Introduction to MT

1
Introduction to MT

• Ling 575
• Fei Xia
• Week 2 1/09/07

2
Outline

• Course overview
• Discussion
• Introduction to MT
• Divergence and crossing

3
Questions

• Who is going to do a MA thesis on MT?
• Who knows a language other than English?
• Have you played with MT systems (e.g., BabelFish)
  before?
• Any particular topics that interest you?

4
Course overview
5
General info

• Course website http//courses.washington.edu/lin
  g575x/
• Syllabus (incl. slides and papers) updated every
  week.
• Message board
• ESubmit
• Office hours Fri 10am-1120am.
• Prerequisites
• Ling570
• Programming C or C.
• Introduction to probability and statistics

6
Expectations

• Reading
• Papers are online
• Finish reading before class. Bring your questions
  to class.
• Grade
• Assignments 30
• Project 50
• Class participation 20
• No quizzes, exams

7
Assignments

• Three assignments, 10 each
• Goal become familiar with common MT packages
• GIZA IBM Models 1-4
• Pharaoh clump-based decoder

8
Project

• Pick a date (via EPost) 4th 9th weeks
• Choose a topic and find papers
• Choose 1-2 papers and tell the group
• Leading discussion 40 min 1 hour
• Final short presentation (?) 15-20 mins
• Final report

9
Deadlines

• Jan 13 Choose the date (via EPost)
• 1 week before your presentation email me the
  topic and 1-2 papers
• 1 day (by 8am on Monday) email me your slides

• On the day presentation
• March 13 final report, via ESubmit

10
Final presentation/report

• Leading discussion literature review
• Final presentation an update on the topic and/or
  methodology.
• Final report
• Major previous work on the topic.
• Your thoughts and plan to address it
• The literature review and methodology
  chapters of your MA thesis.

11
Possible topics

• MT with bridge languages
• MT for Low-density languages
• Collecting parallel data
• New models
• Decoding
• System combination
• Preprocessing e.g., NE translation
• Postprocessing e.g., reranking
• .

12
Finding papers

• Go to acl.ldc.upenn.edu
• Look under CL, ACL, COLING, EACL, HLT, NAACL, and
  Workshops (e.g., EMNLP).
• Search for keywords such as Machine translation

13
Finding papers (cont)

• Citeseer citeseer.ist.psu.edu
• Start with several papers on a topic and compare
  the reference lists find the intersection.
• Feel free to email me with the candidates
  beforehand.

14
Session layout

• Week 1 no class
• Weeks 2-3 Fei
• Weeks 4-9 Fei and a student
• Week 10 students

15
Questions?
16
Discussion
17
Questions

• What resources do you need to build an MT system?
• How does a MT system work? How would you build an
  MT system?
• What are the main challenges?
• What are the major approaches?

18
Introduction to MT
19
A brief history of MT (Based on work by John
Hutchins)

• Before the computer In the mid 1930s, a
  French-Armenian Georges Artsrouni and a Russian
  Petr Troyanskii applied for patents for
  translating machines.
• The pioneers (1947-1954) the first public MT
  demo was given in 1954 (by IBM and Georgetown
  University).
• The decade of optimism (1954-1966) ALPAC
  (Automatic Language Processing Advisory
  Committee) report in 1966 "there is no immediate
  or predictable prospect of useful machine
  translation."

20
A brief history of MT (cont)

• The aftermath of the ALPAC report (1966-1980) a
  virtual end to MT research
• The 1980s Interlingua, example-based MT
• The 1990s Statistical MT
• The 2000s Hybrid MT

21
Where are we now?

• Huge potential/need due to the internet,
  globalization and international politics.
• Quick development time due to SMT, the
  availability of parallel data and computers.
• Translation is reasonable for language pairs with
  a large amount of resource.
• Start to include more minor languages.
• Got stuck?

