Multiprocessing and Scalability

1
Multiprocessing and Scalability

• A.R. Hurson
• Computer Science Department
• Missouri Science Technology
• hurson_at_mst.edu

2
Multiprocessing and Scalability

• Large-scale multiprocessor systems have long held
  the promise of substantially higher performance
  than traditional uni-processor systems.
• However, due to a number of difficult problems,
  the potential of these machines has been
  difficult to realize. This is because of the

3
Multiprocessing and Scalability

• Advances in technology - Rate of increase in
  performance of uni-processor,
• Complexity of multiprocessor system design - This
  drastically effected the cost and implementation
  cycle.
• Programmability of multiprocessor system - Design
  complexity of parallel algorithms and parallel
  programs

4
Multiprocessing and Scalability

• Programming a parallel machine is more difficult
  than a sequential one. In addition, it takes
  much effort to port an existing sequential
  program to a parallel machine than to a newly
  developed sequential machine.
• Lack of good parallel programming environments
  and standard parallel languages also has further
  aggravated this issue.

5
Multiprocessing and Scalability

• As a result, absolute performance of many early
  concurrent machines was not significantly better
  than available or soon-to-be available
  uni-processors.

6
Multiprocessing and Scalability

• Recently, there has been an increased interest in
  large-scale or massively parallel processing
  systems. This interest stems from many factors,
  including
• Advances in integrated technology.
• Very high aggregate performance of these
  machines.
• Cost performance ratio.
• Widespread use of small-scale multiprocessors.
• Advent of high performance microprocessors.

7
Multiprocessing and Scalability

• Integrated technology
• Advances in integrated technology is slowing
  down.
• Chip density - integrated technology now allows
  all performance features found in a complex
  processor be implemented on a single chip and
  adding more functionality has diminishing returns

8
Multiprocessing and Scalability

• Integrated technology
• Studies of more advanced superscalar processors
  indicates that they may not offer a performance
  improvement more than 2 to 4 for general
  applications.

9
Multiprocessing and Scalability

• Aggregate performance of machines
• Cray X-MP (1983) had a peak performance of 235
  MFLOPS.
• A node in an Intel iPSC/2 (1987) with attached
  vector units had a peak performance of 10 MFLOPS.
  As a result, a 256-processor configuration of
  Intel iPSC/2 would offer less than 11 times the
  peak performance of a single Cray X-MP.

10
Multiprocessing and Scalability

• Aggregate performance of machines
• Today a 256-processor system might offer 100
  times the peak performance of the fastest
  systems.
• Cray C90 has a peak performance of 952 MFLOPS,
  while a 256-processor configuration using MIPS
  R8000 would have a peak performance of 76,800
  MFLOPS.

11
Multiprocessing and Scalability

• Economy
• Cray C90 or Convex C4 which exploit IC and
  packaging technology cost about 1 million.
• High end microprocessor cost somewhere between
  2000-5000.
• By using a small number of microprocessors, equal
  performance can be achieved at a fraction of the
  cost of more advanced supercomputers.

12
Multiprocessing and Scalability

• Small-scale multiprocessors
• Due to the advances in technology,
  multiprocessing has come to the desktops and
  high-end personal computers. This has led to
  improvements in parallel processing hardware and
  software.

13
Multiprocessing and Scalability

• In spite of these developments, many challenges
  need to overcome in order to exploit the
  potential of large-scale multiprocessors
• Scalability
• Ease of programming

14
Multiprocessing and Scalability

• Scalability Maintaining the cost-performance of
  a uni-processor while linearly increasing overall
  performance as processors are added.
• Ease of programming Programming a parallel
  system is inherently more difficult than
  programming a uni-processor where there is a
  single thread of control. Providing a single
  shared address space to the programmer is one way
  to alleviate this problem Shared-memory
  architecture.

15
Multiprocessing and Scalability

• Shared-memory eases the burden of programming a
  parallel machine since there is no need to
  distribute data or explicitly communicate data
  between the processors in software.
• Shared-memory is also the model used on
  small-scale multiprocessors, so it is easier to
  transport programs that have been developed for a
  small system to a larger shared-memory system.

