Inclination Sensor, Tilt Sensor Manufacturer

1
2019
VIGOR TECHNOLOGY
Established in 2001, Shanghai Vigor Technology
Development Co., Ltd. is one of the earliest
professional manufacturers engaged in attitude,
position and orientation measurement.
2
CONTENT
1
Company History Introduction
2
Product Service Promotion
3
Enterprise Development Plan
3
PART 01
Company History Introduction
4
History Introduction
5
History Introduction
Shanghai Vigor Technology Development Co., Ltd.
is a professional attitude measurement and
monitoring enterprise with independent
intellectual property rights, specialized in
sensor application technology solutions, test
systems and services development, production and
sales. Based on the past 20 years of commitment
and long-term accumulation of value and corporate
culture, it has independently developed
inclination sensors, data transmission equipment,
data acquisition equipment, data analysis,
automatic measurement (measuring and mapping)
systems, high-precision motion control and
intelligent control. The system can provide
customers with a value-oriented, industry-wide
complete solution. Meanwhile, Vigor Technology is
also a technology-oriented and service-oriented
sci-tech enterprise. At present, our main market
areas are military, aerospace, construction
equipment, automotive, railway, civil
engineering. We not only offer highly competitive
products, but also combines the expertise of
customers in different fields and our sensor
expertise to provide customers with
comprehensive, high quality, professional and
forward-looking technologies, products and
services.
6
Development History of Vigor Technology
R D, Production and Sales of SST series
inclinometers
Foundation of Wuhan Branch Office Focus on
monitoring of civil engineering project and
intelligent tunnel monitoring system
Focus on intelligent tunnel monitoring system
2001
2012
2018
Foundation of Vigor Technology by General Manager
Mr. Zhan
Attitude monitoring, inertial navigation system
application solution
Foundation of Changsha Branch Office Focus on
intelligent system integration technology of
construction machinery and equipment
7
PART 02
Product Service Promotion
8
Core Technologies of Vigor Technology
Inertial Navigation Technology
Intelligent Control Technology
9
Vigor Technology Products
Static Inclinometer
In-place Tiltmeter
Inertial Navigation System
3D Road Mapping System
Dynamic Inclinometer
Automated Online Monitoring System
Settlement Sensor
Intelligent Control System
10
Product Application Industry
11
Product Applications
Tower Health Monitoring
12
Product Applications
Inclination Monitoring of Construction Machinery
Bucket height calculation formula H'' H-
(L2Xsin?2-L1Xsin?1) H means the height of big arm
end above the ground L2 stands for the fixed
length of small arm L1 stands for the fixed
length of big arm
13
Product Applications
Inclination Monitoring of Construction Machinery
14
Product Applications
Civil Engineering
Tunnel monitoring system Bridge
health monitoring system Engineering foundation
pit monitoring system Dam, high wall and
other monitoring
15
Product Applications
Military Field
. The tank optical aiming system requires
inclinometer, and Vigor Technology has provided
various types of inclinometers for the Chinese
military. . Static inclination monitoring (also
known as static tilt sensor on the market). .
Dynamic inclination monitoring (based on
gyroscopes and accelerometers). . Quasi-dynamic
tilt sensor (new concept, but it proved to be
very helpful in some applications). . Artillery
trunnion sensor, and any tank needs a dynamic
inclinometer.
16
Product Applications
Solar Energy Field
The above is a solar project in South Africa
which is one of the application cases of Vigor
Technology. In Linde and Drumberg, Vigor
Technology cooperated with local customers
Scatec Solar, and Weber Hydraulics which is an
engineering enterprise. Products used in the two
solar power plants Vigor SST20 Inclinometer -
output signal 4 20mA 90 measurement range
0.07 accuracy _at_ 15 50 C.
17
Product Applications
Wind Power Generation
18
Aerospace
Product Applications
. Application of SST0442 in ground satellite
attitude measurement. . Application of static and
dynamic tilt sensors in radar systems and radar
leveling systems. . Application of dynamic tilt
sensor in UAV attitude measurement and control
system. . Application of GNSS inertial
navigation system in missile.
19
Product Applications
Railway Transportation Industry
Train Control System The system uses the
SST800 dual-axis tilt sensor to measure the
acceleration of forward and side direction.
CBTC System of Metro Line CBTC is similar to the
''Train Control System'', adopting wireless
communication technology. Train Comfort
Measurement Comfort is important to passengers
when the train is traveling at high speeds. Vigor
Technology's SSA100 tilt sensor is used for such
monitoring. Pantograph Control When the train
is running, the pantograph attitude needs to be
closed-loop controlled. The SST800 dynamic tilt
sensor (based on gyroscopes and accelerometers)
is perfect for monitoring pantograph attitude
information.
20
Product Applications
Automobile Attitude Monitoring
Our SST510 has been widely used in China for
automobile attitude monitoring.
. When the vehicle goes uphill Normally, the
SST510 dynamic tilt sensor is mounted on the
standard plane of the chassis to measure the tilt
angle of the vehicle in the direction of travel
(ie the road gradient), so that the car can get
the correct speed and output power to prevent
engine failures caused by human judgment or
operational errors. . When the vehicle goes
downhill It is also possible to adjust the speed
in time according to the situation and improve
driving comfort.
21
Sales Network of Vigor Technology
01. 15 market share
02. 73 market share Mainly in mainland
China
03. 6 market share
04. 4 market share
05. 2 market share
22
Partners of Vigor Technology
23
Professional Technical Ability
. Design and manufacture sensor based on system
engineering . Continuously upgrade and optimize
products based on the premise of intelligent
applications . Reliability-centric technology
upgrades and developments . Technology-driven,
cost-effective OEM and ODM of mid-to-high end,
closely integrated with practical engineering
applications . Products and systems
(measurement, mapping and control systems)
promote and develop mutually.
24
Intelligent Tunnel Monitoring
25
Intelligent Tunnel Monitoring
Rock drilling rig
Second lining trolley
Wet spraying trolley
26
PART 03
Enterprise Development Plan
27
Corporate Strategic Plan
2018
2019
2020
28
2019
THANKS
Shanghai Vigor Technology Development Co., Ltd.
vigordigital.com
