Theoretical Foundations of Clustering MLSS Tutorial

1
Theoretical Foundations ofClustering MLSS
Tutorial

• Shai Ben-David
• University of Waterloo,
• Waterloo,
• Canada

2
The Theory-Practice Gap
Clustering is one of the most widely used
tool for exploratory data analysis. Social
Sciences Biology Astronomy Computer
Science . . All apply clustering to gain
a first understanding of the structure of large
data sets.
Yet, there exist distressingly little
theoretical understanding of clustering
3
Overview of this tutorial

• What is clustering? Can we formally define it?
• Model selection issues How would you chose the
  best clustering paradigm for your data? How
  should you choose the number of clusters?
• Computational complexity issues Can good
  clustering be efficiently computed?

4
Questions that research of fundamentals of
clustering should address

• Can clustering be given an formal and general
  definition?
• What is a good clustering?
• Can we distinguish clusterable from
  structureless data?
• Can we distinguish meaningful clustering from
  random structure?

5
Inherent Obstacles
Clustering is not well defined. There is a wide
variety of different clustering tasks, with
different (often implicit) measures of quality.
6
There are Many Clustering Tasks

• Clustering is an ill defined problem

There are many different clustering
tasks, leading to different clustering
paradigms
7
There are Many Clustering Tasks

• Clustering is an ill defined problem

There are many different clustering tasks,
leading to different clustering
paradigms
8
Some more examples
9
Some real examples of clustering ambiguity

• Cluster paintings
• by painter vs. topic
• Cluster speech recordings
• by speaker vs. content
• Cluster text documents
• by sentiment vs. topic

10
Other Inherent Obstacles
In most practical clustering tasks there is no
clear ground truth to evaluate your solution
by. (in contrast with classification tasks, in
which you can have a hold out labeled set to
evaluate the classifier against).

11
Examples of some popular clustering paradigms
Linkage Clustering

• Given a set of points and distances between them,
  we extend the distance function to
• apply to any pair of domain subsets. Then the
  clustering algorithm proceeds in stages.
• In each stage the two clusters that have the
  minimal distance between them are merged.
• The user has to set the stopping criteria
  when should the merging stop.

12
Single Linkage Clustering- early stopping
13
Single Linkage Clustering correct stopping
14
Single Linkage Clustering late stopping
15
Examples of some popular clustering paradigms
Center-Based Clustering

• The algorithm picks k center points
• and the clusters are defined by assigning
  each domain point to the center closest to it.
• The algorithm aims to minimize some cost
• function that reflects how compact the
  resulting clusters are.
• Center-based algorithm differ by their choice
  of the cost function (k-means, sum of distances,
  k-median and more)
• The number of clusters, k, is picked by the
  user.

16
4-Means clustering example
17
Examples of some popular clustering paradigms

• Single Linkage
• The K-means algorithm
• The K-means objective optimization.
• Spectral clustering
• The actual algorithms
• The objective function justification.
• EM algorithms over parameterized families of
  (mixtures of simple) distributions.

18
Common Solutions
Objective utility functions Sum Of In-Cluster
Distances, Average Distances to Center Points,
Cut Weight, etc. (Shmoys, Charikar, Meyerson
)
Consider a restricted set of distributions
(generative models) E., g, Mixtures of
Gaussians Dasgupta 99, Vempala,, 03,
Kannan et al 04, Achlitopas, McSherry 05.
Add structure Relevant Information
Information Bottleneck approach Tishby,
Pereira, Bialek 99
19
Common Solutions (2)
Focus on specific algorithmic paradigms Projectio
ns based clustering (random/spectral) all the
above papers
Spectral-based representations (Meila and Shi,
Belkin, ..) The k-means algorithm
Axiomatic approach Postulate clustering axioms
that, ideally, every clustering approach should
satisfy - usually conclude negative results (e.g.
Hartigan 1975, Puzicha, Hofmann, Buhmann 00,
Kleinberg 03).
Many more
20
Quest for a general Clustering theory

• What can we say independently of any particular
  algorithm,
• particular objective function
• or specific generative data model
• ?