16
Multiprocessing and Scalability

• Flynns Taxonomy
• Flynn has classified the concurrent space
  according to the multiplicity of instruction and
  data streams

17
Multiprocessing and Scalability

• Flynns Taxonomy
• The Cartesian product of these two sets will
  define four different classes
• SISD
• SIMD
• MISD
• MIMD

18
Multiprocessing and Scalability

• Flynns Taxonomy
• The MIMD class can be further divided based on
• Memory structure global or distributed
• Communication/synchronism mechanism shared
  variable or message passing.

19
Multiprocessing and Scalability

• Flynns Taxonomy
• As a result we have four additional classes of
  computers
• GMSV Shared memory multiprocessors
• GMMP ?
• DMSV Distributed shared memory
• DMMP Distributed memory (multi-computers)

20
Multiprocessing and Scalability

• A taxonomy of MIMD organization
• The memory can be
• Centralized
• Distributed

21
Multiprocessing and Scalability

• A taxonomy of MIMD organization
• The inter-processor communicate can be either
  through explicit messages or through the common
  address space. This brings out two classes
• Message passing systems (also called distributed
  memory systems. It is natural to assume that the
  memory in message passing system is distributed.)
  ? Intel iPSC, Paragon nCUBE2, IBM SP1 and SP2
• Shared-memory systems ? IBM RP3, Cray X-MP, Cray
  Y-MP, Cray C90, Sequent Symmetry

22
Multiprocessing and Scalability

• Multiple instruction streams multiple data
  streams organizations are made of multiple
  processors and multiple memory modules connected
  together via some interconnection network.
• In this paradigm, based on the memory
  organization and the way processors communicate
  with each other, one can distinguishes two broad
  categories
• Shared memory organization
• Message passing organization.

23
Multiprocessing and Scalability

• A shared memory organization typically
  accomplishes inter-processor coordination through
  a global memory shared by all processors - The
  global address space shared by all processors.
• In shared-memory multiprocessor systems the
  processors are more tightly coupled. Memory is
  accessible to all processors, and communication
  among processors is through shared variables or
  messages deposited in shared memory buffers.

24
Multiprocessing and Scalability

• Shared-memory System (programmers view)

25
Multiprocessing and Scalability

• Shared-memory System (programmers view)
• In a shared-memory machine, processors can
  distinguish communication destination, type, and
  value through shared-memory addresses.
• There is no requirement for the programmer to
  manage the movement of data.

26
Multiprocessing and Scalability

• Shared-Memory Multiprocessor

27
Multiprocessing and Scalability

• Multiprocessors interconnection networks can be
  classified based on a number of criteria
• Mode of operation - Synchronous vs. asynchronous
• In synchronous mode a single clock is used by all
  components in the system (whole system is
  operating in a lock-step manner).
• In asynchronous mode hand-shaking signals are
  used to coordinate the operations.
• Synchronous systems are slower than asynchronous
  systems, but they are race and hazard free.

28
Multiprocessing and Scalability

• Control strategy - centralized vs. decentralized
• In centralized control systems, a single central
  control unit is used to oversee and control the
  operations of the components.
• In decentralized control, the control functions
  are distributed among different components.
• The reliability of centralized control is its
  weak point (single point of failure).
• Crossbar switch is a centralized control and
  multistage interconnection network is a
  decentralized control.

29
Multiprocessing and Scalability

• Switching techniques - circuit switching vs.
  packet switching
• In circuit switching a complete path has to be
  established before the start of communication.
  This path remains intact during the
  communication.
• In a packet switching, communication is divided
  into packets. Packets from one component to
  another component are sent in store-and-forward
  manner.
• Packet switching uses the network resources more
  efficiently.

30
Multiprocessing and Scalability

• Topology - Static vs. dynamic
• Topology defines how the resources in an
  interconnection network are communicating with
  each other. In a ring topology, each processor
  (say pk) is physically connected to its neighbor
  (pk-1, pk1).
• In static topology, direct fixed link are
  established among nodes to form a fixed network.
• In dynamic topology, connections are established
  as needed.

31
Multiprocessing and Scalability

• A shared-memory architecture allows all memory
  locations to be accessed by every processors.
  This helps to ease the burden of programming a
  parallel system, since
• There is no need to distribute data or explicitly
  communicate data between processors in the
  system.
• Shared-memory is the model adopted on small-scale
  multiprocessors, so it is easier to map programs
  that have been parallelized for small-scale
  systems to a larger shared-memory system.

