• Electronica Mechatronics ( I) Pvt. Ltd. , known
  in Indian Machine Tool Market as EMS, was
  established in 1980 in Pune, India.
• The company is engaged in designing and
  manufacturing encoders for precise position and
  motion control.
• Having Customer focus and team work as core
  values, EMS has innovated and continually
  improved their products to offer an optimal
  solutions to changing markets.

www.electronicaems.com
3
Milestones

• What started as a passionate journey of three
  entreprenuers has now become a leading encoder
  and metrology company supplying across the
  globe.Our journey so far has been testimony to
  our team efforts, relentless pursuit of quality
  and value based leadership. Day by day this
  journey becomes more exciting and fulfilling
  benefitting all concerned.

www.electronicaems.com
4
Products and Services
www.electronicaems.com
5
Position Motion Control

• Optical Linear Encoders
• Magnetic Linear Encoders
• Magnetic Rotary Encoders
• Digital Readout Systems
• DRO Kits

www.electronicaems.com
6
Optical Linear Encoders

• GS212
• GS212 is linear bearing scale based on optical
  principle. It offers resolutions down to 0.1,
  with repeat accuracy of one count. It possesses
  IP54 rating.
• This compact design helps in easy mounting in
  congested spaces. Offering lengths from 70mm to
  2040mm, this scale is a preferred choice for high
  accuracy machining and metrology applications.

www.electronicaems.com
7
Magnetic Linear Encoders

• Magnetic Tape
• Magnetic Tapes consists of an extruded plastic
  impregnated with Barium Ferrite glued to a
  stainless steel tape using a special type of
  glue. This stainless steel tape provides the
  rigidity to the magnetic tape. The special glue
  makes sure that the thermal expansion coefficient
  of the glued tape is same as stainless steel tape.

www.electronicaems.com
8
Magnetic Linear Encoders

• Magna Slim
• Magna Slim is a contact less magnetic measurement
  system, easy to install and highly resistant to
  oil, dust, dirt and vibrations, making it
  suitable for use under harshest of conditions.

www.electronicaems.com
9
Magnetic Linear Encoders

• Press Brake Scale
• The Press Brake Scale by Electronica Mechatronic
  Systems is fully guided environmentally sealed
  scale with high mounting tolerance. The high
  performance encoder system provides resolution
  from 1 - 10 m and accuracy up to 10 m/m.

www.electronicaems.com
10
Magnetic Rotary Encoders

• MDB28
• MDB28 magnetic rotary encoder module has a
  precision sensor having an integrated Hall
  element for scanning a permanent Dipole magnet.
• MDB28 module is a 28mm PCB assembly which has a
  wide operating voltage range suitable for many
  applications

www.electronicaems.com
11
Magnetic Rotary Encoders

• MDE22
• MDE22 is a magnetic rotary enclosed encoder with
  a shaft. It has a precision sensor having an
  integrated Hall element for scanning a permanent
  Dipole magnet. The encoder can give Absolute as
  well as incremental outputs up to 14 bits per
  rotation.
• MDE22 enclosure is designed like an enclosed
  shaft encoders allowing for very easy
  installation in applications. Its IP68 robust
  design makes it ideal for use in harsh
  environments.

www.electronicaems.com
12
Digital Readout Systems

• MB100
• MB100 DRO is 1 Axis Digital Measuring System
  which replaces old and worn outs ruler
  measurement guides, making it suitable for use in
  table saw, wall saw, pillar drills etc..
• MB100 has a long battery life and Magnetic tape
  comes with self-adhesive back tape which makes it
  durable and easy to install.

www.electronicaems.com
13
Digital Readout Systems

• EL360A
• The Press Brake Scale by Electronica Mechatronic
  Systems is fully guided environmentally sealed
  scale with high mounting tolerance. The high
  performance encoder system provides resolution
  from 1 - 10 m and accuracy up to 10 m/m.

www.electronicaems.com
14
DRO Kits

• DRO Mill Kits
• DRO Lathe Kits
• DRO Grinder Kits

www.electronicaems.com
