Data Logger

1
Data Logger

• ESD-India Reputed temperature measurement
  control instruments Manufacturer Company in
  India.

2

• Electronics Systems Devices (ESD)  manufacture U
  SB Pen Drive Data Logger. These Data Logger
  is pen drive based on Data Logging unit, just
  plug in the Pen Drive and leave the rest to the
  Get data stored in file compatible with Microsoft
  Excel. You can store records as much as 99,99,999
  in one pen drive.
• Our product range include Temperature
  Controllers ,Indicators ,Transmitters , Process
  Scanners, Data Loggers, Alarm Annunciators, Signal
  Isolators, Portable Calibrator Simulators.

3

• Features
• Proven trouble free field performance
• Highly compact
• Dust and vermin proof enclosure with epoxy power
  coating
• LED display gives better readability at long
  range
• Fast response time
• Available in different DIN std. cutouts
• Designed for Pt-100,Thermocouples and 4-20 mA
  input
• Maximum MTBF and minimum MTTR
• Wide supply variation and environmental band

4

• Features
• Designed for Pt-100, Thermocouples and 4 - 20 mA
  input
• Maximum MTBF and minimum MTTR
• Feather touch push button
• Individual channel Sensor error compensation USB
  Interface
• Applications
• The temperature indicator can be used in almost
  any industry, laboratory etc. where accurate
  temperature indication and continous data logging
  is required.

5

• Specifications
• Max number of records stored gtgt Upto 99,99,999
  (based on the Pen Drive selected)
• Output File gtgt File opens up in Microsoft Excel
  (All versions)
• Data Logging Interval gtgtFrom 1 min to 4 hrs
  (Programmable)
• Sizesgtgt Available in various sizes based on
  functionality requirements
• InputsgtgtPT100, Thermocouples, 4-20mA, Voltage
  Inputs, Digital Inputs (As per order)
• Number of channelsgtgt1, 4, 8, 16, 32 points
  available
• Time KeepinggtgtNon Volatile Time Keeping RAM with
  10 year data retention
• CustomizationAvailable in Indicator, Controller
  modes

6
ESD Address       Electronics Systems
Devices,       ESD House, 55 Hadapsar Industrial
Estate,       Pune 411013, Maharashtra,
India.  Website http//esd-india.com
