Introductions to Constellations

1
Introductions to Constellations
2
http//www.astro.umass.edu/ngow/
http//www.chinapage.com/astronomy/chart/celestial
chart.html
http//www.geocities.com/ResearchTriangle/System/8
870/memory/
3
What did the ancient people use stars (patterns
of stars) for?

• Navigation sailing, travel
• Seasons when to plant and harvest
• Preserve myths, traditions, etc
• Group the brighter stars into patterns, -
  constellations

4
Patterns of stars
Boundaries
http//www.astro.virginia.edu/class/oconnell/astr1
30/im/
5
Constellation

• One of the 88 named Regions of sky defined by the
  International Astronomical Union (IAU)
• Identified with the officially recognized
  Patterns of Stars that lie within the boundaries
  of the region

6
The Northern Hemisphere
7
About Constellations

• Stars in a constellation usually NOT physically
  associated with each others

8
About Constellations

• Some constellations have a lot of bright stars
  (Orion), others mainly contain dim stars.
• Symbolized figures, some patterns don't look like
  the subjects

9
What are the 88 Constellations?

• 14 men and women
• 9 birds
• 19 land animals
• 2 insects
• 10 water creatures
• 2 centaurs
• 1 head of hair
• 1 serpent
• 1 dragon
• 1 flying horse
• 1 river
• 29 inanimate objects, include scientific
  instruments (Microscopium, Telescopium)

10
Asterism

• A generally recognized smaller/cuter pattern of
  stars that is not one of the officially
  recognized constellations
• Whether or not a region of sky is named after it
  yes constellation no asterism

11
Asterism

• The Big Dipper in Ursa Major
• The Little Dipper in Ursa Minor
• The W of Cassiopeia
• Lozenge of Draco
• House (Cepheus)
• Sword of Orion, Belt of Orion

12
History of Modern Constellations

• (Uncertain) Origin Nomad in Mesopotamia named
  some northern constellations more than 5,000
  years ago, including Leo and Taurus
• More constellations were added by Babylonian,
  Egyptian and Greek

13
History of modern constellations

• Oldest systematic description of constellations
  Phaenomena, in 270 B.C. by Greek poet Aratus

http//www.wikipedia.org
14
History of modern constellations

• In 150 A.D., Ptolemy published The Almagest (The
  Great Book)
• A catalog of 1022 stars, with estimates of their
  brightness, arrange into 48 constellations. The
  48 constellations formed the basis for our modern
  constellations
• 44 southern constellations were added after 16th
  century

http//www.wikipedia.org
15
History of modern constellations

• IAU officially adopted the list of 88
  constellations that we use today in 1922
• Definitive boundaries between constellations were
  set in 1930 88 regions cover the ENTIRE sky
• For todays astronomer, constellations refer not
  so much to the patterns of the stars, but to
  precisely defined areas of the sky

16

• Modern constellations
• Greek Constellations
• Latin Names
• Many stars have Arabic names
• Al-Sufin, one of the greatest Arabic astronomers,
  translated Ptolemys book into Arab in the 10th
  century
• Different cultures grouped stars and named
  constellation differently

17
(No Transcript)
18
Are constellations permanent?

• Are stars fixed?
• Stars all move relative to the Sun, with speed of
  many kilometers per seconds
• Stars are far away, and stars in the
  constellations are at different distances
• Stars will move, shapes of constellations will
  change, but it takes thousands of years to see
  the change

19
What are circumpolar Constellations?
20
Star Trail

• Earth rotates about an axis that is pointed very
  close to the star Polaris
• Stars rise in the east and set in the west
  everyday

Anglo Australian Observatory
21
Circumpolar Constellations

• A Constellation that NEVER rises or sets as seen
  at a certain latitude
• Six circumpolar constellations seen in Amherst
  (42º N, 72º W)
• Ursa Major Larger Bear
• Ursa Minor Smaller bear
• Cassiopeia Queen
• Cepheus King
• Draco Dragon
• Camelopardalis The Giraffe

22
Circumpolar Constellations at Amherst
Cassiopeia
Ursa Major
Ursa Minor
Draco
Cepheus
Camelopardalis

• www.acmecompany.com/

23
Questions

• Where on the earth can we see the maximum number
  of circumpolar constellations?
• - At the earths pole
• Where on the earth can we see the minimum number
  of circumpolar constellations?
• - At the earths equator

24
Summary

• Definition of Constellation
• 88, patterns of stars, boundaries
• Asterisms
• Not official
• If theres a region of sky named after it
• Stars in a Constellation usually do not have
  physically connections
• Circumpolar constellations
• Never rise or set
• Remember the 6 circumpolar constellations seen at
  Amherst

25
Find the big dipper
26
How to find Polaris from the Big Dipper and
Cassiopeia

• From the Dipper, follow the two stars at the
  end of its bowl toward Cassiopeia. There, about
  five times the separation of these two stars,
  you'll find Polaris.
• Use the middle three stars of Cassiopeia's "W"
  as an arrow to point in the direction of the
  Dipper. Halfway there you will encounter Polaris.


27
Do we see different constellations at different
seasons?

• Earth rotates about an axis that is pointed very
  close to the star Polaris
• Stars rise in the east and set in the west
  everyday
• It takes 4 minutes less for a star to come back
  to the position yesterday
• If we observe the sky at the same time every
  night, (say 9pm), the positions of constellations
  will change night by night
• 4 minutes each day, is 24 hours for 365 days!
• At different seasons, we see different
  constellations!

28
Zodiac Constellations

• Constellations of stars that lie along the
  apparent path of the Sun across the heavens (the
  ecliptic)
• Aquarius, Pisces, Aries, Taurus, Gemini, Cancer,
  Leo, Virgo, Libra, Scorpio, Sagittarius,
  Capricorn

29

• Summer Triangle
• ?? Altair, alpha Aquila
• ?? Vega, alpha Lyra
• ??? Deneb, alpha Cyg
• Winter Triangle
• Arcturus, the brightest star in the northern sky,
  in Bootes