32
Multiprocessing and Scalability

• A message passing organization typically combines
  the local memory and processor as a node of the
  interconnection network - There is no global
  address space. So there is a need to move data
  from one processor to the other via messages.
• In message passing multiprocessor systems
  (distributed memory), processors communicate with
  each other by sending explicit messages.

33
Multiprocessing and Scalability

• Message passing System (programmers view)

34
Multiprocessing and Scalability

• Message passing System (programmers view)
• In a message passing machine, the user must
  explicitly communicate all information passed
  between processors. Unless the communication
  patterns are very regular, the management of this
  data movement is very difficult.
• Note, multi-computers are equivalent to this
  organization. It is also referred to as No
  Remote Memory Access Machine (NORMA).

35
Multiprocessing and Scalability

• Message passing multiprocessor

36
Multiprocessing and Scalability

• Inter-processor communication is critical in
  comparing the performance of message passing and
  shared-memory machines
• Communication in message passing environment is
  direct and is initiated by the producer of data.
• In shared-memory system, communication is
  indirect, and producer usually moves data no
  further than memory. The consumer, then has to
  fetch the data from the memory decrease in
  performance.

37
Multiprocessing and Scalability

• In a shared-memory system, communication requires
  no intervention on the part of a run-time library
  or operating system. In a message passing
  environment, access to the network port is
  typically managed by the system software. This
  overhead at the sending and receiving processors
  makes the start up costs of communication much
  higher (usually 10s to 100s of microsecond).

38
Multiprocessing and Scalability

• As a result of high communication cost in a
  message passing organization either performance
  is compromised or a coarser grain parallelism,
  and hence more limitation on exploitation of
  available parallelism, must be adapted.
• Note that the start up overhead of communication
  in shared-memory organization is typically on the
  order of microseconds.

39
Multiprocessing and Scalability

• Communication in shared-memory systems is usually
  demand-driven by the consuming processor.
• The problem here is overlapping communication
  with computation. This is not a problem for
  small data items. However, it can degrade the
  performance if there is frequent communication or
  a large amount of data is exchanged.

40
Multiprocessing and Scalability

• Consider the following case, in a message passing
  environment
• A producer process wants to send 10 words to a
  consumer process. In a typical message passing
  environment with blocking send and receive
  protocol this problem would be coded as

Producer process Send (proci, processj,
_at_sbuffer, num-bytes)
Consumer process Receive (_at_rbuffer, max-bytes)
41
Multiprocessing and Scalability

• This code usually is broken into the following
  steps
• The operating system checks protections and then
  programs the network DMA controller to move the
  message from the senders buffer to the network
  interface.
• A DMA channel on the consumer processor has been
  programmed to move all messages to a common
  system buffer. When the message arrives, it is
  moved from the network interface to the system
  buffer and an interrupt is posted to the
  processor.

42
Multiprocessing and Scalability

• The receiving processor services the interrupt
  and determines which process the message is
  intended for. It then copies the message to the
  specified receiver buffer and reschedules the
  program on the processors ready queue.
• The process is dispatched on the processor and
  reads the message from the users receive buffer.

43
Multiprocessing and Scalability

• On a shared-memory system there is no operating
  system involved and the process can transfer data
  using a shared data area. Assuming the data is
  protected by a flag indicating its availability
  and the size, we have

Producer process For i 0 to num-bytes
buffer i source i Flag num-bytes
Consumer process While (Flag 0) For i
0 to Flag dest i buffer i
44
Multiprocessing and Scalability

• For the message passing environment, the dominant
  factors are the operating system overhead
  programming the DMA and the internal processing.
• For the shared-memory environment, the overhead
  is primarily on the consumer reading the data,
  since it is then that data moves from the global
  memory to the consumer processor.

45
Multiprocessing and Scalability

• Thus, for a short message the shared-memory
  system is much more efficient. For long
  messages, the message-passing environment has
  similar or possibly higher performance.

46
Multiprocessing and Scalability

• Message passing vs. Shared-memory systems
• The message passing systems minimize the hardware
  overhead.
• A single-thread performance of a message passing
  system is as high as a uni-processor system,
  since memory can be tightly coupled to a single
  processor.
• Shared-memory systems are easier to program.

