INTEX-NA Campaign -- Aerosol Retrieval Validation
and Regional Aerosol Patterns
Ralph Kahn John Livingston Jens Redemann Phil
Russell the MISR, AATS, and SSFR Teams
2
MISR observing concept
Nine view angles at Earth surface 70.5º forward
to 70.5º aft Four spectral bands at each
angle 446, 558, 672, 866 nm Seven minutes to
observe each scene at all 9 angles 400-km
swath Global coverage about once per week 275
m - 1.1 km spatial sampling Air mass factors
from 1 (nadir) to 3 Scattering angles from 60
to 160 in mid-latitudes
3
Five Years of MISR Global Aerosol Products
Mid-vis AOT Land Water Bright Surfaces
Globe weekly 1030 AM particle size,
shape
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
07 Aug
MISR Coverage Map Path 010 Blocks 55-58 July
22 -- DC-8 11 J-31 13 Aug 07 -- DC-8 17
J-31 22
19
MISR Nadir Level 1B2 RGB Aug 07, 2004 Orbit
24673 Blocks 55-58 1.1 km resolution
DC-8
J-31
Ron Brown
20
From The AATS Team
21
MISR V15.0 Matlab run 10Feb05 (slight change in
AATS due to assumed O3)
From The AATS Team
22
MISR V16.0 Matlab run 10Feb05
From The AATS Team
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Aug 07, 2004, Orbit 24673, Path 010, Blocks 55-58
V16
30
22 July
MISR Coverage Map Path 010 Blocks 55-58 July
22 -- DC-8 11 J-31 13 Aug 07 -- DC-8 17
J-31 22
31
MISR Aa Level 1B2 RGB July 22, 2004 Orbit
24440 Blocks 55-58 1.1 km resolution
32
From The AATS Team
33
AGU poster MISR V15
From The AATS Team
34
MISR V16 Matlab run 11 Feb 2005
From The AATS Team
35
(No Transcript)
36
DC8 (1528 UTC)
37
DC8 (1528 UTC)
38
DC8 (1528 UTC)
39
DC8 (1528 UTC)
40
(No Transcript)
41
July 22, 2004, Orbit 24440, Path 010, Blocks
55-58 V16
42
29 July
MISR Coverage Map Path 011 Blocks 55-58 July
29 -- J-31 16
43
MISR Aa Level 1B2 RGB July 29, 2004 Orbit
24542 Blocks 55-58 1.1 km resolution
44
From Redemann et al.
45
AGU poster MISR V15
From The AATS Team
46
MISR V16 Matlab run 11 Feb 2005
From The AATS Team
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
July 29, 2004, Orbit 24542, Path 011, Blocks
55-58 V16
55
20 July
MISR Coverage Map Path 012 Blocks 55-58 July 20
-- J-31 11
56
MISR Aa Level 1B2 RGB July 20, 2004 Orbit
24411 Blocks 55-58 1.1 km resolution
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
July 20, 2004, Orbit 24411, Path 012, Blocks
55-58 V16
63
From The AATS Team
64
MISR V16 Matlab run 11 Feb 2005
Note V16 MISR AODs gt 0 are available only within
blue box shown in previous slide. These AATS-14
data are means for all AATS data points shown in
previous slide.
From The AATS Team
65
From The AATS Team
66
.
67
(No Transcript)
68
(No Transcript)
