Motion From 2D Image Sequences

1
Motion From 2D Image Sequences
Dr. Ramprasad Bala Computer and Information
Science UMASS Dartmouth CIS 585 Image
Processing and Machine Vision
2
Motion Analysis

• A changing scene may be observed via a sequence
  of images.
• Motion can be observed due to motion of the
  objects or observer (camera motion) or both.
• Changes in a scene provide features for detecting
  objects that are moving or computing their
  trajectories.

3
Motion Phenomena

• Four general cases of motion
• Still camera, single moving object, constant
  background
• Still camera, several moving objects, constant
  background
• Moving camera, relatively constant scene
• Moving camera, several moving objects.

4
Motion Applications

• The simplest application is the detection of
  motion in a constant background
• Security checkpoints or automatically switching
  light on
• Tracking of objects or people
• Objects or people can be tracked over time to
  predict trajectories. Multiple cameras can be
  used to predict 3D motion.

5
Motion Applications

• A moving camera creates image changes, even if
  the 3D scene is static
• Create more observations of the scene than a
  single static camera
• Makes possible computation of relative depth,
  objects closer tend to change faster.
• Provide perception and measurement of 3D shape of
  nearby objects triangulation similar to stereo
  vision.

6
Motion Applications

• The most difficult motion problem involves moving
  sensors and scenes containing so many moving
  objects that it is difficult to identify any
  constant background.
• Robots navigating through traffic.
• Football games!
• Report the outcome of Exercise 9.1!

7
Motion detection Image subtraction

• In surveillance applications a stationary camera
  might be observing a non-uniform background.
  Image subtraction can be used effectively to
  observe changes in the scene.
• If images are received at 30 fps, then sampling
  the image frames can be more efficient.
• The size and location of the change can be
  obtained easily.

8
(No Transcript)
9
Motion Vectors

• Motion of 3D scene points results in motion of
  the image points to which they project.
• Zooming out can be performed by reducing the
  focal length of a still camera or by backing away
  from the scene while keeping the focal length
  fixed.
• The optical axis points toward a scene point
  whose image does not movethis is the focus of
  contraction.

10

• Zooming in is performed by increasing the focal
  length of a still camera or by moving towards a
  particular scene point whose image does not
  change this is called the point of expansion.
• Panning a camera or turning our heads causes the
  images of the 3D scene points to translate.

11
Motion Fields

• A 2D array of 2D vectors representing the motion
  of 3D scene points is called the motion field.
  The motion vectors in the image represents the
  displacements of the images of moving 3D points.
  Each motion vector might be formed with its tail
  at an image 3D point at time t and its head at
  the image of that same 3D point imaged at t?t.
  Alternately, each motion vector might correspond
  to an instantaneous velocity estimate at time t.

12
FOE and FOC

• The focus of expansion (FOE) is that image point
  from which all motion field vectors diverge. The
  FOE is typically the image of a 3D scene point
  towards which the sensor is moving.
• The focus of contraction (FOC) is that image
  point towards which all motion vectors converge,
  and is typically the image of a 3D scene point
  which the sensor is receding.

13
Motion Fields

• Computation of the motion field can support both
  the recognition of objects and an analysis of
  their motion.
• The intensity of the 3D scene point P and that of
  its neighbors remain nearly constant during the
  time interval (t1,t2) over which the motion
  estimate for P is made.
• Image flow is the motion field computed under the
  assumption that image intensity near
  corresponding points is relatively constant.

14
Computing Motion Flow

• Using point correspondences
• A sparse motion field can be computed by
  identifying pairs of points that correspond in
  two images taken at time t1 and t1 ?t.
• The points we must use must be distinguished in
  some way so that they can be identified and
  located in both images.

15
Point correspondence problem

• Automatically extracting point correspondences is
  not a trivial problem. It is a complete research
  topic.
• Several methods have been proposed.
• Corner detectors or high interest points
• Centroid of persistent moving regions from
  segmented images.
• Interest operators computes intensity variances
  in the vertical, horizontal and diagonal
  directions.
• Searching in a small neighborhoods using a mask.
• Texture based operator described in Exercise 9.3.

16
(No Transcript)
17
Correspondences

• This procedure once applied to an image at time
  t1, searching for interest points in the
  subsequent image can be guided by the location of
  the points in the first image.
• Given motion is not going to be large between
  subsequent images, a small neighborhood can be
  searched and matched using cross-correlation.

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
MPEG Compression of Video

• MPEG compression uses complex operations to
  compress a video stream up to 2001
• An MPEG encoder replaces an entire 16x16 image
  block in one frame with motion vector defining
  how to locate the best matching 16x16 block of
  intensities in some previous frame.
• Uniform grid of blocks is used and match of each
  block is sought by searching a previous image of
  the video sequence.
• Ideally each block Bk can be replaced by a single
  vector. Changes in intensities can also be
  transmitted using small number of bits.

