Title: Injection Molding Technique


1
(No Transcript)
2
Injection Molding
  • It is a fast process and is used to produce large
    numbers of identical items from high precision
    engineering components to disposable consumer
    goods. injection molding process produces large
    numbers of parts of high quality with great
    accuracy, very quickly.

3
How Does Injection Molding Work?
4
Injection molding is the most commonly used
manufacturing process for the fabrication of
plastic parts. A wide style of product are
factory-made using injection molding, that vary
greatly in their size, complexity, and
application. The injection molding method needs
the utilization of associate use of an injection
molding machine, raw plastic material, and a
mold. The plastic is melted within the injection
molding machine then injected into the mold,
wherever it cools and solidifies into the
ultimate half. The steps during this method are
described in greater detail in the next section.
5
Injection molding Process Cycle
6
The most common materials used in the process of
molding include
  • Acrylonitrile-Butadiene-Styrene ABS
  • Nylon PA
  • Polycarbonate PC
  • Polypropylene PP

7
Arte Tooling
  • The parts to be injection molded are carefully
    designed so as to effectively facilitate the
    injection mold making process. Moreover, the
    material used for the part, the desired shape and
    features of the part, and the properties of the
    molding machine are taken into consideration by
    the engineers.
  • Arte tooling machinery is versatile enough that
    it can carry out injection molding in China
    facilitated by an assortment of design
    considerations and possibilities.

8
(No Transcript)
9
(No Transcript)