21
Many different clustering setups

• Different inputs
• Points in Euclidean space.
• Arbitrary domain with a point-similarity measure.
• A graph (e.g., social networks, web pageslinks)
• ..
• Different outputs
• Hierarchical (dendograms)
• Partitioning of the domain
• Soft/probabilistic clusters
• ..

22
Our Basic Setting for Formal Discussion

• For a finite domain set S, a dissimilarity
  function (DF) is a mapping, dSxS ? R, such
  that
• d is symmetric,
• and
• d(x,y)0 iff xy.
• Our Input A dissimilarity function on S (or a
  matrix of pairwise distances between domain
  points)
• Our Output A partition of S.
• We wish to define the properties that
  distinguish clustering functions from other
  functions that output domain partitions.

23

• Input

Output a partition of the domain, x1,x7,
x2,x5,x9
24
Kleinbergs Axioms

• Scale Invariance
• F(?d)F(d) for all d and all strictly
  positive ?.
• Richness
• For any finite domain S,
• F(d) d is a DF over SPP a partition of
  S
• Consistency
• If d equals d, except for shrinking distances
  within clusters of F(d) or stretching
  between-cluster distances , then F(d)F(d).

25
Note that any pair is realizable

• Consider Single-Linkage with different
  stopping criteria
• k connected components.
• Distance r stopping.
• Scale a stopping
• add edges as long as their length is
• at most a(max-distance)

26
The Surprising result

• Theorem There exist no clustering function
• (that satisfies all of the three Kleinberg
  axioms simultaneously).

27
Kleinbergs Impossibility result

• There exist no clustering function
• Proof

28
What is the Take-Home Message?

• A popular interpretation of Kelinbergs result
  is (roughly)
• Its Impossible to axiomatize clustering
• But, what that paper shows is (only)
• These specific three axioms cannot work

29
Ideal Theory

• We would like the axioms to be such that
• 1. Any clustering method satisfies all the
  axioms,
• and
• 2. Any function that is clearly not a
  clustering fails to
• satisfy at least one of the axioms.
• (this is probably too much to hope for).
• We would like to have a list of simple properties

• so that major clustering methods are
  distinguishable from each other using these
  properties.

30
Axioms to guide a taxonomy of clustering paradigms

• The goal is to generate a variety of axioms (or
  properties) over a fixed framework, so that
  different clustering approaches could be
  classified by the different subsets of axioms
  they satisfy.

Axioms
Properties
31
Types of Axioms/Properties

• Richness requirements
• E.g., relaxations of Kelinbergs richness,
  e.g.,
• F(d) d is a DF over SPP a partition of S
  into k sets
• Invariance/Robustness/Stability requirements.
• E.g., Scale-Invariance, Consistency,
  robustness
• to perturbations of d (smoothness of F) or
  stability w.r.t. sampling of S.

32
Relaxations of Consistency

• Local Consistency
• Let C1, Ck be the clusters of F(d).
• For every ?0 1 and positive ?1, ..?k 1, if
  d is defined by
• ?id(a,b) if a and b are in Ci
• d(a,b)
• ?0d(a,b) if a,b are not in same
  F(d)-cluster,
• then F(d)F(d).
• Is there any known clustering method for which
  it fails?

33
Some more structure

• For partitions P1, P2 of 1, m say that P1
  refines P2 if every cluster of P1 is contained in
  some cluster of P2.
• A collection CPi is a chain if, for any P, Q,
  in C, one of them refines the other.
• A collection of partitions is an antichain, if no
  partition there refines another.
• Kleibergs impossibility result can be rephrased
  as
• If F is Scale Invariant and Consistent then
  its range is an antichain.

34
Relaxations of Consistency

• Refinement Consistency
• Same as Consistency (shrink in-cluster,
  strech between-clusters) but we relax the
  Consistency requirement F(d)F(d) to
• one of F(d), F(d) is a refinement of
  the other.
• Note A natural version of Single Linkage (join
  x,y, iff d(x,y) lt ?maxd(s,t) s,t in X)
  satisfies this Scale Invariance Richness.
• So Kleinbergs impossibility result breaks
  down.
• Should this be an axiom?
• Is there any common clustering function that
  fails that?

