From Byzantine Agreement to Practical survivability

1
From Byzantine Agreement to Practical
survivability

• Dahlia Malkhi
• The Hebrew University of Jerusalem

2
Why Replicate?

• Cache data
• NFS, DNS, WWW
• Fault tolerance
• Clusters
• Remote backup

3
A replication system

• Servers store x and timestamp t, both initially -

x - t -
x - t -
x - t -
x - t -
x - t -
4
A replication system

• Clients update new values other clients obtain
  them

x 7
x 7, t 1
5
Active State Machine Replication

• Method for consistently replicating arbitrarily
  typed objects
• Start from the same initial state
• Apply operations in the same order without gaps
  at each replica

a
a
a
b
b
c
6
A replication system

• The decentralized approach
• Each server contends for next operation
• When all proposals are collected, everyone decides

x 7, t 1
x 3, t 1
7
A simple ordering protocol

• Each server proposes a value in each round

X7,t1 X8,t2
X7
X8
none
none
none
X9,t3 X1,t4 X3,t5
none
none
X1
X3
X9
8
Analysis of simple protocol

• Each delivery may cost N messages
• cost is amortized during busy times
• Need to respond to each failure
• Reconfigure costly agreement on membership

9
Searching for efficient replication

• The leader-based approach
• Client sends write to leader, leader broadcasts
  to everybody
• Leader may rotate, dynamically change, etc.

x 7, t 1
10
Group communication

• Leader sets order
• variations revolving token, dynamic leader

X7,t1
11
Analysis of Group Communication

• Without further interaction, delivery is
  optimistic and may lead to inconsistency
• Need to respond to leader failure
• Costly agreement on membership
• Virtual synchrony simplify recovery from
  partitioned views

12
Where the costs hurt

• Servers need to monitor for failures
• Reconfiguration
• Recovery from optimistic delivery

13
Some design choices

• Scale
• Survivability
• Trusted clients

14
Why scalability?

• Yesterday
• NFS
• Fault tolerant replicated file system (cluster)
• Four computers flying a shuttle
• Today
• Digital archiving Andersons Eternity
• Ubiquitous computing
• Peer-to-peer resource sharing
• eCommerce and eApplication on the Internet

A mobile user
15
Electronic voting system

• Develop electronic voting system for national
  elections
• Build on experience with Costa Rica Project (with
  ATT Secure Systems Research Dept)
• Goals
• vote from any polling station
• usable by all voters
• security
• double voting, voter privacy, vote coercion, ...

16
Preventing double voting

• Scope 3,000,000 voters,1000 polling stations
• Simple problem Prevent using voter id twice
• For privacy, binding between vote voter id is
  not kept
• detecting double voting afterwards doesnt help
• Globally permanently lock voter id when vote is
  cast
• Centralized server or global protocol is no good
• lose availability, performance
• Need scalable, survivable solution!

17
Why survivability?

• Yesterday
• Closely coupled, locally administered system
• Today
• Wide spread computing
• Internet hackers
• More

18
(No Transcript)
19
(No Transcript)
20
Survivable systems

• The last frontier of protection
• Component penetrations will occur, so we should
  build systems to anticipate them
• Survivable system makes meaningful progress when
  components fail to behave as expected, even when
  they conspire to undermine the operation of the
  system as a whole

21
(No Transcript)
22
Could clients be faulty?

• Benign faults yes
• Byzantine faults no
• Employ access control
• If bypassed, who cares?
• A malicious client can mess up the data anyway

23
Summary of design choices

• Scaling
• thousands of servers, millions of clients
• Survivability
• Servers may be penetrated, hence use voting
• Trusted clients

24
From replicated process to replicated storage
model

• Fault-tolerant computing in Storage Area Networks
• Fault-tolerant client/server computing with
  passive servers
• Servers are playing the role of data stores
• Servers are not communicating with one another
• Protocols are carried out by clients

25
Byzantine quorum systems example Malkhi and
Reiter 98

• At most one server can be penetrated
• Read/write safe register

26
Byzantine quorum systems example

• At most one server can be penetrated
• Read/write safe register

27
Masking quorums

• A b-masking quorum system over a universe U of
  servers is a set such that

• Justification let B be set of actually faulty
  servers

28
Replication using masking quorum systems

• Write(v)
• Read timestamps from quorum
• Choose higher, unique timestamp
• Read()
• Read (value, timestamp) pairs from quorum
• Identify correct values that appear b1
  identical times
• Return highest-timestamp correct value