22
What is MT good for?

• Rough translation web data
• Computer-aided human translation
• Translation for limited domain
• Cross-lingual IR
• Machine is better than human in
• Speed much faster than humans
• Memory can easily memorize millions of
  word/phrase translations.
• Manpower machines are much cheaper than humans
• Fast learner it takes minutes or hours to build
  a new system. Erasable memory ?
• Never complain, never get tired,

23
Major challenges in MT
24
Translation is hard

• Novels
• Word play, jokes, puns, hidden messages
• Concept gaps go Greek, bei fen
• Other constraints lyrics, dubbing, poem,

25
Major challenges

• Getting the right words
• Choosing the correct root form
• Getting the correct inflected form
• Inserting spontaneous words
• Putting the words in the correct order
• Word order SVO vs. SOV,
• Unique constructions
• Divergence

26
Lexical choice

• Homonymy/Polysemy bank, run
• Concept gap no corresponding concepts in another
  language go Greek, go Dutch, fen sui, lame duck,

• Coding (Concept ? lexeme mapping) differences
• More distinction in one language e.g., kinship
  vocabulary.
• Different division of conceptual space

27
Discussion

• More examples on concept gaps
• More examples on coding differences
• Does language shape thought? (Sapir-Whorf
  assumption)
• Ex1 Chinese radicals whale, dolphin, bat,
  marriage
• Ex2 kinship, color

28
Choosing the appropriate inflection

• Inflection gender, number, case, tense,
• Ex
• Number Ch-Eng all the concrete nouns
• ch_book ? book, books
• Gender Eng-Fr all the adjectives
• Case Eng-Korean all the arguments
• Tense Ch-Eng all the verbs
• ch_buy ? buy, bought, will buy

29
Inserting spontaneous words

• Function words
• Determiners Ch-Eng
• ch_book ? a book, the book, the books,
  books
• Prepositions Ch-Eng
• ch_November ? in November
• Relative pronouns Ch-Eng
• ch_buy ch_book de ch_person ? the person
  who bought /book/
• Possessive pronouns Ch-Eng
• ch_he ch_raise ch_hand ? He raised his
  hand(s)
• Conjunction Eng-Ch
• Although S1, S2 ? ch_although S1, ch_but S2

30
Inserting spontaneous words (cont)

• Content words
• Dropped argument Ch-Eng
• ch_buy le ma ? Has Subj bought Obj?
• Chinese First name Eng-Ch
• Jiang ? ch_Jiang ch_Zemin
• Abbreviation, Acronyms Ch-Eng
• ch_12 ch_big ? the 12th National Congress of
  the CPC (Communist Party of China)

31
Major challenges

• Getting the right words
• Choosing the correct root form
• Getting the correct inflected form
• Inserting spontaneous words
• Putting the words in the correct order
• Word order SVO vs. SOV,
• Unique construction
• Structural divergence

32
Word order

• SVO, SOV, VSO,
• VP PP ? PP VP
• VP AdvP ? AdvP VP
• Adj N ? N Adj
• NP PP ? PP NP
• NP S ? S NP
• P NP ? NP P

33
Word order (cont)

• Languages you know

34
Unique Constructions

• Overt wh-movement Eng-Ch
• Eng Why do you think that he came yesterday?
• Ch you why think he yesterday come ASP?
• Ch you think he yesterday why come?
• Ba-construction Ch-Eng
• She ba homework finish ASP ? She finished her
  homework.
• He ba wall dig ASP CL hole ? He digged a hole in
  the wall.
• She ba orange peel ASP skin ? She peeled the
  oranges skin.

35
Translation divergences

• Source and target parse trees (dependency trees)
  are not identical.
• Example I like Mary ? S Marta me gusta a mi
  (Mary pleases me)
• More discussion after the break

36
Major approaches
37
How humans do translation?

• Learn a foreign language
• Memorize word translations
• Learn some patterns
• Exercise
• Passive activity read, listen
• Active activity write, speak
• Translation
• Understand the sentence
• Clarify or ask for help (optional)
• Translate the sentence

Training stage
Translation lexicon
Templates, transfer rules
Reinforced learning? Reranking?
Decoding stage
Parsing, semantics analysis?
Interactive MT?
Word-level? Phrase-level? Generate from meaning?
38
What kinds of resources are available to MT?

