Proposed FIA DWM protocol

1
Proposed FIA DWM protocol

• July 2009

2
Why a P2-DWM protocol?

• Increasing need for information about the DWM
  biomass and carbon pool
• Desire for national protocol, with less effort
  needed than for P3 DWM
• Desire for national consistency
• Desire rapid assessments (e.g. MS hurricane)
  option

3
Why a new DWM protocol design effort?

• Desire for more details on what we gain/lose by
  using different variables or transect
  configurations
• Based on FIA information needs
• Design guided by empirical data
• Integrated with current P3 DWM protocol (MT
  Direction develop a P2 DWM protocol that is a
  subset of P3 DWM protocols and also address and
  correct whatever P3 DWM protocols problems are
  identified in the re-work process)

4
FIA Information Needs

• Volume, biomass, carbon
• Fuel Loading Biomass per acre
• Wildlife/Ecological CWM length per acre
  number of logs by large-end diameter

5
Results of Analyses

• Estimates and variance minimally affected by
  transect configuration transect orientation,
  location, or multiple piece crossings.
• Length is the primary factor for reducing
  variance.
• Additional plots buys more than adding transects
  or transect lengths to fewer plots.
• Estimates are sensitive to log and FWM
  inclination, decay class biomass reduction
  factors, and other compilation assumptions.

6
How does the proposed design integrate P2 and P3
DWM?

• Three Protocol Options
• Protocol Improvements

7
PROTOCOL OPTIONS

• OPTION I. BASE (CORE-OPTIONAL PROTOCOL for P2
  Plots) Provides information about volume,
  biomass, carbon, and fuel load per acre,
  addressing the primary FIA information needs.

8
PROTOCOL OPTIONS

• OPTION I. BASE (CORE-OPTIONAL PROTOCOL for P2
  Plots) Provides information about volume,
  biomass, carbon, and fuel load per acre,
  addressing the primary FIA information needs.
• OPTION II. WILDLIFE/ECOLOGICAL (CORE PROTOCOL for
  P3 Plots) Captures additional CWM structural
  information to address wildlife questions.

9
PROTOCOL OPTIONS

• OPTION I. BASE (CORE-OPTIONAL PROTOCOL for P2
  Plots) Provides information about volume,
  biomass, carbon, and fuel load per acre,
  addressing the primary FIA information needs.
• OPTION II. WILDLIFE/ECOLOGICAL (CORE PROTOCOL for
  P3 Plots) Captures additional CWM structural
  information to address wildlife questions.
• OPTION III. RAPID ASSESSMENT (CUSTOMIZED
  PROTOCOL) Accommodates the need for a temporary
  response to significant events allows
  customization of the protocol for assessment
  information needs.

10
Measured variables

• Base protocol (P2) addresses volume, biomass,
  carbon, and fuel load per acre with these
  variables CWM species, decay class, and
  intersect diameter FWM counts and litter/duff
  depth.
• Wildlife/Eco package (P3) to get CWM size class
  data, density(logs/ac), and cavity info large
  small end diameter, length, and hollow cavities.
• Any non-base CWM variable can be measured as an
  optional add-on (e.g. large-end diameter or
  length).
• Some non-base, dropped CWM variables are
  preserved and available for optional add-ons as
  desired e.g., CWM history, log charred by fire.

11
Protocol Improvements

• Pile measurement simplified moved to transect
  cross-section instead of subplot 3-D volume
  estimate.
• Microplot fuels and fuelbed depth dropped from
  all options optional fuelbed ID from Scott
  Burgan (2005 RMRS-GTR-153) photo-series
  provided.
• Duff and litter depth non-sampled status
  clarified.
• Improved compilation parameters included.
• Further research needs highlighted.

12
Proposed transect design

• Two 24 transects per subplot (transects start at
  subplot center). Transects connect to form a
  straight-line across subplot (reduces multiple
  intersections of same piece).
• New transect azimuths more balanced than choosing
  2 transects/subplot from the current P3 design.
• Transects may be extended onto macroplot if
  macroplot is mapped and extra length desired.
• A third 24 transect may be added if maintaining
  transect length is important (e.g. to finish a P3
  cycle using current design).

13
Proposed DWM Protocol
14
Strengths of the proposed transect design

• Minimizes orientation bias
• Reduces multiple intersections of the same piece
  by different transects
• Gain in field efficiency
• P2 / P3 integration

15
Rapid assessment options for specific events

• Can customize to meet local needs
• Can select any combination of 1 to 4
• subplots
• Can select any combination or number
• of transects
• Choices are documented in columns on
• PLOT table, for compilation purposes

16
Change Analysis

• Line Intersect Sampling of DWM does not lend
  itself to change analysis.
• DWM protocols do not track individual pieces
  estimates of change on the plot are based on the
  difference in volume/biomass/carbon at the plot
  level between time 1 and time 2.
• Variance of the change estimates may be higher
  for measurements taken on different transect
  layout.

17
Example of length effect on variance
18
Example of piece inclination effect on expansion
Inclination0, expansion1.0
transect plane
selection probability length10 ft
transect plane
Inclination35, expansion1.22
Inclination matters whether piece is supported or
on a slope Inclination matters for both CWM and
FWM Likely bias could be underestimating CWM by
5
selection probability length8.2 ft
19
THE NITTY GRITTY 1 CWM
20
THE NITTY GRITTY 2 CWM IN RESIDUE PILES
21
THE NITTY GRITTY 3 FWM DUFF / LITTER DEPTHS
22
THE NITTY GRITTY 4 PLOT-COND-SEGMENTS
23
THE NITTY GRITTY 5 FUEL LOADING ON MICROPLOT
