Chapter 6 Color

1
Chapter 6Color

• Multimedia Systems

2
Key Points

• Colour is a subjective sensation produced in the
  brain.
• The measurable physical quantity that best models
  colour is a spectral power distribution (SPD).
• In the RGB colour model, a colour is represented
  by three values, giving the proportions of red
  (R), green (G) and blue (B) light which make up
  light of the desired colour.

3
Key Points

• The RGB colour gamut is a proper subset of the
  visible colours.
• The colour depth of an image is number of bits
  used to hold a colour value.
• Indexed colour The stored 8-bit value is used as
  an offset into a colour lookup table (CLUT) or
  palette containing up to 256 24-bit colour
  values.

4
Key Points

• Dithering helps avoid the posterization that can
  occur when indexed colour is used, by using
  patterns of dots to simulate a wider range of
  colours using optical mixing.
• The CMYK model is important for printing, as it
  models the way colour is produced by mixing ink
  or paint.
• Other colour models include HSV, YUV and its
  variants, and the CIE device-independent spaces
  Lab and Luv.

5
Key Points

• A 24-bit image can be thought of as being made up
  of three 8-bit channels, one each for red, green
  and blue in RGB colour.Colour correction etc.
  can be performed by using techniques from Chapter
  5 on individual channels.
• Colour management software uses device profiles
  to help maintain consistent colour.

6
Color Science

• Color is a subjective sensation produced in the
  brain.

7
Color Science

• Light is a form of electromagnetic radiation, we
  can measure its wavelength.
• http//micro.magnet.fsu.edu/primer/lightandcolor/i
  ndex.html

8
Microwave Ovens

• The wavelength is tuned to frequencies that are
  readily absorbed by water molecules in food
  causing them to absorb energy and release heat as
  they vibrate.
• Containers holding the food in microwave ovens
  usually contain very little water and tend to
  remain cool.

9
Color Science

• Visible light (???) 400nm700nm

10
Color Science

• Spectral power distribution (SPD)

11
Color Science

• Receptor Cells
• Rods night-vision and cannot distinguish color
• Cones in three sorts which respond to different
  wavelengths

12
Cone Response
13
Tristimulus Theory

• Any colors can be specified by just three values,
  giving weights of three components.
• Each type of cone responds to R, G, B

14
Primary Colors

• Additive mixing
• TV, monitors
• Subtractive mixing
• Paint absorbs light

15
Color Temperature

• The color temperature model is based on the
  relationship between the temperature of a
  theoretical standardized material, called a black
  body radiator, and the energy distribution of its
  emitted light as the radiator is brought to
  increasingly higher temperatures, measured in
  Kelvin (K).
• Although this radiator does not exist, many
  metals behave very similar to a black body so we
  can take a metal pot as an example for this
  discussion.

16
Color Temperature
17
RGB Colors

• RGB color model
• Not possible to represent all visible color as a
  combination of fixed R, G, B.

18
Other Color Spaces
19
Color Depth

• Color depth
• 24, 30, 36, 48 bits
• Grey scale image RGB
• PNG format up to 48 bits
• Scanner 48 bits
• Accurate approximations when reduced to a lower
  resolution for display
• Millions of colors, true color 24 bitsThousands
  of colors, hi-color 16 bits256 colors 8 bits
• Grey-level 256 8 bits

20
Indexed Color

• Direct color
• Indexed color
• Palette of 256 colors
• Color lookup table (CLUT)
• Logical colors gt physical colors
• 24 bits color gt indexed color
• 1/3 of data
• PNG, BMP, TGA, TIFF paletteGIF only 256 colors
  JPEG 24 bit color
• Missing color the nearest color
• Visible artifacts
• Posterization gradations replace by sharp
  boundaries
• Web-safe Palette
• 216 colors, Displayed on any platform

21
Posterization

• Area of a single color are replaced by a pattern
  of dots of several colors
• Pink red white
• Dithering high resolution
• Halftoning greyscale images
• N by N pixels N21 grey levels

22
Other Color Models

• CMYK
• C GB W-RM RB W-GY RG W-B
• Complementary color
• Art and design
• The dyes do not supply color to light reflected
  off surface, but to light that penetrates through
  them and gets reflected or scattered back from
  beneath it.

23
Mixing Colored Inks
White light
White light
Cyan light
Cyan light
Absorption of green light
Absorption of red light
Cyan ink
Magenta
Absorption of red light
Cyan ink
24

• Not possible to manufacture inks which absorb
  only light of precisely the complementary
  color.Some unwanted colors are absorbed.
• RGB gamut gt CMY gamut
• CMM ! perfect black
• With black CMYK
• Hue, saturation, brightness
• As white is mixed in, saturation decreases.

25
Color wheel
26
HSV
27
Color Pickers
28
Color Differences

• Brightness(RGB)/3
• LuminanceY0.2125R 0.7154G 0.0721BGreen
  contributes far more
• Color differences
• UB-Y and VR-Y
• YUV
• YCBCR

29
Device-independent Color Spaces

• RGB, CMYK device-dependent
• CIE XYZ device-independent
• Not perceptually uniformthe same change in one
  of vales produced the same change in
  appearanceR (1 to 11) ! (101 to 111)
• Perceptually uniform
• CIE Lab as in CMYK for prepress industry
• CIE Luv as in RGB for monitors and scanners

30
Channels and Color Correction

• Color images R B C channels
• Each channel can be manipulated separately.
• Color correction
• Compensate for the deficiencies of scanners and
  other input devices
• Time-consuming
• Wizards, assistants

31
Color Correction

• Color balance hue saturation adjustment
• Color balance
• 3 sliders CR, MG, YB

32

• Replace a specified color with a different color
• CMYK printing YCBCR video
• Alpha channeldifferent from color channels
• Blue screen alpha blue channel
• Mask out background
• JPEG process each channel separately
• YCBCR downsample color difference

33
Consistent Color

• Color profiles
• White(255,255,255)specified in a
  device-independent color space
• Gamma

34
Gamma Correction
Sample Input
Graph of Input
Gamma Corrected Input
Graph of Correction L' L (1/2.5)
Monitor Output
Graph of Output
35
Color Profile

• EPS, TIFF JFIF, PNG color profile
• At least R, G, B, white point, gamma
• Fig. 6.13

36
(No Transcript)
37
ICC

• International Color Consortium
• Apples ColorSync
• Kodak Precision Color Management System
• TIFF, EPS complete ICC profiles
• sRGB standard RGB
• ITU-R BT.709 standard
• Gamma2.2 and white point 6500 K