23
(No Transcript)
24
Computing Image Flow
25
Computing Image Flow

• We will look at a classical method that combines
  spatial and temporal gradients computed from at
  least two frames.
• We assume that the object reflectivity and the
  illumination of the object does not change during
  the interval t1 t2.
• We assume that the distances of the object from
  the camera or light sources does not vary
  significantly over this interval.
• We shall also assume that each small intensity
  neighborhood Nxy at time t1 is observed in some
  shifted position Nx?xy?y.

26
The image flow equation

• Using the continuous intensity function f(x,y,t),
  we apply its Taylor series representation in s a
  small neighborhood of an arbitrary point (x,y,t).
• This is a multivariable version of the very
  intuitive approximation for the one variable
  case.

27
(No Transcript)
28

• The image flow equation does not give a unique
  solution for the flow vector V, but imposes a
  linear constraint.

29
Solving for Image Flow

• The image flow equation provides a constraint
  that can be applied at every pixel position.
• By assuming coherence, neighboring pixels are
  constrained to have similar flow vectors.
• Propagating constraints we can reach two
  conclusions
• Only at the interesting corner points can image
  flow be safely computed using small apertures.
• Second, constraints on the flow vectors at the
  corners can be propagated down the edges
  however, as Figure 9.12(c) shows,it might take
  many iterations to reach an interpretation for
  edge points, such as P, that are distant from any
  corner.

30
(No Transcript)
31
Computing the path of moving points

• If the intensity neighborhood of each point is
  uniquely textured, then we should be able to
  track the point over time using normalized
  cross-correlation.
• Also domain knowledge might make it easier to
  track an object orange tennis ball in a tennis
  match or a pink face in front of a workstation
  etc.

32
Tracking objects

• We can exploit the following general assumptions
  that hold for physical objects in 3D
• The location of a physical object changes
  smoothly over time
• The velocity of a physical object changes
  smoothly (both in speed and direction) over time
• An object can be at only one location in space at
  a given time
• Two objects cannot occupy the same location at
  the same time.

33

• The first three assumptions hold for 2D
  projections of 3D space, i.e smooth 3D motion
  results in smooth 2D trajectories.
• The fourth may be violated under projections,
  since one object might occlude another.
• We will see an algorithm that uses these four
  assumptions.

34
Tracking Algorithm

• Definition if an object i is observed at time
  instants t 1,2,,n, then the sequence of image
  points Ti (pi,1, pi,2,,pi,t,,pi,n) is called
  the trajectory of i.
• Between any two points of the trajectory we can
  define their difference vector
• Vi,t pi,t1 pi,t

35

• We can define a smoothness value at a trajectory
  point pi,t in terms of the difference of vectors
  reaching and leaving that point.
• Smoothness of direction is measured by their dot
  product.
• Smoothness of speed is measured by comparing the
  geometric mean of their magnitude to their
  average magnitude
• The weight w of the two factors is set between 0
  and 1, such that Si,t is between 0 and 1.

36

• Note that for a straight trajectory with equally
  spaced points al the difference vectors are the
  same, the equation will yield 1.0, which is the
  optimal point smoothness value.
• Changes in speed or direction will decrease the
  value of Si,t.
• Suppose you have m points over n frames, the
  problem is to construct m trajectories Ti with
  the maximum smoothness value.
• The total smoothness is defined by

37
(No Transcript)
38
Exercise 9.10 as practice.
39
(No Transcript)
40
Detecting Significant Changes in Video

• Changes can be several forms
• Scene change (large change in the background)
• Shot change (switching to different cameras)
• Camera pan (motion vector to one side)
• Camera zoom (changes in focal length)
• Camera effects fade, dissolve and wipe.

41
Segmenting Video Sequence

• The goal of the analysis is to parse a long
  sequence into sub-sequences representing single
  shots or scene.
• For example consider your evening news
• Often there are several different shots of the
  event being reported with transitions between
  them.
• The transitions can be used to segment the video
  and can be detected by large changes in the
  features of the image over time.

42

• One obvious method of computing the difference
  between two frames of a sequence is to compute
  the average difference between corresponding
  pixels.
• Depending on the camera effect delta t might be
  one for more frames.
• This equation is likely to yield large numbers
  even for small amounts of changes.

43

• A more robust measure could be to break the image
  into blocks and compute the mean (u) and variance
  (v) of the intensities.
• Then compare the corresponding blocks. If most
  blocks remain the same then the shot remains the
  same.
• Kasturi and Jain proposed the following
  likelihood ratio for this purpose.

44

• An alternate solution is to compute the histogram
  (of either color or intensities) of the two
  frames and compute the similarities between the
  histograms (which would be faster than the method
  described earlier).
• However the weakness of this method is as before,
  no spatial relation is taken into account.

45
(No Transcript)
46
(No Transcript)
47
Ignoring some camera effects

• Certain camera effects can be detected and
  ignored.
• For example zooming or panning would essentially
  result in the same segment.
• Zooming and panning can be detected using motion
  fields a similar block-wise approach to MPEG
  can used for efficiency.

48
Storing the sub-sequences

• These sub-sequences, once segmented can be stored
  in a database and can be retrieved like in CBIR.
• Key frames can be identified for indexing.

49

• Image Segmentation Part I