47
Multiprocessing and Scalability

• Message passing vs. Shared-memory systems
• Overall, the shared-memory paradigm is preferred
  since it is easier to use and it is more
  flexible.
• A shared-memory organization can emulate a
  message passing environment while the reverse is
  not possible without a significant performance
  degradation.

48
Multiprocessing and Scalability

• Message passing vs. Shared-memory systems
• Shared-memory systems offer lower performance
  than message passing systems if communication is
  frequent and not overlapped with computation.
• In shared-memory environment, interconnection
  network between processors and memory usually
  requires higher bandwidth and more sophistication
  than the network in message passing environment.
  This can increase overhead costs to the level
  that the system does not scale well.

49
Multiprocessing and Scalability

• Message passing vs. Shared-memory systems
• Solving the latency problem through memory
  caching and cache coherence is the key to a
  shared-memory multiprocessor.

50
Multiprocessing and Scalability

• In the design of shared memory organization a
  number of basic issues have to be taken into
  account
• Access control determines which process accesses
  are possible to which resource.
• Access control protocols make the required check
  for every access request issued by the processors
  to the shared memory against the contents of
  access control table.

51
Multiprocessing and Scalability

• Synchronization rules and constraints limit the
  time of accesses from sharing processors to
  shared resources.
• Appropriate synchronization ensures that the
  information flows properly and ensures system
  functionality.

52
Multiprocessing and Scalability

• Protection prevents processes from making
  arbitrary access to resources belonging to other
  processes.

53
Multiprocessing and Scalability

• In message passing organization processors
  communicate with each other via send/receive
  operations. The processing units of a message
  passing system are connected in a variety of ways
  ranging from architecture-specific
  interconnection structure to geographically
  dispersed networks.
• The massage passing approach, in general, is
  scalable.

54
Multiprocessing and Scalability

• Two design factors must be considered in
  designing interconnection networks for message
  passing systems
• Bandwidth which is the number of bits that can be
  transmitted per unit of time, and
• Latency which is defined as the time to complete
  a message transfer.

55
Multiprocessing and Scalability

• Shared Memory Multiprocessor
• In most shared-memory organizations, processors
  and memory are separated by an interconnection
  network.
• For small-scale shared-memory systems, the
  interconnection network is a simple bus.
• For large-scale shared-memory systems, similar to
  the message passing systems, we use multistage
  networks.

56
Multiprocessing and Scalability

• Shared memory multiprocessors - A taxonomy
• Based on the memory organization, shared memory
  multiprocessor systems are classified as
• Uniform Memory Access (UMA) systems,
• Non-uniform Memory Access (NUMA) systems, and
• Cache-only memory (COMA) systems
• Note, most large-scale shared memory machines
  utilize a NUMA structure.

57
Multiprocessing and Scalability

• Uniform Memory Access Architecture (UMA)
• The physical memory is uniformly shared by all
  the processors.
• Each processor may use a private cache.
• UMA is equivalent to tightly coupled
  multiprocessor class.
• When all processors have equal access to
  peripheral devices, the system is called a
  symmetric multiprocessor (SMP).

58
Multiprocessing and Scalability

• In UMA, the shared memory is accessible by all
  processors via an interconnection network in the
  same way a single processor accesses its memory.
  As a result, all processors have equal access
  time to any memory address.
• The interconnection network in UMA can be a
  single bus, multiple busses, crossbar switch, or
  a multiport memory.

59
Multiprocessing and Scalability

• Uniform Memory Access Architecture

60
Multiprocessing and Scalability

• Symmetric Multiprocessor
• Each processor has its own cache, all the
  processors and memory modules are attached to the
  same interconnect Usually a shared bus.
• The ability to access all shared data efficiently
  and uniformly using ordinary load and store
  operations, and
• Automatic movement and replication of date in the
  local caches
• makes this organization attractive for concurrent
  processing.

