Identifying Active Components

1
EST 130, Identifying Active Components

• CEC

2
Contents

• Introduction.
• Vaccum Tubes
• Semiconductor PN Junction Diodes.
• - Silicon Diodes.
• - Germanium Diodes.
• Zener Diodes.
• Bipolar Junction Transistors.
• Field Effect Transistors.
• Integrated Circuits.

3
Electronic Component

• Wikipedia says
• An electronic component is any basic discrete
  device or physical entity in an electronic system
  used to affect electrons or their associated
  fields.

4
Electronic Components

5
Active Components

• Tube Devices or Semiconductor Devices.
• Voltage Controlled or Current Controlled.
• Vaccum Tubes, Diodes, Transistors, Field Effect
  Transistors, Thyristors, Integrated Circuits etc.
• Rely on a source of energy usually from a DC
  power supply.
• Can inject power into a circuit.
• Capable of amplification.

6
Vaccum Tubes

7
Vaccum Triode

Cathode emits electrons when heated by applying
voltage, Anode collects, flow of current
controlled by applying voltage to control gird.
8
Silicon Semiconductor Diodes

9
Silicon Semiconductor Diodes

• 1N 4001
• 1N means one junction between P-type and
  N-type.400 means serial number of the
  rectifier.1 means 1 Ampere current rating.
• BY 127
• B means silicon diode
• Y means rectifier, 127 is the serial
• number.

10
Semiconductor Diodes

BY 126 B Silicon, Y Rectifier 126 Serial
No.
BY 126
11
Silicon Semiconductor Diodes

Unidirectional
12
Diode Characteristics

Cut in voltages Silicon 0.6 V. Germanium
0.2 V.
Conducts when forward biased. Only leakage
current flows when reverse biased.
13
Types of Semiconductor Diodes

14
Germanium Diodes
.

Used for demodulation in radio receivers.

15
Germanium Diode

• Point Contact Diodes
• OA 79
• O means cold cathode (no heating).
• A means low current diode.
• 79 Loctal Lorenz an all-glass wire (fly-leads
  in place of pins) subminiatures.
• Courtesy
• MullardPhilips tube designation.
• https//en.wikipedia.org/wiki/MullardE28093Phil
  ips_tube_designation

16
Types of Semiconductor Diodes

17
Semiconductor Diode Symbols

18
Semiconductor Diode

Forward Bias
Reverse Bias
19

K
A
20
Surface Mount Diodes

21
Applications

• In rectifiers/regulated power supplies.
• In wave shaping circuits.
• For surge protection.
• For unidirectional current flow.
• In clampers/voltage multipliers.
• Can construct basic logic gates.

22
Zener Diodes

23
Zener Diodes
Standard Voltage Ratings 2.2 V, 2.7 V, 3.3 V,
4.7 V, 5.1 V, 5.6 V, 6.8 V, 8.2 V etc _at_ standard
wattage ratings.
24
Zener Diodes

25
Zener Diodes

26
Zener Voltage Regulator

As normal diode under forward bias. Normally
operated under reverse bias. Breaks down under
reverse bias. In voltage regulators and limiters,
waveshaping circuits.
27
Zener Diode for Circuit Protection

28
Bipolar Junction Transistors

• Current Controlled Device.
• Bipolar device.
• Three terminals Emitter, Base and Collector.
• PNP and NPN Transistors - Two PN Junctions.
• Germanium and Silicon transistors.
• Audio Frequency Transistors.
• Radio Frequency Transistors.
• Power Transistors.

29
Silicon NPN Transistors

BC 107 NPN Transistor B Silicon. C Audio
Frequency Low Power Transistor. 107 Serial
Number, for domestic use. TO-18 package.
30
Silicon NPN Transistors

31
Silicon NPN Transistors

Arrow pointed outwards
SL 100 NPN Transistor
32
Silicon PNP Transistor

C
B
E
E
Arrow pointed inwards
SK 100 Silicon PNP Transistor
33
Transistor Symbols

34
Germanium Transistors

AC 128 A Germanium. C Audio frequency low
power . 128 serial number, domestic use
35
Power Transistors

NPN Transistor
2N 3055 2N Two PN Junctions. 3055 Serial No.
36
High Frequency Transistors

BF 194/494 B Silicon. F High Frequency Low
Power. 194 Serial No.
37
Field Effect Transistors

• Voltage Controlled Device.
• Unipolar Device.
• High Input Impedance.
• Source, Drain Gate and Body/Shield.
• Junction Field Effect Transistor (JFET).
• N Channel and P Channel JFETs.
• Metal Oxide Semiconductor Field Effect Transistor
  (MOSFET).
• N Channel and P Channel MOSFETs.

38
Junction Field Effect Transistors

BFW 10, N Channel Junction Field Effect
Transistor.
39
Junction Field Effect Transistor

40
MOSFET

41
Applications of Transistors

• In amplifiers and other electronic circuits.
• In oscillator circuits.
• In domestic and industrial equipments.
• In audio frequency and high frequency circuits.
• In voltage follower circuits.

42
Thyristors

Applications Fan Speed Control. Light Dimmer.
43
Integrated Circuit Chip

Dual In Line Package, May contain millions of
transistors on a single chip, Can be Analog or
Digital.
Pins numbered counterclockwise
44
Integrated Circuit Chip

Surface Mount Chip
Single In Line Package
45
Different IC Packages

46
EPROM Memory Chip

Electrically Programmable Read Only Memory Erased
using Ultraviolet Rays through the window.
47
IC on a Bread Board

48
Thank You
