Direct Broadcasting Satellite

1
http//www.horizon-teleports.com
2
GSM Backhauling

• Horizon Teleports provides GSM backhaul solutions
  to extend cellular coverage by creating a network
  backbone, which can also be used as a backup in
  case of terrestrial networks failures. This is
  particularly useful when terrestrial capacity is
  either not available or too costly a solution to
  implement. In such cases terrestrial networks can
  be bypassed using Horizon Teleports GSM Backhaul
  service, noted for its flexibility, scalability
  and reliability, allowing operators to reach more
  customers geographically, irrespective of the
  protocol used on their network. Connected
  directly with redundant fiber to Equinix Munich,
  and any POP around the world can be inter
  connected.

3
Teleport Facilities

• Horizon Teleports is a state-of-the-art Teleport
  located in Munich, Germany, and can provide a
  wide range of satellite and Teleport services.
  Due to its geographic location it has access to
  satellites located from 55 degrees west to 78
  degrees East, serving the most demanding
  telecommunication markets of Middle East, Africa,
  Europe and Asia.
• An experienced engineering team supports our
  customers with a 24/7 support hotline, who manage
  and maintain the following infrastructure

4
Broadband Services

• Horizon Teleport delivers broadband Internet and
  communication solutions to Telcos, Governments
  and large Institutions across the entire spectrum
  of broadband applications. This is accomplished
  through VNO services, which enable customers to
  manage their own networks through dedicated hub
  based solutions in a proprietary manner so that
  they may benefit from the flexibility of sharing
  and allocating their bandwidth and space segment
  resources between sites, resulting in savings in
  time and money.

5
IP Trunking

• IP transit can be used for direct end-to-end
  Internet backbone access in locations where
  terrestrial infrastructures are limited. The
  service can also be used as back-up to fibre
  optics lines.
• Horizon Teleports offers a wide range of IP
  Transit services, all backed with the latest
  State-of-the-Art Technology. IP Transit service
  comprises up- and downlink from our Teleport,
  provision of satellite capacity and broadband
  Internet access using well-established satellite
  technologies like DVB-S2, SCPC and SCPC/SCPC.
  Bandwidth is available from 64 kbps up to 155
  Mbps. Additionally secure VPN (Virtual Private
  Network) tunneling or TCP acceleration can be
  realized.
• Applications for IP transit services are data,
  VoIP (Voice over IP), video, media and digital
  TV.
• Our customers are Telcos, Internet Service
  Providers (ISPs), Corporate customers, Public
  Protection and Disaster Relief (PPDR),
  Governmental Organizations and TV Broadcasters in
  the covered areas.
• In order to ensure cost-effectiveness for our
  customers we calculate reliable satellite
  linkbudgets with best possible modulation and use
  high-quality equipment.

6
TV Contribution

• A contribution link permits broadcasters to
  transport video programming by satellite from a
  remote source such as a Satellite news gathering
  (SNG) unit to a broadcaster's studio or from a
  studio to our Teleport / uplink Centre. With the
  advantage of its access to a number of
  satellites, Horizon Teleports can retransmit
  programs from any part of the region.

7
TV Distribution

• Perhaps the best way of distributing TV and radio
  programming to reach close to 100 of a
  population in any geographic area, irrespective
  of ground infrastructures, is through satellites.
• Broadcasting companies can reach a large audience
  without having to worry about local
  infrastructures. A video signal is transmitted to
  our Teleport/uplink center and from the teleport
  video/audio signals are compressed using MPEG
  codec and transmitted to satellites as a digital
  video-broadcasting (DVB) signal. Horizon
  Teleports can broadcast DVB signals via satellite
  to an unlimited number of viewers in any coverage
  area.

8
ABOUT US

• Horizon Teleports is a world class, totally
  redundant and secure teleport facility operated
  from Munich, Germany.
• At the core of Horizon Teleports'
  state-of-the-art infrastructure, are 16 high-end,
  technically sophisticated antennas ranging in
  sizes from 2.4 meters up to 9.4 meters and a top
  of the line 24/7 Network Operations Center,
  enabling worldwide communication for business and
  government entities across the globe.
• The teleport uplinks to 8 satellites across C-
  and Ku-band and provides access to multiple
  satellites in the eastern and western sky.
  Horizon Teleports offers satellite communication
  services across Asia, Europe, the Middle East,
  Africa and the Americas.
• Through our redundant internet backbone and
  stable satellite network Horizon Teleports is
  able to provide to the costumer most effective
  communications solutions via satellite.
• At Horizon Teleports you get fully managed
  services and solid technical consultancy tailored
  to your needs.

9
Contact Us

• Horizon Teleports GmbHMarketing and
  SalesDegernpoint K7 85368 Moosburg a.d. Isar
  Germany
• 49-8761-72080-0
