EXTREME VALUES, COPULAS AND GENETIC MAPPING

• Bojan Basrak
• Department of Mathematics,
• University of Zagreb, Croatia

EVA 2005, Gothenburg
2
Genetic mapping

• Genetic map gives the relative positions of genes
  on the chromosomes with distances between them
  typically measured in centimorgans (cM)
• Linkage analysis aims to find approximate
  location of genes associated with certain traits
  in plants and animals.
• It is a statistical method that compares genetic
  similarity between two individuals (at a marker)
  to similarity of their physical or psychological
  traits (phenotype).
• Among the most studied traits are inheritable
  diseases.

3
QTL

• Quantitative trait A measurable trait that shows
  continuous variation, e.g. skin pigmentation,
  height, cholesterol, etc.
• Quantitative traits are normally influenced by
  several genes and the environment.
• QTL or quantitative trait locus a locus (or a
  gene) affecting quantitative trait.
• There is even The Journal of Quantitative Trait
  Loci.

4

• Genetic similarity between two individuals at a
  given locus is typically measured by a number
  called identity by descent (IBD) status.
• Two genes of two different people are IBD if one
  is a physical copy of the other, or if they are
  both copies of the same ancestral gene.
• For any two people IBD status is a number in the
  set 0,1,2. In real-life, this number typically
  needs to be estimated.

5

• Linkage analysis is very effective with Mendelian
  inheritance.
• Mapping genes involved in inheritable diseases
  can be done by comparing IBD status of affected
  relatives (e.g. breast cancer)
• Mapping QTLs in animals or plants is performed by
  arranging a cross between two inbred strains,
  which are substantially different in a
  quantitative trait (e.g. tomato fruit mass or pH).

6
IBD status of two half sibs
Mother chromosomes
Chromosomes of two half sibs
Sib 1
After two meiosis and some other developments
Sib 2
X(t) number of alleles identical by descent
distance in Morgans
t s
X(t)0, X(s)1
7

• Recombinations, or more specifically, locations
  of crossovers in meiosis are frequently modelled
  by a stochastic process (standard choice is the
  Poisson process, suggested by Haldane in 1919.)
• The process (X(t)) is an ON-OFF process in the
  case of half-sibs, or sum of two independent such
  processes in the case of siblings.
• In particular, under Poisson process model,
  (X(t)) is a stationary Markov process. Moreover,
  X(t) is Bernoulli distributed for each t in the
  case of half sibs.

8

• In the Haldane model, we have
• where
• is the recombination probability.
• For simplicity, we assume that IBD status is
  known at each marker (i.e. markers are completely
  genetically informative).

9

• Human genome consists of over 3 109 basepairs
  (in two copies) on 23 chromosomes. The average
  length of a chromosome is 140 cM.
• Total length of female (autosomal) genome is
  4296cM
• Total length of male genome is 2851 cM
• That is there is 1 expected crossover over 105
  Mb in males and over 88 Mb in females. Thus, on
  human genome, 1 cM approximately equals 1Mb.

10
Data

• From n sib-pairs we observe
• - a sequence of iid phenotypes, with continuous
  marginal distribution
• and
• - a sequence of iid processes

11
IBD 1 at t IBD 0 at t
12
Haseman-Elston

• In 1972, they suggested to test whether there is
  a linear regression with negative slope between
• Soon, this became the standard tool for mapping
  of QTLs in human genetics

13
Variance Components Model

• Variance components model (Fulker and Cherny)
  essentially assumes that the joint distribution
  of the phenotypes is
• bivariate normal, conditionally on the IBD status
  x, with the same marginal distributions,
• and the correlation

14
Linkage Analysis

• The main question
• Does higher IBD status mean stronger dependence
  between the two trait values?
• In variance components model this translates into
  the test of Ho
• against HA

15
Test statistic

• Statistical test is based on the log-likelihood
  ratio statistic
• Or (equivalently) on the efficient score statistic

16

• Where
• is the score function, and
• is appropriate entry of Fisher information matrix
  and
• needs to be estimated in practice.

17
Z(t)
tmax
18
Significance in genome-wide scans

• If we have more than one marker we need to deal
  with the issue of multiple testing. The solution
  of this problem depends on the intermarker
  spacings and the sample size.
• One could use permutation tests or other
  simulation based methods to obtain p-values.
• If the sample size is large, one can apply a nice
  asymptotic theory that determines significance
  thresholds from the analysis of extremes of
  certain Gaussian processes (see. Lander and
  Botstein, Siegmund et al.)

19

• For an illustration, we assume that the markers
  are dense, that is IBD status is measured
  continuously along the genome. It turns out that
  under our assumptions and the null hypothesis one
  can show that
• where is Ornstein-Uhlenbeck process with mean
  zero and covariance function
• over each chromosome.