29
Byzantine Quorums - surprisingly
efficientMalkhi, Reiter and Wool 98
30
Quorum-based replicationFleet, Malkhi and
Reiter 00
Persistent object servers
Server 1
Server 3
Server 2
Server 4
Server 5
No centralized management No locking No
server-to-server interaction No client-to-client
interaction Quorum tuning - benign/Byzantine
faults - strict/probabilistic
guarantees Simple, secure, modular
Q-RPC
Q-RPC
Object-stub
Object-stub
application
application
Client 1
Client 2
31
Universal object emulation
Servers are data containers
Determine total order of object-operations
x.a()
x.b()
32
The Approach Lamport 98
PAXOS

• Assume a weak leader election primitive
• Eventually there is a unique leader
• ? failure detector, partially synchronous/timed
  asynchronous systems, etc.
• To order operations, the leader invokes an
  instance of the agreement protocol
• Never disagree on the operation order
• Might fail to make progress if there is no unique
  leader

33
Identifying an agreement building-block
34
Adding Ranks (ballots)
35
Ranked Register Boichat et al. 02, Chockler and
Malkhi 02

• The interface
• rr-read(R), returns ltr,vgt
• rr-write(R,v), commits or aborts

• The Paxos Agreement
• Collect proposals with a rank
• Make a new proposal with a rank

• If rr-write with rank R1 commits, then rr-read
  with rank R2gtR1 must see it
• return the value written by this rr-write (or by
  a write with rank Rgt R1)

36
Agreement using RR
Shared A single ranked register propose(inp) wh
ile (true) do choose a unique monotonically
increasing rank R ltr,vgtrr-read(R) if
(v ) vinp if (rr-write(R,v)
commit) return v od
37
The complete system
RR
RR
38
Implementability of RR
39
Some historical quotes

• The Byzantine agreement problem has received
  more attention from the computer science
  community than any other problem
• Chor and Dwork, 89
• Essay on the Application of Analysis to the
  Probability of Majority Decisions
• Condorcet, 85
• Only five computers would be needed for the
  entire country
• Thomas Watson Sr., 1943

40
More quotes

• The challenge of reliability in distributed
  computing is perhaps the unavoidable challenge of
  the coming decade, just as performance was the
  challenge of the past decade
• Ken Birman, 1996

41
Why is this working?
42
Replication models
43
Operation ordering

• Easy if there are no failures and/or the system
  is synchronous
• E.g., leader based, LTS based
• Real systems are both asynchronous and
  failure-prone
• Accurate failure detection is impossible
  multiple/no leaders might exist at times
• Solution

PAXOS
44
Fault-tolerant client/server (1)

• Scalable dynamic fault-tolerant services (e.g.,
  Fleet)
• Replication groups are created on-the-fly by
  clients out of dynamic server universe
• Servers need neither monitor nor be aware of each
  other
• Accommodates Byzantine failures
• Database servers
• Client-server middleware

45
Paxos in Replicated Storage Model
client
client
client
46
Disk Paxos Pros and Cons

• Assumes very weak memory objects
• Regular registers
• Not suitable for dynamic environments
• The number of clients and their Ids are known a
  priori
• Employs data structure whose size grows with the
  number of clients

47
Our Contribution

• Identified an abstract building block for Paxos
  agreement
• Ranked register (RR)
• Follows deconstruction of BG.. (round-based
  register )
• Implemented RR in a setting with infinitely many
  dynamic client processes
• Proven a lower bound on number of R/W registers

48
Identifying an agreement building block
Propose(V) Begin RMW if (val
) valV return val End RMW
consensus
RMW

• Agreement is trivial with a single RMW
• RMW cannot be emulated out of faulty memory
  objects of any type Jayanti, Chandra, Toueg 9?

49
Conclusions and Future Work

• Paxos with infinitely many processes based on new
  ranked register abstraction
• Fault-tolerant replication in SANs
• Fault-tolerant client/server applications
• Future work
• Handling Byzantine memory failures (NR-arbitrary)
• Specifying/implementing the leader election
  primitive
