anonymity

1
Anonymity on the Internet
2
Types of Anonymity

• Pseudonymity
• Susceptible to subpoenas
• Sender
• Receiver / observer cant identify sender
• Receiver
• Observer cant identify receiver
• Sender-receiver
• Observer cant identify that communication has
  been sent

3
Uses of Anonymity

• Positive
• Free speech for political claims as well as
  non-political comments
• engage in whistle-blowing
• conduct commercial transactions
• freedom from detection, retribution, and
  embarrassment
• New York Times Co. vs. Sullivan, 1964
• "an author's decision to remain anonymous...is
  an aspect of the freedom of speech protected by
  the First Amendment"

4
Uses of Anonymity

• Negative
• Spam
• DoS -
• Illegal activity anonymous bribery, copyright
  infringement, harassment, financial scams,
  disclosure of trade secrets

5
Assumptions

• Weak attacker
• Eavesdrops on first and last hop
• Can introduce messages here
• Strong attacker
• Eavesdrops on all links
• Can introduce messages anywhere
• Attacker has finite time, computing power
• Multiple users

6
Types of Attackers

• Local eavesdropper
• Observes inbound and outbound messages on users
  computer
• Administrator
• Operator or group of operators of anonymizing
  systems attempting to foil their own system
• Remote attack
• Observation at the remote end by eavesdropper or
  attack by the remote host

7
Attacks

• Timing Attack, Volume Attack
• Watches shape of traffic instead of content
• Flooding Attack
• With batch size n, attacker sends n-1 messages
• Usage Pattern Attack
• Consistent usage patterns leads to predictability

8
Levels of Anonymity
Absolute Privacy
Beyond Suspicion
Probable Innocence
Possible Innocence
Exposed
Provably Exposed

• Beyond Suspicion
• Attacker can see evidence of a sent message, but
  the sender appears no more likely to be the
  originator than any other potential sender in the
  system
• Probable Innocence
• The sender is more likely the originator than any
  other potential sender, but there is equal
  likelihood the sender is not the originator
• Possible Innocence
• The sender appears more likely to be the
  originator than to not be the originator, but
  theres still a non-trivial probability that the
  originator is someone else

9
Capabilities

• Latency, Bandwidth, Anonymity
• Pick 2
• Human element
• Repetitive usage patterns make attacks easier
• Pizza effect

10
Proxy Anonymizers

• Use trusted centralized servers
• Anonymous remailers - Helsingius
• Anonymizer.com
• Hides IP address - NAT
• Users not anonymous to proxy server
• Susceptible to traffic analysis

11
Mixes

• Source routing chosen by user
• Shuffles order of packets
• Mix cascade consists of several mixes under
  separate operators
• Encrypted for each mix in the path
• Processes packets in batches
• Used to counter traffic analysis

12
Mixes
Ai Next Hop Address
Ci Message encrypted with public key of Mix i
S Destination Host address
M Original message
4.
Mix 1
Mix 2
1.
3.
2.
Mix 4
Mix 3
A1, C1(A3, C3(A2, C2(S, M, r2), r3), r1)
A2, C2(S, M, r2)
1.
3.
A3, C3(A2, C2(S, M, r2), r3)
S, M
2.
4.
13
Mixes

• Fine for non real-time (email)
• Not sufficient for VoIP, video, web
• Mix waits to accumulate inputs to process as a
  batch (especially slow for low traffic)

14
Enhancements

• Messages all the same length
• Buffers messages until several can be sent at
  once
• Dummy messages inserted
• Between mixes
• Between mixes and user
• Balance end to end throughput with anonymity
• Duration to wait for mixes to accumulate traffic
• Percentage of dummy traffic

15
P5

• Decentralized
• Harder to attack
• Allows choice of tradeoff between anonymity /
  throughput
• Encrypted with public key of each node in route
• Nodes change packet order
• Fixed message size
• Users have broadcast map and route map
• Noise packets counter statistical traffic analysis

16
User A
User B
Hash of Users public key provides choice of
groups.
User A can send an anonymous message to User B
via group /0, 1/1, 111/3, etc
01/2 is a subset of /0 more efficient but less
anonymous
User A can route messages between 00/2 and 01/2
Broadcast hierarchy independent of network
topology
17
P5

• Within a channel, P5 functions as a mix cascade
• Between channels, P5 provides greater anonymity
  per bandwidth
• For 8192 users, 1.5 Mbps provides 200Kbps with
  40 loss
• Resistant to Timing/Volume and DoS attacks
• Susceptible to Flood Attack (Mob Attack)
• Users channel is flooded, prompting him to
  reveal more of his mask to gain efficiency,
  thereby reducing his anonymity

18
Conclusion

• Costly to be anonymous (Use Anonymous VPN
  Service)
• Tradeoff with throughput
• Can not be completely anonymous anyway
• No protection from monitoring usage patterns
• Aside from this, practical anonymity can be
  achieved
