PCB Manufacturer

1
WELCOME TO pcbquick.com
2
LED Strip Application
Indoor Decoration Material PI Board Thickness
0.15-0.22mm Copper Thickness 1/1 Cover Film
white Silkscreen Color black Surface Technics
OSP Min Holes 0.2mm Min Line space and width
6/6mil
Bridge Material PI Board Thickness
0.15-0.22mm Copper Thickness 1/1 Cover Film
white Silkscreen Color black Surface Technics
OSP Min Holes 0.2mm Min Line space and width
6/6mil
3
Color Warm white WARM WHITE Voltage
DC24V Length 5M/ROLL LED Type 3014 40LED/M CCT
2800-3200K Power 40.8W(MAX) Authentication CE /
RoHS / ETL
LED Strip Application
LED Strip
4
LED Lighting Application
T8 LED Lighting PCB Material Aluminium,FR4,CEM Bo
ard Thickness 1.0-2.0mm  Copper Thickness
18-35um Thermal Conductivity1.0-2.0w/mk  Withstan
d Voltage1.5-3.5KV/AC Soldermask Color
White Silkscreen Color Black Surface Technics
OSP or HAL-Free
Street LED Lighting PCB Material Aluminium Board
Thickness 1.0-2.0mm  Copper Thickness
18-35um Thermal Conductivity1.0-4.0w/mk  Withstan
d Voltage1.5-3.5KV/AC Soldermask Color White or
Black Silkscreen Color Black or White Surface
Technics OSP or HAL-Free
5
LED Lighting Application
Car LED Lighting PCB Material Aluminium Board
Thickness 1.0-2.0mm  Copper Thickness
18-35um Thermal Conductivity1.0-4.0w/mk  Withstan
d Voltage1.5-3.5KV/AC Soldermask Color White or
Black Silkscreen Color Black or White Surface
Technics OSP or HAL-Free
High Power LED PCB Material 2layer
Aluminium Board Thickness 1.0-2.0mm  Copper
Thickness 18-35um Thermal Conductivity1.0-4.0w/m
k  Withstand Voltage1.5-3.5KV/AC Soldermask
Color White or Black Silkscreen Color Black or
White Surface Technics OSP or HAL-Free
6
LED has the advantage of energy saving and
environmental protection, and the development of
the lighting industry has become the main trend.
It is widely used in outdoor lighting, indoor
lighting, automobile lighting, backlighting and
special lighting. It has been applied in all
fields of our life and has been widely used in
the world. The competition in the LED lighting
industry is increasingly fierce, and it is
particularly important to establish a brand and
high-end customization.
7
(No Transcript)
8
Contact Information
Shenzhen KingFung Technology Co.,LTD. Address
Building D, Xintai Industrial Park, Xitou Second
Industrial Zone, SongGang Town, Bao'an, Shenzhen,
Guangdong, China Tel[phone] Fax86-0755-
61658538 E-mail mary_at_kfquickpcb.com Wechat136329
89860 WhatsApp[phone] Skypepcbquick Website
https//www.pcbquick.com/