61
Multiprocessing and Scalability

• Symmetric Multiprocessor

62
Multiprocessing and Scalability

• Non-uniform Memory Access (NUMA)
• In NUMA, each processor has part of the shared
  memory attached. However, access time to a
  shared memory address depends on the distance
  between the processor and the designated memory
  module - access time varies with the location of
  the memory word.
• In NUMA a number of architectures can be used to
  interconnect processors to memory modules.
• NUMA is also referred to as Distributed
  Shared-Memory Multiprocessor Architecture (DSM).

63
Multiprocessing and Scalability

• Shared Memory Multiprocessor
• UMA is easier to program than NUMA.
• This configuration is not symmetric, as a result,
  locality should be exploited to improve
  performance.
• Most of the small-scale shared-memory systems are
  based on UMA philosophy and large-scale
  shared-memory systems are based on NUMA.

64
Multiprocessing and Scalability

• Non-uniform Memory Access (NUMA)

65
Multiprocessing and Scalability

• Shared Memory Multiprocessor Distributed Memory

66
Multiprocessing and Scalability

• Distributed Shared-memory architecture
• As noted, it is possible to build a shared-memory
  machine with a distributed-memory organization.
• Such a machine has the same structure as the
  message passing system, but instead of sending
  messages to other processors, every processor can
  directly address both its local memory and remote
  memories of other processors.

67
Multiprocessing and Scalability

• Cache-only memory (COMA)
• In COMA similar to NUMA, each processor has part
  of the shared memory. However, the shared memory
  consists of cache memory - data must be migrated
  to the processor requesting it.
• In short, COMA is a special class of NUMA in
  which distributed global main memory are caches.

68
Multiprocessing and Scalability

• Cache Only Memory Architecture (COMA)

69
Multiprocessing and Scalability

• Shared Memory Multiprocessor
• Since all communication and local computations
  generate memory accesses in a shared address
  space, from a system architectures perspective,
  the key high level design issue lies in the
  organization of memory hierarchy.
• In general there are the following choices

70
Multiprocessing and Scalability

• Shared Memory Multiprocessor Shared cache

71
Multiprocessing and Scalability

• Shared Memory Multiprocessor Shared cache
• This platform is more suitable for small scale
  configuration 2 to 8 processors.
• It is a more common approach for multiprocessor
  on chip.

72
Multiprocessing and Scalability

• Shared Memory Multiprocessor Bus based Shared
  Memory

73
Multiprocessing and Scalability

• Shared Memory Multiprocessor Bus based Shared
  Memory
• This platform is suitable for small to medium
  configuration 20 to 30 processors.
• Due to its simplicity it is very popular.
• Bandwidth of the shared bus is the major
  bottleneck of the system.
• This configuration also is known as Cache
  Coherent Shared Memory Configuration.

74
Multiprocessing and Scalability

• Shared Memory Multiprocessor Dance Hall

75
Multiprocessing and Scalability

• Shared Memory Multiprocessor Dance Hall
• This platform is symmetric and scalable.
• All memory modules are far away from processors.
• In large configurations, several hops are needed
  to access memory.

76
Multiprocessing and Scalability

• Shared Memory Multiprocessor
• In all shared memory multiprocessor organization,
  the concept of cache is becoming very attractive
  in reducing the memory latency and the required
  bandwidth.
• In all design cases, except shared cache, each
  processor has at least one level of private
  cache. This raises the issue of cache coherence
  as an attractive research directions.

77
Multiprocessing and Scalability

• Shared Memory Multiprocessor Cache Coherency
• The architecture supports the caching of both
  shared and private data
• When a private item is requested, its location is
  migrated to the cache, reducing the average
  access time as well as the memory bandwidth
  required.
• When shared data is cached, the shared value may
  be replicated in multiple caches. This reduces
  the access latency, memory bandwidth required,
  and contention at the shared data item.

78
Multiprocessing and Scalability

• Shared Memory Multiprocessor Cache Coherency
• Caching of the shared data, however, introduces a
  new problem - Cache Coherence.
• Cache Coherence problem means that two different
  processors can have two different values for the
  same location.

79
Multiprocessing and Scalability

• Shared Memory Multiprocessor Cache Coherency
• Assume write-through in a 2-processor
  configuration

Cache CPU A
Cache CPU B
Memory For X
Time
Event
80
Multiprocessing and Scalability

• Shared Memory Multiprocessor Cache Coherency
• Copies of the same memory blocks are resident in
  one or more caches and processors make
  modifications to the very same cache block.
• Unless special action in taken, other processors
  will continue to access the old stale copy of the
  block in their caches.