• Translation lexicon
• Bilingual dictionary
• Templates, transfer rules
• Grammar books
• Parallel data, comparable data
• Thesaurus, WordNet, FrameNet,
• NLP tools tokenizer, morph analyzer, parser,
• ? More resources for major languages, less for
  minor languages.

39
Major approaches

• Transfer-based
• Interlingua
• Example-based (EBMT)
• Statistical MT (SMT)
• Hybrid approach

40
The MT triangle
Meaning
(interlingua)

Synthesis
Analysis
Transfer-based
Phrase-based SMT, EBMT
Word-based SMT, EBMT
word
Word
41
Transfer-based MT

• Analysis, transfer, generation
• Parse the source sentence
• Transform the parse tree with transfer rules
• Translate source words
• Get the target sentence from the tree
• Resources required
• Source parser
• A translation lexicon
• A set of transfer rules
• An example Mary bought a book yesterday.

42
Transfer-based MT (cont)

• Parsing linguistically motivated grammar or
  formal grammar?
• Transfer
• context-free rules? A path on a dependency tree?
• Apply at most one rule at each level?
• How are rules created?
• Translating words word-to-word translation?
• Generation using LM or other additional
  knowledge?
• How to create the needed resources automatically?

43
Interlingua

• For n languages, we need n(n-1) MT systems.
• Interlingua uses a language-independent
  representation.
• Conceptually, Interlingua is elegant we only
  need n analyzers, and n generators.
• Resource needed
• A language-independent representation
• Sophisticated analyzers
• Sophisticated generators

44
Interlingua (cont)

• Questions
• Does language-independent meaning representation
  really exist? If so, what does it look like?
• It requires deep analysis how to get such an
  analyzer e.g., semantic analysis
• It requires non-trivial generation How is that
  done?
• It forces disambiguation at various levels
  lexical, syntactic, semantic, discourse levels.
• It cannot take advantage of similarities between
  a particular language pair.

45
Example-based MT

• Basic idea translate a sentence by using the
  closest match in parallel data.
• First proposed by Nagao (1981).
• Ex
• Training data
• w1 w2 w3 w4 ? w1 w2 w3 w4
• w5 w6 w7 ? w5 w6 w7
• w8 w9 ? w8 w9
• Test sent
• w1 w2 w6 w7 w9 ? w1 w2 w6 w7 w9

46
EMBT (cont)

• Types of EBMT
• Lexical (shallow)
• Morphological / POS analysis
• Parse-tree based (deep)
• Types of data required by EBMT systems
• Parallel text
• Bilingual dictionary
• Thesaurus for computing semantic similarity
• Syntactic parser, dependency parser, etc.

47
EBMT (cont)

• Word alignment using dictionary and heuristics
• ? exact match
• Generalization
• Clusters dates, numbers, colors, shapes, etc.
• Clusters can be built by hand or learned
  automatically.
• Ex
• Exact match 12 players met in Paris last Tuesday
  ?
• 12 Spieler trafen sich
  letzen Dienstag in Paris
• Templates num players met in city time ?
• num Spieler trafen sich
  time in city

48
Statistical MT

• Basic idea learn all the parameters from
  parallel data.
• Major types
• Word-based
• Phrase-based
• Strengths
• Easy to build, and it requires no human knowledge
• Good performance when a large amount of training
  data is available.
• Weaknesses
• How to express linguistic generalization?

49
Comparison of resource requirement
50
Hybrid MT

• Basic idea combine strengths of different
  approaches
• Syntax-based generalization at syntactic level
• Interlingua conceptually elegant
• EBMT memorizing translation of n-grams
  generalization at various level.
• SMT fully automatic using LM optimizing some
  objective functions.
• Types of hybrid HT
• Borrowing concepts/methods
• SMT from EBMT phrase-based SMT Alignment
  templates
• EBMT from SMT automatically learned translation
  lexicon
• Transfer-based from SMT automatically learned
  translation lexicon, transfer rules using LM
• Using two MTs in a pipeline
• Using transfer-based MT as a preprocessor of SMT
• Using multiple MTs in parallel, then adding a
  re-ranker.

