Title: Introduction to TCPIP


1
COURSE
LECTURE 3
COMS 525 TCPIP
TOPIC
TRANSMISSION CONTROL PROTOCOL / INTERNET
PROTOCOL(TCP/IP)
K. PALANIVEL Systems Analyst, Computer
Centre Pondicherry University, Puducherry
605014.
2
Topics to be covered
  • TCPIP
  • Layered Architecture
  • Functions
  • Layered Communications
  • Different Views of Layers
  • Encapsulation and Demultiplexing
  • Summary

3
Why TCP/IP is so popular?
  • TCP/IP was developed very early
  • Technologies were widely discussed and circulated
    in documents called Request for Comments (RFC)
    free of charge
  • Supported by UNIX operating system

4
TCP/IP Model
  • Because TCP/IP was developed earlier than the OSI
    7-layer mode, it does not have 7 layers but only
    4 layers

OSI 7-layer
TCP/IP Protocol Suite
FTP, SMTP, Telnet, HTTP,
TCP, UDP
IP, ARP, ICMP
Network Interface
5
TCP/IP Model
Application Layer Application programs using the
network
Transport Layer (TCP/UDP) Management of
end-to-end message transmission, error detection
and error correction
Network Layer (IP) Handling of datagrams
routing and congestion
Data Link Layer Management of cost effective and
reliable data delivery, access to physical
networks
Physical Layer Physical Media
6
Application Layer Protocols
  • Application layer protocols define the rules when
    implementing specific network applications
  • Rely on the underlying layers to provide accurate
    and efficient data delivery
  • Typical protocols
  • FTP File Transfer Protocol
  • For file transfer
  • Telnet Remote terminal protocol
  • For remote login on any other computer on the
    network
  • SMTP Simple Mail Transfer Protocol
  • For mail transfer
  • HTTP Hypertext Transfer Protocol
  • For Web browsing

7
Transport Layer Protocols
  • TCP/IP is built on connectionless technology,
    each datagram finds its own way to its
    destination
  • Transport Layer protocols define the rules of
  • Dividing a chunk of data into segments
  • Reassemble segments into the original chunk
  • Typical protocols
  • TCP Transmission Control Protocol
  • Provide further the functions such as reordering
    and data resend
  • UDP User Datagram Service
  • Use when the message to be sent fit exactly into
    a datagram
  • Use also when a more simplified data format is
    required

8
Network Layer Protocols
  • Network layer protocols define the rules of how
    to find the routes for a packet to the
    destination
  • It only gives best effort delivery. Packets can
    be delayed, corrupted, lost, duplicated,
    out-of-order
  • Typical protocols
  • IP Internet Protocol
  • Provide packet delivery
  • ARP Address Resolution Protocol
  • Define the procedures of network address / MAC
    address translation
  • ICMP Internet Control Message Protocol
  • Define the procedures of error message transfer

9
Encapsulation and Demultiplexing
10
TCP/IP Protocol Suite
  • The TCP/IP protocol suite is the protocol
    architecture of the Internet
  • The TCP/IP suite has four layers Application,
    Transport, Network, and Data Link Layer
  • End systems (hosts) implement all four layers.
    Gateways (Routers) only have the bottom two
    layers.

11
Functions of the Layers
  • Data Link Layer
  • Service Reliable transfer of frames over a
    link Media Access Control on a LAN
  • Functions Framing, media access control, error
    checking
  • Network Layer
  • Service Move packets from source host to
    destination host
  • Functions Routing, addressing
  • Transport Layer
  • Service Delivery of data between hosts
  • Functions Connection establishment/termination,
    error control, flow control
  • Application Layer
  • Service Application specific (delivery of
    email, retrieval of HTML documents, reliable
    transfer of file)
  • Functions Application specific

12
TCP/IP Suite and OSI Reference Model
The TCP/IP protocol stack does not define the
lower layers of a complete protocol stack
13
Assignment of Protocols to Layers
14
Layered Communications
  • An entity of a particular layer can only
    communicate with
  • a peer layer entity using a common protocol (Peer
    Protocol)
  • adjacent layers to provide services and to
    receive services

15
Layered Communications
  • A layer N1 entity sees the lower layers only as
    a service provider

N1 LayerEntity
N1 LayerEntity
Service Provider
16
Service Access Points
  • A service user accesses services of the service
    provider at Service Access Points (SAPs)
  • A SAP has an address that uniquely identifies
    where the service can be accessed

17
Exchange of Data
  • The unit of data send between peer entities is
    called a Protocol Data Unit (PDU)
  • For now, let us think of a PDU as a single packet
  • Scenario Layer-N at A sends a layer-N PDU to
    layer-N at B
  • What actually happens
  • As layer-N passes the PDU to one the SAPs at
    layer-N-1
  • Layer-N-1 entity at A constructs its own
    (layer-N-1) PDU which it sends to the layer-N-1
    entity at B
  • PDU at layer-N-1 layer-N-1 Header layer N
    PDU

A
B
18
Exchange of Data
Exchange of Data
A
B
19
Layers in the Example
20
Layers in the Example
21
Layers and Services
  • Service provided by TCP to HTTP
  • reliable transmission of data over a logical
    connection
  • Service provided by IP to TCP
  • unreliable transmission of IP datagrams across an
    IP network
  • Service provided by Ethernet to IP
  • transmission of a frame across an Ethernet
    segment
  • Other services
  • DNS translation between domain names and IP
    addresses
  • ARP Translation between IP addresses and MAC
    addresses

22
Encapsulation and Demultiplexing
23
Encapsulation and Demultiplexing
  • As data is moving down the protocol stack, each
    protocol is adding layer-specific control
    information

24
Encapsulation and Demultiplexing
  • Let us look in detail at the Ethernet frame
    between Argon and the Router, which contains the
    TCP connection request to Neon.
  • This is the frame in hexadecimal notation.
  • 00e0 f923 a820 00a0 2471 e444 0800 4500 002c
    9d08 4000 8006 8bff 808f 8990 808f 4715 065b 0050
    0009 465b 0000 0000 6002 2000 598e 0000 0204 05b4

25
Parsing the information in the frame
26
Encapsulation and Demultiplexing Ethernet Header
27
Encapsulation and Demultiplexing Ethernet Header
28
Encapsulation and Demultiplexing IP Header
29
Encapsulation and Demultiplexing Ethernet Header
30
Encapsulation and Demultiplexing TCP Header
Option maximum segment size
31
Encapsulation and Demultiplexing Ethernet Header
32
Encapsulation and Demultiplexing Application Data
33
Different Views of Networking
34
Different Views of Networking
  • Different Layers of the protocol stack have a
    different view of the network. This is HTTPs and
    TCPs view of the network.

35
Network View of IP Protocol
36
Network View of Ethernet
  • Ethernets view of the network

37
  • Questions?