81
Multiprocessing and Scalability

• Cache Coherence Problem An Example
• Consider the following configuration and the
  sequence of events
• 1 p1 reads u from main memory
• 2 p2 reads u from main memory
• 3 p3 writes and changes u from 5 to 7 using
  write through policy
• 4 p1 reads u again

82
Multiprocessing and Scalability

• Cache Coherence Problem An Example

83
Multiprocessing and Scalability

• Cache Coherence Problem An Example
• Unless we take special action, if p1 reads u for
  the second time, it might get an old value.
• The value read by p2 is a subject of write policy.

84
Multiprocessing and Scalability

• Cache Coherence Problem An Example
• Assume that in the previous example p3 uses
  write-through policy. Does it help the situation
  or not?

85
Multiprocessing and Scalability

• Cache Coherence Problem An Example

86
Multiprocessing and Scalability

• Cache Coherence Problem An Example
• Now the situation is even worse, if p2 initiate a
  read on u, it will get an old value of u.
• In a shared memory multiprocessor system, reading
  and writing shared variable by different
  processors are frequent events. As a result,
  cache coherence needs to be addressed as a basic
  hardware design issue.

87
Multiprocessing and Scalability

• Cache Coherence Problem
• Informally memory is coherent if any read of a
  data item returns the most recently written value
  of that data item.
• This simple definition contains two different
  aspects of memory behavior
• Coherence what values can be returned by a read?
• Consistency When a written value will be
  returned by a read?

88
Multiprocessing and Scalability

• Cache Coherence Problem
• A memory system is coherent if
• Preserving Program Order - A read by a processor
  P to a location X that follows a write by P to X,
  with no writes of X by another processor, between
  the write and the read by P, always returns the
  value written by P.

89
Multiprocessing and Scalability

• Cache Coherence Problem
• Coherent View - A read by a processor to location
  X follows a write by another processor to X,
  returns the written value if the read and write
  are sufficiently separated and no other write to
  X occur between the two accesses.

90
Multiprocessing and Scalability

• Cache Coherence Problem
• Write Serialization - Writes to the same location
  are serialized. Two writes to the same location
  by two processors are seen in the same order by
  all processors.

91
Multiprocessing and Scalability

• Cache Coherence Definitions
• A memory operation is referred to as read, write,
  and read-modify-write on individual data element.
• A memory operation is atomic.
• Write propagation means that writes become
  visible to all processors.
• Write serialization means that all writes to a
  location are seen in the same order by all
  processors.

92
Multiprocessing and Scalability

• Cache Coherence
• For a multiprocessor system, memory is coherent
  if the results of any execution of a program are
  such that for each location, it is possible to
  construct a hypothetical serial order of all
  operations to the location that is consistent
  with the results of the execution and in which
• Operations issued by any particular process
  occurs in the order in which they were issued to
  the memory system by that process, and
• The value returned by each read operations is the
  value written by the last write to that location
  in the serial order.

93
Multiprocessing and Scalability

• Cache Coherence Protocol
• The protocol to maintain coherence for multiple
  processors are called cache coherence protocol.
• The key issue to implement a cache coherence
  protocol is tracking the state of any sharing of
  a data block.

94
Multiprocessing and Scalability

• Cache Coherence Protocol
• Directory Bases The sharing status of a block
  of physical memory is kept in just one location -
  Directory.
• Snooping Based Every cache that has a copy of
  the data are on the shared memory bus and snoop
  on the bus to determine whether or not they have
  a copy of a block that is requested on the bus.

95
Multiprocessing and Scalability

• Cache Coherence Protocol
• There are two ways to maintain the coherence
  requirement
• Write Invalidation
• Write Propagate (Write update or Write Broadcast)

96
Multiprocessing and Scalability

• Write Invalidation To ensure that a processor
  has exclusive access to a data item before it
  writes that item.

Bus activity
CPU As Cache
CPU Bs Cache
Memory Location X
Processor activity
0
97
Multiprocessing and Scalability

• Write Propagate All the cached copies of a data
  item are updated when data item is written.

