Security and Certification; Authentication and Authorization

1
Security and Certification Authentication and
Authorization

• Assaf Gottlieb
• EGEE Training Team

EGEE is funded by the European Union under
contract IST-2003-508833
2
Acknowledgements

• Some of these slides have been taken from a
  longer presentation by Mike Jones of the
  University of Manchester.
• Prepared by John Kewley, CCLRC Daresbury
  Laboratory

3
Goals of this module

• Describe
• Security basics
• Use of Certificates
• Importance of Certificate Authorities

4
Overview

• Introduction to Security
• Public/private keys in action
• Certificates
• Certificate Authorities

5
Introduction to Security

• What aspects of security should we be concerned
  about?
• Authentication (Identification)
• Confidentiality (Privacy)
• Integrity (non-Tampering)
• Authorization
• Also
• Accounting
• Delegation
• Non-Repudiation

6
Tools of the trade

• Encryption
• Secret symmetric key both parties need to
  share the key
• DES, RC4
• Comparatively efficient
• Public/private key asymmetric - 2 keys
  mathematically related
• RSA, DSA
• Slower
• Oneway hash / message digest
• MD5, SHA-1
• fast

7
Gbbyf bs gur genqr

• Rapelcgvba
• Frpergt flzzrgevp xrl obgu cnegvrf arrq gb
  funer gur xrl
• QRF, EP4
• Pbzcnengviryl rssvpvrag
• Choyvp/cevingr xrl nflzzrgevp - 2 xrlf
  zngurzngvpnyyl eryngrq
• EFN, QFN
• Fybjre
• Barjnl unfu / zrffntr qvtrfg
• ZQ5, FUN-1
• Snfg

8
Tools of the trade

• Encryption
• Secret symmetric key both parties need to
  share the key
• DES, RC4
• Comparatively efficient
• Public/private key asymmetric - 2 keys
  mathematically related
• RSA, DSA
• Slower
• Oneway hash / message digest
• MD5, SHA-1
• fast

9
Encrypting for Confidentiality (1)

• Sending a message using symmetric keys
• Encrypt message using shared key
• Send encrypted message
• Receiver decrypts message using shared key
• Only someone with shared key can decrypt message
• But how do the keys get shared?

Sender space
Receiver space
Public space
key
key
hR3a rearj
hR3a rearj
hR3a rearj
openssl
openssl
2
3
1
Hello World
Hello World
10
Encrypting for Confidentiality(2)

• Sending a message using asymmetric keys
• Encrypt message using Receivers public key
• Send encrypted message
• Receiver decrypts message using own private key
• Only someone with Receivers private key can
  decrypt message

Receiver space
Public space
Sender space
Private Key
Public Key
Receivers Public Key
Receivers Public Key
3
hR3a rearj
hR3a rearj
openssl
openssl
2
hR3a rearj
1
Hello World
Hello World
11
Signing for Authentication

• Encrypt message with Senders private key
• Send encrypted message
• Message is readable by ANYONE with Senders
  public key
• Receiver decrypts message with Senders public
  key
• Receiver can be confident that only someone with
  Senders private key
• could have sent the message

Public space
Sender space
Receiver space
Senders Public Key
Senders Public Key
Public Key
Private Key
3
openssl
1
openssl
n52krj rer
n52krj rer
openssl
Hello World
4
2
n52krj rer
Hello World
Hello World
12
Certificates

• A statement from someone else (the Certificate
  Authority), that your public key (and hence your
  private key) is associated with your identity
• A certificate can be checked if you have the
  public key of the party who signed it

13
Certificate Authority

• A Certificate Authority (CA) issues you your
  certificates.
• By signing them it is able to vouch for you to
  third parties
• In return for this service, you must provide
  appropriate documentary evidence of identity when
  you apply for a certificate through a
  Registration Authority (RA)

14
Certificate contents

• The certificate that you present to others
  contains
• Your distinguished name (DN)
• Your public key
• The identity of the CA who issued the certificate
• Its expiry date
• Digital signature of the CA which issued it

15
The Full Monty

• Server authenticates Client
• Client authenticates Server
• (Symmetric) Session key exchanged confidentially
  using public key mechanism
• Secure session can now commence using more
  efficient, agreed session key
• Secure messages will also contain a message
  digest to ensure integrity

16
The Israeli Certificate Authority

• Each university has one authorized RA.
• The CA is located at the Computer Science
  department at Tel Aviv University
• Supply appropriate documentary evidence of your
  identity to the RA
• Once documentary and RA assurance is supplied to
  the CA, a certificate is supplied to you
• A public/private key is generated for you as part
  of the certificate. Your private key will be put
  on a floppy disk

17
Summary

• We have looked at
• Security basics
• Use of Certificates
• Importance of Certification Authorities