35
More on Refinement Consistency

• Minimize Sum of In-Cluster Distances satisfies
  it
• (as well as Richness and Scale Invariance).
• Center-Based clustering fails to satisfy
  Refinement Consistency
• This is quite surprising, since they look very
  much alike.

(Where d is Euclidean distance, and ci the center
of mass of Ci)
36
Hierarchical Clustering

• Hierarchical clustering takes, on top of d, a
  coarseness parameter t.
• For any fixed t, F(t,d) is a clustering
  function.
• We require, for every d
• CdF(t,d) 0 t Max a chain.
• F(0,d) x x e S and F(Max,d)S.

37
Hierarchical versions of axioms

• Scale Invariance For any d, and ?gt0,
• F(t,d) t F(t, ?d)t (as sets of
  partitions).
• Richness For any finite domain S,
• F(t,d)t d is a DF over SCC a chain of
  partitions of S (with the needed Min and Max
  partitions).
• Consistency If, for some t, d is an F(t,d)
  -consistent transformation of d, then, for some
  t, F(t,d)F(t,d)

38
Characterizing Single Linkage

• Ordinal Clustering axiom
• If, for all w,x,y,z,
• d(w,x)ltd(y,z) iff d(w,x)ltd(yz)
• then F(t,d) t F(t,d)t (as sets of
  partitions).
• (note that this implies Scale Invariance)
• Hierarchical Richness Consistency Ordinal
  Clustering characterize Single Linkage
  clustering.

39
Other types of clustering

• Edge-Detection (advantage to smooth contours)
• Texture clustering
• -The professors example.

40
A different setup for axiomatizationMeasuring
the Quality of clustering

• You get a data set.
• Run, say, your 5-means clustering algorithm,
• and get a clustering C.
• You compute its 5-means cost -- its 0.7.
• Can you conclude that C is a good clustering?
• How can we verify that structure described by
• C is not just noise?

41
Clustering Quality Measures

• A clustering-quality measure is a function
• m(dataset, clustering)
• so that these values reflect how good or
  cogent that clustering is.

42
Axiomatizing Quality Measures

• Consistency
• Whenever d is a C consistent variant of d,
• then m(C,X, d) m(C,X, d).
• Scale Invariance
• For every positive ?, m(C,X, d) m(C,X, ?d).
• Richness
• For each non-trivial clustering C of X,
• there exists a distance function d over X
  such that C Argmaxm(C,X, d).

43
An Additional Axiom Isomorphism Invariance

• Clusterings C and C over (X, d) are isomorphic,
  if there exists a distance-preserving
  automorphism F X ? X,
• such that x, y share the same C-cluster iff
  F(x) and F(y) share the same C-cluster.
• Isomorphism Invariance
• If C and C are isomorphic then
• m(C,X, d) m(C,X, d).

44
Major gain (over Kleinbergs framework)

• Every reasonable clustering quality measure
  satisfies our axioms.
• Clustering functions can be defined as
• functions that optimize the clustering
  quality.

45
Some examples of quality measures

• Normalized clustering cost functions
• (e.g., k-means, ratio-cut, k-median etc. )
• Variance ratio
• V R(C,X, d)
• Relative margins
• (the average ratio between the distance from a
  point to its cluster center, and its distance to
  its second-closest cluster center).

46
Major gain (over Kleinbergs framework)

• Every reasonable clustering quality measure
  satisfies our axioms.
• Clustering functions can be defined as
• functions that optimize the clustering
  quality.

47
Basic Open Questions

• What do we want from a set of clustering axioms?
  (Meta axiomatization )
• How can the completeness of a set of axioms be
  defined/argued?
• Is there a general property distinguishing,
• say, linkage-based from center-based
  clusterings?
• Any candidate general clustering properties
  that the axioms should prove?

48
Single Linkage Clustering
