PETE 301

1
PETE 301

• Nonlinear Systems of Equations

2
Nonlinear Systems of Equations

• f(x)0 (n variables, n equations)
• Newton-Raphson method
• Meaning is the same as in one variable
• Create a linear approximation locally
• Force the linear approximating function to solve
  the system and continue the iteration

3
Multivariable Taylor Series

• Taylor series
• We will truncate this series to give

4
Multivariable Taylor Series

• This can be represented using a matrix known as
  the Jacobian

5
Multiple Equations

• We are interested in solving cases with several
  equations.

6
Multiple Equations

• This case is a simple extension from the single
  equation case

7
Newton-Raphson

• If we want f(x1Dx1, x2Dx2)0 the Taylor series
  implies

8
Newton-Raphson

• Solve it for the step vector
• We solve it by LU decomposition and back
  substitution for
• (Equivalent to )
• Once Dx is known we calculate the new x

9
Cautious Approach

• We calculate the new approximant according to
• where a is 1 if there is no problem of
  convergence and alpha is taken less if we
  encounter convergence problems.
• a can be adjusted during the iteration process.

10
Questions

• How many subroutines does the user have to
  provide for a Newton-Raphson method?
• Answer two subroutines
• What is the input to the f(x) subroutine?
• What is the output?
• What is the input to the J(x) subroutine?
• What is the output?

11
Example

• Two equations
• The f function
• The Jacobian matrix

12
Example - LTS101

• The starting point
• The convergence criterion
• Now alpha is 1
• Another safeguard max 20 iterations

13
Newton-Raphson Pros and Cons

• Second order convergence
• Needs analytical Jacobian
• Convergence as in the case of single variable
• Good if you start from the vicinity of the
  solution
• Might diverge
• Basically it is in every sophisticated
  engineering code

14
Convergence Criterion

• Sometimes it is formulated in terms of function
  values ("errors")
• That is dangerous, because often the functions
  are math constructions without clear physical
  meaning (and the unit is blurred)
• In practice x always has a well defined unit, and
  "eps" has to correspond to it
• If the elements of x are of different nature, use
  normalization

15
Newton-Raphson Variants

• If the Jacobian is not available analytically, we
  can estimate it by finite difference or
• Quasi Newton (1) We can continuously improve its
  estimate with every new function evaluation or
• Quasi Newton (2) Even better continuously
  improve the estimate of the INVERSE OF THE
  JACOBIAN with every new function evaluation

16
Minimization Multivariate Case

• In many engineering problems we wish to minimize
  a nonlinear function which depends on several
  variables.
• One method for doing this is the polytope method.
  One of its chief advantages is that it does not
  require function derivative information.

17
Polytope Method

• The polytope method was proposed by Nelder and
  Mead and involves moving a simplex of N1
  points across an N-dimensional surface.
• Easiest to think about in 2D!

18
Polytope Method

• In a 2D example think of the 3 points forming a
  triangle.
• The method proceeds by choosing a fourth point
  and checking if the function value at this point
  is less than the function values at the original
  3 points.

From Practical Optimization, Gill, Wright and
Murray
19
Polytope Method

• The method is trying to move the triangle of
  points in a direction which will minimize the
  function.
• Rules define how a fourth point is calculated and
  how this point is used to replace one of the
  values defining the triangle.

20
Steepest Descent Method

• An alternative to the polytope method is the
  steepest descent method. This method uses both
  the values of the function and the values of the
  function derivative.
• The steepest descent method looks for the
  direction in which the function decreases the
  most rapidly and changes the estimates of the
  independent variables (x) in that direction.

21
Constrained Minimization

• Linear objective function and linear constraints
• Linear Programming (simplex algorithm)
• Nonlinear objective function and/or constraints
• - Example Excel solver

22
ODEs Systems of Equations

• Original Runge-Kutta 4 (one equation)

23
System of ODEs

• Runge Kutta 4 (applied to system of equations)

Bold face symbols are vectors
24
Nonlinear Least Squares

• Consider using regression to fit the parameters
  a1 and a2 in the model using measured data y(x)
• This model can not be linearized so the
  regression techniques we learned previously will
  not work
• use nonlinear regression

25
Nonlinear Least Squares

• First expand with a multivariate Taylor series
• We will iterate on the parameters (a1 and a2)
  from a starting guess. Taylor series predicts
  f(xi1) will match y(xi) if

26
Nonlinear Least Squares

• To match every data point (yi) a system of
  equations must be formed and solved
• where

27
Nonlinear Least Squares

• Can DZDA be solved with LU factorization?
• Is the system square?

28
Nonlinear Least Squares

• The system can not be solved in its current form
  because it is not square.
• Multiply both sides by Z

• This can be solved for DA. Equivalent to
  minimizing the sum of the squared difference
  between the data and the model.