20

• Now, approximate thresholds for a given
  significance level can be obtained by studying
  extremes of Ornstein-Uhlenbeck process (cf.
  Leadbetter et al) over finite interval. Hence, we
  get
• For 23 human chromosomes with average length of
  140 cM and significance level 0.05 we get
  threshold b4.08 (3.62 on LOD scale).

21
Other models

• The asymptotic theory does not change for other
  more realistic models of the recombination
  process (e.g. Kosambi model or chi squared
  model), since the asymptotic results for extremes
  of Gaussian processes depend only on the local
  behavior of the autocorrelation function of the
  process.
• Howver, for all of these models it holds that
  corr(Xs,Xt)1-rt-s as t-s converges to 0. So
  in the limit we obtain Gaussian process with the
  same behavior of autocorrelations.

22
Disadvantages

• Normality assumption is frequently questionable
• Correlation can be a very bad measure of
  dependence if this assumption does not hold
• Risch and Zhang (1995) show how
• "The majority of such pairs provide little power
  to detect linkage only pairs that are concordant
  for high values, low values, or extremely
  discordant pairs (for example, one in the top 10
  percent and other in the bottom 10 percent of the
  distribution) provide substantial power"

23
Copula

• Copula of a random pair is the
  distribution function C of the random vector
• where we assume that the marginal distributions
  F1 and F2 of Y1and Y2 are invertible. Hence the
  marginal distributions of the copula are both
  uniform on 0,1.
• It is well known that the distribution of a
  random pair splits into two marginal
  distributions and the copula. Also copula is
  invariant under continuous increasing
  transformations.

24

• It is straightforward to check that
• i.e. the distribution of a random pair splits
  into two marginal distributions and the copula
• Copula is invariant under monotone
  transformations, that is
• have the same copula, for increasing function h.

25
Basic Examples
26
Linkage analysis rephrased

• The main question
• Does higher IBD status mean stronger dependence
  between the two trait values?
• could be rephrased as
• Does higher IBD status mean that the two trait
  values have more diagonalized copula?
• Note marginal distributions do not change with
  IBD status.

27
Normal Copula

• Normal copula is a copula of a normally
  distributed random vector. Thus, if
• then the random vector has the bivariate
  normal copula.
• Since it depends only on we denote it by

28
Bivariate Normal Copula
29
New Model

• Assume that the pair has
• the same copula as in the variance components
  model, i.e.
• conditionally on the IBD status x
• and the same (but arbitrary) continuous marginal
  distribution i.e. F1 F2 .

30

• The model is not so new after all, equivalently,
  there is an h such that
• satisfies the assumption of the v.c. model.
• Suppose that has the standard normal
  distribution function then
• That is

31

• We can proceed in two ways
• we could guess (estimate) h, or
• we could guess (estimate) F1
• The first method is already frequently applied in
  practice,
• while the second one is easier to justify using
  the empirical
• distribution function of the phenotypes.
• To estimate F1 we may use data from a larger
  sample if
• available.

32
Transformation

• In practice we might have only 2n sib-pairs to
  estimate marginal distribution. So we could use
• Transformed phenotypes are

33

• If , one can show the following
• Theorem
• as
• Observe that we essentially use van der Waerden
  normal scores rank correlation coefficient to
  measure dependence between the traits.
• Klaassen and Wellner (1997) showed that this is
  asymptotically efficient estimator of the
  correlation parameter in bivariate normal copula
  model.

34

• Hence, it is also efficient estimator of the
  maximum correlation coefficient.
• For a pair of random variables Y1 and Y2 ,
  maximum correlation coefficient is defined as
• where supremum is taken over all real
  transformations a and b such that a(Y1) and b(Y2)
  have finite nonzero variance.

35
Simulation study
36
Application - Lp(a)

• Twin data on lipoprotein levels, collected in 4
  populations in three countries (Australia, the
  Netherlands, Sweden).
• Analysis was performed using the variance
  components method and published by Beekman et al.
  (2003).

37
Ad hoc transformation
38
Lp(a) - chromosome 1
39
Lp(a) - chromosome 6
40
Discussion

• The normal copula based method has correct
  critical levels under the null hypothesis for any
  marginal distribution. Its power seems to be
  close to optimal.
• The method easily extends to general pedigrees,
  discrete data, multiple QTLs, etc.
• It is straightforward to implement in any
  existing software.
• Other families of copulas (Clayton, Gumbel, etc.)
  could be more suitable in certain applications.

41
Discrete data

• In biomedical applications, phenotypes are
  frequently measured on some ordinal scale that
  is for some natural number l
• If we want to detect if higher IBD status
  translates into more similar phenotypic values we
  may apply nonparametric methods or discretize
  some parametric family of copulas, and test if
  the parameters change with IBD status.

42
Discrete data
43
Acknowledgments

• C. Klaassen (UvA, Eurandom)
• D. Boomsma (VUA)
• M. Beekman (LUMC)
• N. Martin (Australia)
