MPI Magnet - Sorting System

1
MPI Magnet Sorting system

• Products that remove ferrous or non-ferrous
  metals from your sorting systems

2
Separation Roll

• MPIs Magnetic Head Pulley Separation Roll
  Magnets are designed to remove both large and
  small ferrous tramp iron contaminants from
  product streams in belt conveyor systems.
  SR-series separators provide a continuous, 24/7
  automatic removal of tramp iron from the
  materials flow.

3
Drum Separator

• MPIs Magnetic Drum Separators and Housing are
  designed to provide trouble-free automatic
  extraction of tramp iron from heavy flows of
  large size and abrasive materials such as coal,
  aggregates, ores, sugarcane, wheat etc.

4
Suspended Magnets

• MPIs Suspended Permanent Magnet Cross Belt
  Separators produce the most effective removal of
  unwanted tramp metal from heavy burden depths of
  material being conveyed on fast- moving conveyor
  belts. They are ideal for separating tramp metal
  from wet or dry and fine or coarse conveyed
  materials in large or small volumes. Tramp metal
  extraction from product streams protects
  processing machinery, prevents fire or explosions
  caused by sparks, and improves product quality.
  The lower profile design of all CBS allows for
  installations where space is limited.

5
Eddy Current

• MPIs proven eddy current technology ensures
  higher separation rates. State-of-the-art system
  controls and features combined with technological
  advances result in improved nonferrous metal
  removal, particularly when trying to separate
  smaller particles such as aluminum and brass from
  non-conductive waste streams. Eddy Current
  Separators (ECS) can be used wherever nonferrous
  metals have to be recovered or separated. Common
  applications include
• Trash and Municipal Waste Processing
• Auto Shredding
• Beverage Can Sorting
• Glass and Foundry Sand Recovery
• Window Recycling
• Plastic Recycling
• Scrap Wood Recycling

6
