Practical Byzantine Fault Tolerance

1
Practical Byzantine Fault Tolerance
2
Byzantine Generals Problem
3
Motivation

• Malicious attacks
• Software errors
• Faulty nodes exhibit Byzantine (arbitrary)
  behavior

4
Failures of previous algorithms

• Theoretically feasible but inefficient in
  practice
• Assumes synchrony known bounds of message
  delays and process speeds
• Synchrony assumption for correctness denial of
  service

5
Improvements in this algorithm

• Does not rely on synchrony of safety
• Magnitude order improvement
• 1 message round trip for read only operations and
  2 to read write operations
• Efficient authentication using message
  authentication codes (MAC)
• Public key cryptography

6
Contribution of paper

• First state machine replication protocol that
  survives Byzantine faults in asynchronous
  networks
• Important optimizations
• Implementation of a Byzantine fault tolerant
  distributed file system (BFS)
• Experiments that measure cost of replication
  technique

7
System Model and Assumptions

• Asynchronous distributed system nodes connected
  by network
• Independent nodes failure
• Cryptographic techniques- public key signatures,
  MAC, message digest produced by collision
  resistant hash functions
• Signing digest of message and appending to
  plaintext of message
• All replicas know each others public keys to
  verify signatures

8
Service Properties

• Safety
• - satisfies linearizability like a
  centralized system that executes operations
  atomically one at a time
• - regardless of faulty clients
• - insufficient to guard against faulty
  clients
• - limit damage by access control mechanisms


9

• Liveness
• - Must rely on synchrony
• - clients receive replicas to their requests
  if at most (n-1)/3 replicas are faulty and
  delay(t) does not grow faster than t indefinitely

• - proof for n gt 3f

10
The Algorithm

• A client sends a request to invoke a service
  operation to the primary
• The primary multicasts the request to the backups

• Replicas execute the request and send a reply to
  the client
• The client waits for f1 replies from different
  replicas with the same result this is the
  result of the opeartion

11
Normal Case Operation

• State of replica state of service , a message
  log containing messages the replica has accepted
  and no. denoting replicas current view
• The primary, p, accepts message, m , starts
  three phase protocol pre-prepare, prepare,
  commit
• Pre-prepare and prepare to order requests sent in
  same view even if primary faulty
• Prepare and commit to ensure requests that commit
  are ordered across views

12
(No Transcript)
13

• In pre-prepare phase, the primary assigns a
  sequence no. n, to the request, multicasts a
  pre-prepare message with m piggybacked to all the
  backups and appends the message to its log.
• ltltPRE-PREPARE,v,n,dgtro p,mgt
• A backup accepts a pre-prepare message provided
• The signatures in the request and the pre-prepare
  message are correct and d is the digest for m
• It is in view v
• It has not accepted a pre-prepare message for
  view v and sequence number n containing a
  different digest
• The sequence number in the pre-prepare message is
  between a low water mark h and a high water mark
  H

14

• If backup i accepts the ltltPRE-PREPARE,v,n,dgtro p
  ,mgt message, it enters the prepare phase by
  multicasting a ltPREPARE,v,n,d,igtro i message to
  all other replicas and adds both messages to its
  log
• A replica accepts prepare message if their
  signatures are correct, their view no. equals
  replicas current view, and h lt seq no lt H
• Def - Prepared(m,v,n,i) to be true iff replica i
  has inserted in its log m, pre-prepare for m in
  view v with seq n and 2f prepares from different
  backups that match the pre-prepare. The replicas
  verify if the prepares match the pre-prepare by
  same view, seq no and digest.

15

• Replica i multicasts ltCOMMIT, v,n,D(m),igtro i to
  other replicas if prepared(m,v,n,i) is true.
• Commit phase begins
• Replicas accept commit messages and insert in log
  if properly signed, view no. in message is equal
  to the replicas current view and hltseq no ltH

16

• Def - committed(m,v,n) is true iff
  prepared(m,v,n,i) is true for all i in some set
  of f1 non-faulty replicas
• Def - committed-local(m,v,n,i) is true iff
  prepared(m,v,n,i) is true and i has accepted 2f1
  commits from different replicas that match the
  pre-prepare for m
• A commit matches a pre-prepare if they have same
  view, seq no. and digest
• If committed-local(m,v,n,i) is true for some
  non-faulty i then committed(m,v,n) is true.
• It ensures that non-faulty replicas agree on the
  sequence nos of requests that commit locally even
  if they commit in different views at each replica

• Also any request that commits locally at a
  non-faulty replica will commit at f1 or more
  non-faulty replicas eventually.
• Each replica i executes the operation requested
  by m after committed-local(m,v,n,i) is true and
  is state reflects the sequential execution of
  all requests with lower sequence numbers ensuring
  that all non-faulty replicas execute requests in
  the same order as required to provide the safety
  property.
• After executing the requested operation replicas
  send a reply to the client.

17
Garbage Collection

• Periodical generation of proofs
• Checkpoints and stable checkpoints (checkpoint
  with proof of 2f1 messages)
• Discards pre-prepare, prepare, commit messages lt
  n from log and earlier checkpoints and checkpoint
  messages
• Lower water mark h sequence no. of last stable
  checkpoint
• Higher water mark H hk k big enough not to
  stall waiting for checkpoint to be stable

18
View Changes

• VIEW CHANGE MESSAGE
• NEW VIEW NESSAGE

19
Correctness

• Safety
• - If all non-faulty replicas agree on the
  sequence nos. of requests that commit locally.
• In same view
• In different views

20

• Liveness
• - Avoid starting a view change soon
• - Prevents the next view change too late
• - Unable to impede progress by forcing frequent
  view changes

21
Optimization

• Avoid sending most large replies
• Reduces no. of message delays for an operation
  from 5 to 4
• Improves the performance of read only operations
  that do not modify the service state.
• Cryptography
• - use digital signatures for view change and
  new view messages
• - all others use message authentication codes
  (MAC)
• - less storage for MAC

22
Implementation and Results

• BFS , a byzantine fault tolerant NFS service
  using the replication library
• The performance of BFS is 3 worse than standard
  NFS implementation in Digital Unix
• Can not mask errors at all replicas
• Mask errors that occur independently at different
  replicas including non-deterministic software
  errors

23
Conclusions

• First to work correctly in an asynchronous system
• Improves the previous algorithms by more than an
  order of magnitude

24
Future Work

• Problem of fault tolerance privacy
• Reducing the amount of resources required by
  system
• - no of replicas
• - no of copies of state to f1

25

• Thanks for being patient!!