Bus activity
CPU As Cache
CPU Bs Cache
Memory Location X
Processor activity
0
98
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• Within this class bus based shared memory
  multiprocessors, this is a simple and elegant
  solution. Recall that
• Bus is a single set of wires connecting
  resources,
• Every resources attached to the bus can observe
  every bus transaction,
• All transactions that appear on the bus are
  visible to the cache controllers in the same
  order,

99
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• When a processor issues a request to its cache,
  its cache controller examines the status of the
  cache and takes suitable actions, including a
  request to access memory.
• All cache controllers snoop on the bus and
  monitor transactions.

100
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• A snooping cache controller may take action if a
  bus transaction is relevant to it
• In case of a write-through policy, if a snooping
  cache has a copy of the data, it either
• Updates its copy update based protocols, or
• Invalidates its copy invalidation based
  protocols.
• In either case, when a processor requests for a
  block, it will see the most recent value.

101
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• Refer to our previous example

102
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• When p3 writes into u, its cache controller
  generates a bus transaction to update memory.
• Observing this bus transaction, it is relevant to
  p1 and hence p1s cache controller invalidates
  its own copy of the block containing u.
• The main memory updates u to 7.
• Subsequent reads to u from processors p1 and p2
  generate misses and hence, they will get the
  correct value of 7 from the main memory.

103
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• Simplicity is the main advantage of snooping
  protocols there is no need to explicitly use
  coherence operations in the program.
• By extending the cache controller and exploiting
  the properties of the bus, reads and writes that
  are natural to the program keep the caches
  coherent.
• However, snooping systems with write-through
  policy are not very efficient, specially if we
  realize the natural bandwidth limitation of a bus.

104
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• Let us look at the snooping protocol with
  write-back policy - The processors are able to
  write to different blocks in their local caches
  concurrently without any bus transactions.
• Recall that in a uni-processor system updates to
  the main memory blocks resident in cache will be
  done during the replacement - cache block will be
  dirty for a period.
• In a multiprocessor system, this modified state
  is used by the protocols to indicate exclusive
  ownership of the block by cache.

105
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• A cache is said to be the owner of a block if it
  must supply the data upon a request for that
  block.
• A cache has an exclusive copy of a block if it is
  the only cache with a valid copy of the block -
  Exclusivity implies that the cache may modify the
  block without notifying anyone else.

106
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• As a result, if a cache does not have
  exclusivity, then it cannot write into that block
  before first putting a transaction on the bus to
  communicate with others - consequently, a
  processor might have the block in its cache in a
  valid state, but since a transaction must be
  generated, it is treated as a write miss.

107
Multiprocessing and Scalability

• Cache Coherence Solutions Bus Snooping
• If a cache has a modified block, then it is the
  owner and thus it has exclusivity.
• On a write miss in an invalidation protocol, a
  special form of transaction, read exclusive, is
  generated to acquire exclusive ownership.
• As a result, concurrent writes to the same block
  is not allowed - the read exclusive bus
  transactions are serialized.

108
Multiprocessing and Scalability

• Scalable shared-memory multiprocessors (SSMP)
  provides the shared-memory programming model
  while removing the bottleneck of todays
  small-scale systems.

109
Multiprocessing and Scalability

• Scalable shared-memory multiprocessors
• Scalability must be physically possible and
  technically feasible.
• Adding processors increases the potential
  computational capability of the system, but to
  realize this potential, all aspect of the system
  must be scaled up - Specially the memory
  bandwidth.

110
Multiprocessing and Scalability

• Scalable shared-memory multiprocessors
• A natural solution is to distribute memory among
  processors so that each processor has direct
  access to its local memory.
• However, interconnection network, connecting
  processors must provide scalable bandwidth at
  reasonable cost and latency.

111
Multiprocessing and Scalability

• Scalable shared-memory multiprocessors
• Scalable systems are less closely coupled than
  bus based shared memory multiprocessors, so
  interactions among processors and
  processors/memories are different.
• A scalable system attempts to avoid inherent
  design limits on the extent to which resources
  can be added to the system.

112
Multiprocessing and Scalability

• Scalable shared-memory multiprocessors
• Scalability is studied based on its effect on the
  following metrics
• Throughput
• Latency per operation
• Cost
• Implementation.