51
Evaluation of MT
52
Evaluation

• Unlike many NLP tasks (e.g., tagging, chunking,
  parsing, IE, pronoun resolution), there is no
  single gold standard for MT.
• Human evaluation accuracy, fluency,
• Problem expensive, slow, subjective,
  non-reusable.
• Automatic measures
• Edit distance
• Word error rate (WER), Position-independent WER
  (PER)
• Simple string accuracy (SSA), Generation string
  accuracy (GSA)
• BLEU

53
Edit distance

• The Edit distance (a.k.a. Levenshtein distance)
  is defined as the minimal cost of transforming
  str1 into str2, using three operations
  (substitution, insertion, deletion).
• Use DP and the complexity is O(mn).

54
WER, PER, and SSA

• WER (word error rate) is edit distance, divided
  by Ref.
• PER (position-independent WER) same as WER but
  disregards word ordering
• SSA (Simple string accuracy) 1 - WER
• Previous example
• Sys w1 w2 w3 w4
• Ref w1 w3 w2
• Edit distance 2
• WER2/3
• PER1/3
• SSA1/3

55
Generation string accuracy (GSA)

• Example
• Ref w1 w2 w3 w4
• Sys w2 w3 w4 w1
• Del1, Ins1 ? SSA1/2
• Move1, Del0, Ins0 ? GSA3/4

56
BLEU

• Proposal by Papineni et. al. (2002)
• Most widely used in MT community.
• BLEU is a weighted average of n-gram precision
  (pn) between system output and all references,
  multiplied by a brevity penalty (BP).

57
N-gram precision

• N-gram precision the percent of n-grams in the
  system output that are correct.
• Clipping
• Sys the the the the the the
• Ref the cat sat on the mat
• Unigram precision
• Max_Ref_count the max number of times a ngram
  occurs in any single reference translation.

58
N-gram precision

• i.e. the percent of n-grams in the system output
  that are correct (after clipping).

59
Brevity Penalty

• For each sent si in system output, find closest
  matching reference ri (in terms of length).
• Longer system output is already penalized by the
  n-gram precision measure.

60
An example

• Sys The cat was on the mat
• Ref1 The cat sat on a mat
• Ref2 There was a cat on the mat
• Assuming N3
• p15/6, p23/5, p31/4, BP1 ? BLEU0.50
• What if N4?

61
Summary

• Course overview
• Major challenges in MT
• Choose the right words (root form, inflection,
  spontaneous words)
• Put them in right positions (word order, unique
  constructions, divergences)

62
Summary (cont)

• Major approaches
• Transfer-based MT
• Interlingua
• Example-based MT
• Statistical MT
• Hybrid MT
• Evaluation of MT systems
• Edit distance
• WER, PER, SSA, GSA
• BLEU

63
Next time

• Hw1 is due.
• Word-based SMT
• Read Knights tutorial beforehand

64
Additional slides
65
Translation divergences(based on Bonnie Dorrs
work)

• Thematic divergence I like Mary ?
• S Marta me gusta a mi (Mary pleases me)
• Promotional divergence John usually goes home ?
• S Juan suele ira casa (John tends to go
  home)
• Demotional divergence I like eating ?G Ich esse
  gern (I eat likingly)
• Structural divergence John entered the house ?
• S Juan entro en la casa (John entered in
  the house)

66
Translation divergences (cont)

• Conflational divergence I stabbed John ?
• S Yo le di punaladas a Juan (I gave
  knife-wounds to John)
• Categorial divergence I am hungry ?
• G Ich habe Hunger (I have hunger)
• Lexical divergence John broke into the room ?
• S Juan forzo la entrada al cuarto (John
  forced the entry to the room)

67
Calculating edit distance

• D(0, 0) 0
• D(i, 0) delCost i
• D(0, j) insCost j
• D(i1, j1)
• min( D(i,j) sub,
• D(i1, j) insCost,
• D(i, j1) delCost)
• sub 0 if str1i1str2j1
• subCost otherwise

68
An example

• Sys w1 w2 w3 w4
• Ref w1 w3 w2
• All three costs are 1.
• Edit distance2
