum from different time
instants demonstrates how one moves from white
noise to physical spectrum in modes.
37
Problematic levels of noise
Fluctuations _at_ ra/2
  • Figure show exceptionally bad case regarding
    noise effects.
  • It is a kinetic cyclone base case with scaled
    parameters and low T100eV and n4.51017 m-3.
  • Density fluctuations remain almost constant in
    time.
  • Regression shows almost perfect N-1/2 scaling,
    indicating that results are dominated by noise.

38
but not always problematic...
  • In FT-2, fluctuation levels are much higher
    (10-40) than in scaled Cyclone Base Case (1).
  • So high perturbation level warrants the use of a
    full f scheme.
  • Image shows density fluctuations relative to flux
    surface average.
  • Relative importance of noise values can be seen
    in videos of both cases.

39
Probability distribution functions
  • Fluctuation levels can be represented by the PDF
    graphs.
  • PDFs show fluctuation distributions over a middle
    flux surface.
  • Density values are averaged over time.
  • Turbulence in FT-2 takes fluctuations up to 40
    in start (up) and 15 after 50µs (down).

40
Section VIITransport simulations
41
Case 1 under study LH heated FT-2
  • Parameters from 100 kW LH heated 22 kA FT-2
    tokamak.
  • Case shows a rapid growth of potential and
    electric field and reduction of thermal
    conductivity interpreted as ITB formation.
  • Top figure diagram (r,t) of flux surface average
    of potential.
  • Bottom figure ion diffusivity at mid radius.

42
Evolution of profiles
  • Strong ExB flow shear is created at r0.05 m,
    where a knee-point in Ti profile is found

43
Calculated spectra
  • Parameters of the FT-2 case, devised to cause the
    formation of Internal Transport Barrier.
  • B2.2T, I22kA, n3.51019m-3, Ti250eV, Te300eV

S(k) at r5.1cm
? vs. time
S(k) at r7.5cm
44
Case 2 under study LH heated FT-2
  • Heating phase for 100 kW LH heated 22 kA FT-2
    tokamak (O8 impurities included).

45
Evolution of large scale fluctuations
  • Density fluctuations plots show the formation and
    further destruction of macroscopic structures

46
Evolution of diffusivity
  • Both particle diffusivity and heat conductivity
    drop drastically when poloidal flow shear
    destroys the turbulent structures
  • The figures show values from the middle radius

47
Case 3 under study Ohmic FT-2
  • Reproduce the FT-2 reflectometer signal I(t)
    with ELMFIRE
  • I(t)? w(r,?) dn(r,?,t) r dr d?
  • W(r, ? ) Weighting function calculated by beam
    tracing code using exp. data
  • dn(r,?,t) Density fluctuations simulated by
    ELMFIRE code
  • Results
  • Poloidal velocity calculated by the shift of the
    power spectrum of I(t) is in reasonable agreement
    with the poloidal velocity measured by the
    Doppler reflectometer for an Ohmic discharge
  • Width of the power spectrum is too narrow
    compared to the experimental results.

48
Frequency broadening is too narrow in the
simulation
49
Section VIIIFuture challenges
50
Unresolved issues in full f
  • How to ensure a sufficient number of particles in
    all grid cells when density varies strongly in
    global PIC simulation
  • Adaptation of good grid resolution for strongly
    varying f in Vlasov simulations
  • Full collision operator in Vlasov simulations
  • SOL plasma simulation with sheath boundaries
  • Gyrokinetics with strong fluctuations

51
Scalability
IB-new Sepeli with InfiniBand and optimized
parallelization IB Sepeli with InfiniBand LAM
Sepeli with Gigabit Ethernet IBM-new IBM with
optimized parellelization
52
Resource scenario
53
Conclusions
  • Successful 5D gyrokinetic full f PIC and Vlasov
    simulations of tokamak electrostatic turbulence
    and transport for core plasma.
  • Careful benchmarking of the codes is performed in
    appropriate limits for the turbulence saturation
    and neoclassical characteristics.
  • Linear and nonlinear benchmarking.
  • Vlasov approach has less noise and better control
    of resolution PIC code is more flexible to
    implement
  • Most urgently needed for edge plasma simulations
    further development of nonlinear terms in
    gyrokinetics may be needed

ACKNOWLEDGEMENTS
This project receives funding from the European
Commission
CSC The Finnish IT Center for Science for its
computing facilities
Write a Comment
User Comments (0)
About PowerShow.com
