SE 746-NT Embedded Software Systems
Development Robert Oshana Lecture
6 For more information, please
contact NTU Tape Orders NTU Media
Services [phone]
oshana_at_airmail.net
tapeorders_at_ntu.edu
2
Lecture 6

• More Hardware fundamentals - Memory

3
Agenda

• Memory testing
• Validating memory contents
• Flash memory

4
Electrical wiring problems

• Data line problems
• Bits might appear to be stuck
• Two or more bits contain the same value
  regardless of the data being transferred
• stuck high (always 1)
• stuck low (always 0)
• Detected by writing a sequence of data values
  designed to test each data pin can be set to 0
  and 1, independently of all others

5
Electrical wiring problems

• Address wiring problems
• Contents of two memory locations may appear to
  overlap
• Data written to one address will overwrite the
  contents of another address
• Memory device is seeing an address different
  from the one the processor has selected

6
Electrical wiring problems

• Control lines
• Hard to describe a general test for testing for
  control lines open or closed
• Operation specific to processor or memory
  architecture
• Problems here usually indicate that memory will
  not work at all
• Seek advice of designer for how to test

7
Missing memory chips

• Missing memory chips may not be detected!
• Capacitance nature of unconnected electrical
  wires
• Some memory tests do write followed immediately
  by a read
• This could result in reading remaining voltage
  from the previous write
• If read to quickly, it appears there is data
  being stored when there is nothing there!

8
Missing memory chips

• Perform several consecutive writes followed by
  the same number of reads
• Write value 1 to memory location A
• Write value 2 to memory location B
• Write value 3 to memory location C
• Read from location A
• Read from location B
• Read from location C
• If no memory, first value read will correspond to
  last value written instead of first

9
Improperly inserted chips

• Symptom is that system will behave as though
  there is a wiring problem or a missing chip
• Some number of pins not connected at all or
  connected to the wrong locations
• Could be part of the address, data, or control
  lines
• Tests for missing chips and wiring problems will
  catch this problem as well

10
Developing a test strategy

• Carefully select the test data
• Carefully select the order in which addresses are
  tested
• Break your memory into small testable pieces
• Improves efficiency of test
• Improves readability of code
• More specific tests can provide more detailed
  information if desired

11
Developing a test strategy

• Three individual tests
• Data bus test (wiring and improperly inserted
  chip test)
• Address bus test (wiring and improperly inserted
  chip test)
• Device test (missing chips and catastrophic
  failures)

12
Developing a test strategy

• Order to execute tests
• 1. Data bus test
• 2. Address bus test assumes a working data bus
• 3. Device test assumes working address and data
  bus
• Most of the problems can be found by looking at
  the data

13
Data bus test

• Verify that the value placed on the bus is
  correctly received by the memory device on the
  other end
• Test the bus one bit at a time
• Passes if each data bit can be set to 0 and 1,
  independently of the other data bits
• walking 1s test

14
Data bus test

• Reduces number of test patterns from 2n to n,
  where n is the width of the data bus
• Because we are testing the data bus, all data
  values can be written to the same address (any
  address will do)
• If data bus splits you must test one address
  within each chip

15
Data bus test

• Write the first value to memory
• Verify it by reading it back
• Write the second value
• Etc
• Ok to read back immediately (not looking for
  missing chips yet)

• 00000001
• 00000010
• 00000100
• 00001000
• 00010000
• 00100000
• 01000000
• 10000000

16

• /

• Function memTestDataBus()
• Decription Test the data bus wiring in a
  memory region by
• performing a walking 1s test at a
  fixed address
• within that region. The address
  (and hence the
• memory region) is selected by the
  caller.
• Returns 0 if the test succeeds
• A nonzero result is the first
  pattern that failed
•
  /
• datum
• memTestDataBus(volatile datum address)
• datum pattern

17

• memTestDataBus(volatile datum address)
• datum pattern
• /
• perform a walking 1s test at the given
  address
• /
• for (pattern 1 pattern ! 0 pattern ltlt 1)
• /
• write the test pattern
• /
• address pattern
• /
• read it back (immediately is ok for this
  test)
• /

18

• return (0)
• / memTestDataBus() /

19
Address bus test

• Next test to run after confirming that the data
  test passes
• Many possible addresses that could overlap
• Try to isolate each address bit during testing
  (like the data test)
• Confirm each address pin can be set to 0 and 1

20
Address bus test

• Use power of 2 address
• 00001h, 00002h, 00004h, 00008h, 00010h, 00020h,
  etc
• Also test 00000h
• Possibility of overlapping locations makes this
  test harder to implement
• After writing to one of the addresses, must check
  that none of the others have been over written

21
Address bus test

• Not all addresses can be tested this way
• Leftmost bits select the memory chip
• Rightmost bits may not be significant if data bus
  width greater than 8 bits
• These bits will remain constant throughout the
  test and reduce the number of test addresses

