Lecture 8 Iterative systems of Equations

1
Lecture 8 - Iterative systems of Equations

• CVEN 302
• June 11, 2001

2
Lectures Goals

• Iterative Techniques
• Jacobian method
• Gaus-Siedel method
• Relaxation technique

3
Iterative Techniques

• The method of solving simultaneous linear
  algebraic equations using Gaussian Elimination
  and the Gauss-Jordan Method. These techniques
  are known as direct methods. Problems can arise
  from round-off errors and zero on the diagonal.
• One means of obtaining an approximate solution to
  the equations is to use an educated guess.

4
Iterative Methods

• We will look at three iterative methods
• Jacobi Method
• Gauss-Seidel Method
• Successive over Relaxation (SOR)

5
Convergence Restrictions

• There are two conditions for the iterative method
  to converge.
• Necessary that 1 coefficient in each equation is
  dominate.
• The sufficient condition is that the diagonal is
  dominate.

6
Jacobi Iteration

• If the diagonal is dominant, the matrix can be
  rewritten in the following form

7
Jacobi Iteration

• The technique can be rewritten in a shorthand
  fashion, where D is the diagonal, A is the
  matrix without the diagonal and c is the
  right-hand side of the equations.

8
Jacobi Iteration

• The technique solves for the entire set of x
  values for each iteration.
• The problem does not update the values until an
  iteration is completed.

9
Example (Jacobi Iteration)

• 4X1 2X2 2
• 2X1 10X2 4X3 6
• 4X2 5X3 5
• Solution (X1 , X2 , X3 ) (0.41379, 0.17241,
  0.86206)

10
Jacobi Example
11
Jacobi Example
12
Jacobi Example

• Formulation of the matrix

13
Jacobi Iteration

• Iteration 1 2 3 4 5 6 7
• X 1 0.5 0.2 0.45 0.324 0.429 0.376 0.42
• X 2 0.6 0.1 0.352 0.142 0.248 0.16 0.204
• X 3 1 0.52 0.92 0.718 0.886 0.802 0.872

14
Jacobi Program

• The computer program is setup to do the Jacobi
  method for any size square matrix
• Jacobi(A,b)
• The program can has options for maximum number of
  iterations, nmax, and tolerance, tol.
• Jacobi(A,b,nmax,tol)

15
Gauss-Seidel Iterations

• The Gauss-Seidel / Seidel technique is similar to
  the Jacobi iteration technique with one
  difference.
• The method updates the results continuously. It
  uses the new information from the previous
  iteration to accelerate converge to a solution.

16
Gauss-Seidel Model

• The Gauss-Seidel Algorithm
• The combined vector is upgraded ever term.

17
Example (Gauss-Seidel Iteration)

• 4X1 2X2 2
• 2X1 10X2 4X3 6
• 4X2 5X3 5
• Solution (X1 , X2 , X3 ) (0.41379, 0.17241,
  0.86206)

18
Gauss-Seidel Example

• Formulation of the matrix problem

19
Gauss-Seidel Iteration

• Iteration 1 2 3 4 5 6 7
• X 1 0.5 0.25 0.345 0.384 0.401 0.408 0.411
• X 2 0.5 0.31 0.231 0.197 0.183 0.177 0.175 X
  3 0.6 0.75 0.815 0.842 0.854 0.858 0.858

20
Gauss-Seidel Model

• The computer program is setup to do the
  Gauss-Seidel method for any size square matrix
• Seidel(A,b)
• The program can has options for maximum number of
  iterations, nmax, and tolerance, tol.
• Seidel(A,b,nmax,tol)

21
Example - Iteration with no diagonal domination

• 3X1 - 3X2 5X3 4
• X1 2X2 - 6X3 3
• 2X1 - X2 3X3 1
• Solution (X1 , X2 , X3 ) (1.00, -2.00, -1.00)

22
Using the GS algorithm

• Using the Gauss-Seidel Program with the
  following A matrix and b vector.
• Solution (X1 , X2 , X3 ) (1.00, -2.00, -1.00)

23
Gauss-Seidel Example
24
Gauss-Seidel Example

• Program will work with the equations

25
Using a Gauss-Seidel Iteration

• Iteration 1 2 3 4 5 6
  7
• X 1 1.33 2.630 3.412 2.296 -1.375 6.078
  -7.620
• X 2 0.833 -0.648 -5.113 -10.584
  -11.989 -3.698 14.769
• X 3 -0.278 -1.635 -3.645 -4.725 -2.746 3.153
  10.336

26
Successive over Relaxation

• The technique is a modification on the
  Gauss-Seidel method with an additional parameter,
  w, that may accelerate the convergence of the
  iterations.
• The weighting parameter, w, has two ranges 0 lt w
  lt1, and 1lt w lt2. If w 1, then the problem is
  the Gauss-Seidel technique.

27
SOR Method

• The SOR algorithm is defined as
• The difference is the weighting parameter, w.

28
The Weighting Parameter

• If the parameter, w is under 1, the residuals
  will be under-relaxed.
• If the parameter, w 1, the residuals are equal
  to a Gauss-Seidel model.
• If 1lt w lt 2 the residuals will be over-relaxed
  and will general help accelerate the convergence
  of the solution.

29
Example of SOR

• 4X1 2X2 2
• 2X1 10X2 4X3 6
• 4X2 5X3 5
• Solution (X1 , X2 , X3 ) (0.41379, 0.17241,
  0.86206)

30
SOR Example

• Formulation of the SOR Algorithm

31
Effects of w Parameter

• Using the SOR program SOR(A,b,w,nmax,tol) with
  nmax50 and tol 0.000001

32
Summary

• Convergence conditions need to be met in-order
  for iterative techniques to converge
• Jacobi method upgrades the values after each
  iteration.
• Gauss-Seidel upgrades continuously through
  method.
• SOR (Successive over Relaxation) uses the
  residuals to accelerate the convergence.

33
Homework

• Check the Homework webpage
