Different types of electrical switches and their
uses

• Electrical counter

2
Different types of electrical switches and their
uses

• Electric switches are electromechanical gadgets
  that are utilized in electrical circuits to
  control electricity, sign controllers of the
  whereabouts of machine parts and workpieces,
  control gadgets manually, manage the lighting,
  and so on. Electrical switches come in loads of
  styles and can be operated by hand, foot, level,
  or objects. Switches can be simply on-off types
  or can have multiple designs and positions that,
  for instance, can manipulate the rate of a
  multi-speed fan. Switch operators can be in
  diverse shapes and sizes, like, toggles or
  buttons, and come in various colors.

3
Types of Electrical Switches

• There are many types of electrical switches such
  as foot-switch, pushbutton, LED dimmer switch. As
  mentioned above they come in different shapes,
  sizes, colors. Not only that but different
  switches have different purposes.
• Foot Switches
• Level Switches
• Limit Switches
• Magnetic Switches
• LED dimmer switch
• Pressure Switches
• Pull Chain Switches

4
Foot Switches

• Foot Switches are electro-mechanical devices used
  to manipulate electricity in an electrical
  circuit by means of foot strain. They are
  frequently used on machines in which an operator
  needs his or her hand to stabilize a workpiece.
  Its key specifications include the number of
  pedals, switching feature, voltage score, and
  current rating. Footswitches are used in lots of
  press applications in which hand controls cant
  be used to actuate a cycle. They also are
  normally used in medical equipment and office
  machines.

5
Level Switches

• Level Switches are electro-mechanical gadgets
  used to detect the extent of liquids, powders, or
  solids. They are mounted in tanks, hoppers, or
  bins, and can give output to a control system. In
  a few instances, they may be used to actuate a
  tool directly, along with level switches used in
  residential pumps. Key specifications consist of
  measured media, output type, switch type,
  voltage, and current scores. Level switches are
  used drastically in the technique industries to
  observe tank and hopper levels. They are used in
  normal appliances also.

6
Limit Switches

• Limit Switches are electro-mechanical gadgets
  designed to sense motion and position routinely
  and offer output alerts to a controller. They are
  accessible as bare switches, or in rugged
  enclosures meant for the tough environment. Key
  specifications encompass actuator type, voltage,
  and current score. A type of actuator sorts from
  rods to whiskers guarantees that any component or
  workpieces can be sensed with the help of a limit
  switch. Limit switches are used in lots of common
  customer machines which includes washing
  machines. In their ruggedized shape, they may be
  used in many types of manufacturing centers
  inclusive of steel turbines and paper plants.

7
Magnetic Switches

• Magnetic Switches, also called reed switches, are
  a form of an electric switch in which the switch
  closure mechanism is operated through the
  presence or absence of a magnetic field. In a
  regular design, the switch contacts are usually
  open while a magnetic field isnt in close
  proximity to the switch. One application for
  magnetic switches is to control the opening and
  closing of doorways and windows as part of a
  safety system.

8
LED dimmer switch

• A LED Dimmer Switch is used to manipulate or
  alternate the speed of a fan or once in a while
  to exchange the depth of light among bright and
  dim. Earlier, the regulators used to rotate in
  steps, each step represented a particular level
  of fan speed, but the LED Dimmer switch regulator
  lets you rotate it smoothly without any steps or
  levels.

9
Pressure Switches

• Pressure Switches are electro-mechanical gadgets
  used to feel fluid stress and provide output
  indicators to a controller. They frequently use a
  diaphragm because of the sensing means. Key
  specifications encompass the stress type, media
  measured, the material of diaphragm, connection
  of the pressure, minimum and maximum operating
  pressures, and switch current. Pressure switches
  are used to keep the pressure under the limits in
  the lubrication system wherein over-pressure or
  below-pressure conditions can bring about harm to
  the machine or equipment.

10
Pull Chain Switches

• Pull Chain Switches are electro-mechanical
  appliances that are hand-operated and used to
  turn a circuit on and off. Their most usual
  utility is in lighting fixtures in which they may
  be used to turn lamps on or off. Pull Rope
  Switches are used as emergency prevent devices
  like in trains. Key specifications include
  switching characteristics, voltage, and current
  scores, and also numerous functions particular to
  e-stop applications such as detection of the
  broken-cable.
