Problem Solving Tools

1
Problem Solving Tools
2
What Is A Problem?
A condition or set of circumstances that a person
or group thinks should be changed
3
Types of Problems
All Work Is A Process
Defined
Undefined
Stable
Unstable
Improvement
4
Definitions
Cause
Effects
Symptoms
Absent
50
40
C
30
H
20
10
5
Cause Unknown
Fuzzy Vision
Enlarged Blood Vessel
High Blood Pressure
Obese
Poor Diet
Bad Teeth
Dental Hygiene
Ask Why?
6
The Seven QC Tools

• Flowcharts
• Check sheets
• Histograms
• Cause-and-effect diagrams
• Pareto diagrams
• Scatter diagrams
• Control charts

7
Flowcharts

• Shows unexpected complexity, problem areas,
  redundancy, unnecessary loops, and where
  simplification may be possible
• Compares and contrasts actual versus ideal flow
  of a process
• Allows a team to reach agreement on process steps
  and identify activities that may impact
  performance
• Serves as a training tool

8
Flowcharts

• Why use Flow Charts?
• Used to identify and document the path that a
  product or service follows
• Helps problem solvers understand the process
• Pictorially represents all of the steps of a
  process
• Used to examine the relationship between the
  steps in the process
• Used to compare the existing process with a
  proposed process

9
Flowcharts

• Cautions
• Document the process as it truly operates, not as
  it should "ideally" operate
• Include enough detail to address the problem
• Identify departments or operations, not
  individuals

10
Check Sheet

• Creates easy-to-understand data
• Builds, with each observation, a clearer picture
  of the facts
• Forces agreement about the definition of each
  condition or event of interest
• Makes patterns in the data become
• obvious quickly

xx xxxxxx x
11
Check Sheet

• Why use check sheets?
• Gather data to begin to identify patterns
• Help determine how often certain things occur
• Easy to use on shop floor operations
• Cautions
• Only a beginning in the fact finding process
• Collect data consistently and honestly

12
Check Sheets

• Purchase Order Mistakes at Manifold Destiny Plant
  X
• Defect July
  Total
• 5 6
  7 8 9
• No Vendor Info. I II 3
• Missing Charge No. I II I III 7
• Wrong Charge No. III IIII I II 10
• Missing Contact Info. I I I 3
• Missing Part Number III IIII III IIII III 17
• Wrong Part Number II I II I I 7
• No Authorization I 1
• Incorrect Authorization I IIII I I III 11
• TOTAL 12 17 9 9 12 59

13
Histogram

• Displays large amounts of data that are difficult
  to interpret in tabular form
• Shows centering, variation, and shape
• Illustrates the underlying distribution of the
  data
• Provides useful information for predicting future
  performance
• Helps to answer the question Is the process
  capable of meeting requirements?

14
Histogram

• Why use Histograms?
• Used to display distribution of measurements, or
  the variation in a process
• Shows the spread of the measurements
• Shows how many of each measurement there are
• Cautions
• Use intervals of equal width. Unequal widths are
  confusing
• Keep the histogram simple and to the point. Too
  much information is confusing and visually
  displeasing. The best graphs are easy to
  understand quickly.

15
Cause and Effect Diagram

• Enables a team to focus on the content of a
  problem, not on the history of the problem or
  differing personal interests of team members
• Creates a snapshot of collective knowledge and
  consensus of a team builds support for solutions
• Focuses the team on causes, not symptoms

Effect
Cause
16
Cause and Effect Diagram

• Why use Cause Effect Diagrams?
• Used to represent the relationship between an
  effect and possible causes influencing it
• Used to determine the root cause of the problem
• Used to identify, explore, and display the
  possible causes of a problem in a structured
  format
• Useful in organizing the ideas presented in a
  brainstorming session
• Organizes possible causes of a problem into
  groups material, machine, method, measurement,
  environment (mother nature), and man (operator)

17
Cause and Effect Diagram

• Cautions
• Use the major categories to spark ideas for
  causes
• Use as few words as possible for the causes
• Make sure the group understands the "effect" or
  problem to be analyzed. Demonstrations and "show
  and tell" are helpful for group understanding.
• Remember to ask "why does this happen" instead of
  "who did this wrong."
• Cause/Effect must identify the ROOT causes before
  analysis is considered complete.

18
Cause/Effect Diagrams
19
Pareto Diagram

• Helps a team focus on causes that have the
  greatest impact
• Displays the relative importance of problems in a
  simple visual format
• Helps prevent shifting the problem where the
  solution removes some causes but worsens others

20
Pareto Diagram

• Why use Pareto Charts?
• Used to display items in order of relative
  importance
• Used to identify the "vital few" problems on
  which to focus attention and resources
• Commonly known as the "80/20" rule. For example,
  where 80 of the defects are caused by 20 of the
  defect types

21
Pareto Diagram

• Cautions
• Use different measurement scales to identify the
  most important problems. The most frequent
  problems are not always the most costly.
• Regrouping the data may be necessary to identify
  differences. The frequency of defects by defect
  type may show no difference while frequency of
  defects by machine may show a vast difference.
• Break down the broad causes into more and more
  specific parts to help identify the cause and not
  just the symptoms.
• Compare the process before and after alterations
  to the process to assess the impact of the
  changes.
• Only a beginning of the fact finding process
• Remember the most frequent problems are not
  always the most costly

22
Scatter Diagram

• Supplies the data to confirm a hypothesis that
  two variables are related
• Provides both a visual and statistical means to
  test the strength of a relationship
• Provides a good follow-up to cause and effect
  diagrams

23
Run Chart

• Monitors performance of one or more processes
  over time to detect trends, shifts, or cycles
• Allows a team to compare performance before and
  after implementation of a solution to measure its
  impact
• Focuses attention on truly vital changes in the
  process

24
Run Chart

• Why use Run Charts?
• Used to show a trend in distribution
• Cautions
• Only a beginning in the fact finding process
• Collect data consistently and honestly

25
Run Charts
26
Deviation
Norm
Performance
Deviation
Time
27
Frequency
Continuous
Cyclical
Random
28
Trend
Stable

Deviation
Increasing

Deviation
Decreasing

Deviation
29
Changes
Changed crew
Applied new cleaner
Switched suppliers
Hired new foreman
New Non-glare glass
6th anniversary
Measurement
3/1
3/27
4/10
4/15
Time
30
Control Chart

• Focuses attention on detecting and monitoring
  process variation over time
• Distinguishes special from common causes of
  variation
• Serves as a tool for on-going control
• Provides a common language for discussion process
  performance

31
Deviation
UCL
AVG
norm
LCL
32
Poka-Yoke (Mistake-Proofing)

• An approach for mistake-proofing processes using
  automatic devices or methods to avoid simple
  human or machine error, such as forgetfulness,
  misunderstanding, errors in identification, lack
  of experience, absentmindedness, delays,
• or malfunctions

33
Poka-Yoke Examples (from John Grouts Poka-Yoke
Page)
34
Cause/Effect Diagram Exercise
Manpower
50 of all freshman at Lamar fail College Algebra
EFFECT
CAUSE
