TCP Flooding

1
TCP Flooding
2
TCP handshake
3
TCP handshake

• What is stored at the server in the handshake?
• TCP Control Block (TCB) keeps track of what the
  server agreed to
• gt 280 bytes
• FlowID, timer info, Sequence number, flow control
  status, out-of-band data, MSS, other options
  agreed to
• Half-open TCB entries exist until timeout
• Fixed bound on half-open connections
• Resources exhausted ? requests rejected

4
SYN Flooding
5
TCP SYN flooding

• Basic problem
• No client authentication of packets before
  resources allocated
• Attacker sends many connection requests
• Spoofed source addresses
• RSTs quickly generated if source address exists
• No reply for non-existent sources
• Attacker exhausts TCP buffer to w/ half-open
  connections

6
TCP SYN flooding
TCP Buffers
169.237.5.23
168.150.241.155
169.237.7.114
7
SYN-flood
TCP Buffers
128.120.254.1
128.120.254.2
128.120.254.3
128.120.254.4
128.120.254.5
128.120.254.6
128.120.254.7
128.120.254.8
128.120.254.9
128.120.254.10
128.120.254.11
128.120.254.12
128.120.254.13
128.120.254.14
169.237.7.114
128.120.254.15
8
TCP SYN flooding counter-measures

• End host
• Reduce half-open timeout value
• May deny legitimate access
• Increase backlog queue
• Increase in resource usage
• Disable non-essential services
• Router
• Ingress filtering to prevent spoofing

9
TCP SYN flooding counter-measures

• Firewall
• Full connection proxy
• Terminates handshake, re-establishes connection
  on valid 3-way handshake
• Must not be vulnerable to SYN flooding?
• Must translate each subsequent packet
• Semi-transparent
• Spoofs ACKs optimistically when receiving SYN/ACK
• Subsequent (duplicate) ACK let through or RST
  generated if ACK not received

10
TCP SYN flooding counter-measures

• Active monitoring (synkill)
• synkill
• keep track of source IP addresses
• null (never seen), good (seen to be OK before)
• new (seen, but not sure yet if spoofed)
• bad (non-existent, 0.0.0.0, 127.0.0.0, 10.0.0.0,
  192.168.0.0, etc.)
• Send RST packets for bad source IP addresses
• Send ACK packets for new, potentially spoofed IP
  addresses
• degrade service if you can't tell for sure
• if ACK or RST received, place in good
• if ACK or RST not observed, reclassify IP as bad
• Reclassify periodically
• ACK/RST spoofing is a problem

11
TCP SYN cookies

• General idea
• Client sends SYN w/ ACK number
• Server responds to Client with SYN-ACK cookie
• sqn f(src addr, src port, dest addr, dest port,
  rand)
• Server does not save state
• Honest client responds with ACK(sqn)
• Server checks response
• If matches SYN-ACK, establishes connection

12
TCP SYN cookie

• Server's TCP SYN/ACK seqno encodes a cookie
• seqno 32-bits
• t mod 32 gt counter to ensure seqno's increase
  every 64sec
• MSS gt encoding of server MSS (can only have 8
  settings)
• Cookie gt easy to create and validate, hard to
  forge blindly

32
0
t mod 32
MSS
CookieHMAC(t, Ns, SIP, SPort, DIP, DPort)
5 bits
3 bits
13
SYN-Cookies

• Modified TCP Handshake
• Example of stateless handshake
• client
• sends SYN packet and ACK number to server
• waits for SYN-ACK from server w/ matching ACK
  number
• server
• responds w/ SYN-ACK packet w/ initial SYN-cookie
  sequence number
• Sequence number is cryptographically generated
  value based on client address, port, and time.
• No TCP buffers are allocated
• client
• sends ACK to server w/ matching sequence number
• server
• If ACK is to an unopened socket, server validates
  returned sequence number as SYN-cookie
• If value is reasonable, a buffer is allocated and
  socket is opened.
• .
• Spoofed packets will not consume TCP buffers

SYN ack-number
SYN-ACK seq-number as SYN-cookie, ack-number NO
BUFFER ALLOCATED
ACK seq_number ack-numberdata
SYN-ACK seq-number, ack-number TCP BUFFER
ALLOCATED
14
Status?

• Support exists in all modern operating systems
• Not turned on by default....Why?
• Not sure, but it...
• May break some options such as large windows
• Assumes TCP parameters that are negotiated do not
  change

15
Cookies for the bad guy

• TCP SYN cookies
• Used by good guy to securely keep track of valid
  half-open connections using constant-state at the
  server
• Encode information in destination seqno
• Inverse TCP SYN cookies
• Used by bad guy to securely keep track of valid
  half-open connections using constant-state at the
  client
• Encode information in the source port/seqno
• Allows for high-speed scanning