22
Address bus test

• Example for 20 bit address range
• Can address 1 M of memory
• 128K byte block test implies three MSBs will
  remain constant (128K byte is 1/8th of the total
  1M address range)
• Only 17 rightmost bits of the address bus can
  actually be tested

23
Address bus test

• To confirm no 2 memory addresses overlap
• Write an initial data value at each power of 2
  offset within the device
• Write an inverted data value to the first test
  offset
• Verify initial data value is still stored at
  every other power of 2 location
• Problem with current address bit if any other
  power of 2 location is not right
• Repeat for remaining offsets

24

• /

• Function memTestAddressBus()
• Decription Test the address bus wiring in
  memory region by
• performing a walking 1s test on
  the relevant bits
• of the address and checking for
  aliasing. The
• base address and size of the region
  are selected
• by the user.
• Notes For best results, the selected base
  address should
• enough LSB 0s to guarantee single
  address bit
• changes (to test a 64 KB region,
  select a base
• address on a 64 KB boundary
• Returns NULL if the test succeeds
• A nonzero result is the first
  address that failed

25

• memTestAddressBus(volatile datum baseAddress,
  unsigned long nBytes)
• unsigned long addressMask (nBytes 1)
• unsigned long offset
• unsigned long testOffset
• datum pattern (datum) 0xAAAAAAAA
• datum antipattern (datum) 0x55555555
• /
• write the default pattern at each of the power
  of two offsets
• /
• for (offset sizeof(datum) (offset
  addressMask) ! 0 offset ltlt1)
• baseAddressoffset pattern
• /
• check for address bits stuck high
• /

26

• if (baseAddressoffset ! antipattern
• return ((datum ) baseAddressoffset
  )
• baseAddresstestOffset pattern
• /
• check for address bits stuck low or shorted
• /
• for (offset sizeof(datum) (offset
  addressMask) ! 0 testOffset ltlt1)
• baseAddresstestOffset antipattern
• for (offset sizeof(datum) (offset
  addressMask) ! 0 offset ltlt1)
• if ((baseAddressoffset ! pattern)
  (offset ! testOffset))

27

• baseAddresstestOffset pattern
• return (NULL)
• / memTestAddressBus() /

28
Device test

• Used to test the integrity of the memory device
  itself
• Test every bit in device is capable of holding a
  1 and a 0
• Easy to implement but harder to execute
• Must write and verify every location twice
• Any value for the first half invert for the
  second half

29
Device test

• First do an increment test
• Second pass is a decrement test
• Incrementing data pattern is adequate and easy to
  compute

30
Device test
31
Example

• Test the second 64K byte chunk of SRAM on an
  embedded device (Arcom board)
• Recall the memory map talked about earlier

32
Memory map for example
FFFFFh E0000h C0000h 72000h 70000h 20000h
00000h
EPROM (128K)
Flash memory (128K)
Unused
2nd 64K byte Segment is 10000h
Zilog SCC
Unused
SRAM (128K)
33
Example

• Width of data bus (80188EB) is 8 bits
• Total of 64K bytes to be tested
• Rightmost 16 bits of address bus
• If any of the tests return nonzero value (error)
  then turn on red LED to indicate error (and
  return useful information)
• If all tests pass turn on green LED

34

• /

• Function main()
• Decription Test the 2nd 64K byte bank of SRAM
• Returns 0 on success
• Otherwise 1 indicates error
•
  /
• main(void)
• (
• if ((memTestDataBus(BASE_ADDRESS) ! 0)
• (memTestAddressBus(BASE_ADDRESS, NUM_BYTES)
  ! NULL
• (memTestDevice(BASE_ADDRESS, NUM_BYTES) !
  NULL))
• toggleLed(LED_RED)
• return(-1)
• else

35
Example

• Not always possible to test memory in HOL
• C/C require a stack
• Stack required working memory
• Create stack in an area known to be working
  test it from assembly
• Or, the memory test can be run from an emulator
• Place the stack in emulator memory
• Move the emulator to different areas in the
  target memory map to test all locations

36
Example

• Memory testing most useful during product
  development when design is unproven
• Memory is so important it might make sense to
  always test it
• Run during power on or reset
• Forms part of a hardware diagnostics

37
Validating memory contents

• Memory tests do not make much sense for Rom
  devices and some hybrid devices that have
  programs that cannot be overwritten
• However same memory problems can occur!
• Improper insertion, etc
• Need a confirmation for these devices as well

38
Validating memory contents

• Confirmation techniques
• Checksum
• Cyclic redundancy checks

39
Checksums

• Way to tell if a program stored in a non-volatile
  device is still good
• Compute a checksum of the program when you know
  its good
• E.g. prior to programming the ROM
• Re-calculate the checksum each time you wan to
  verify contents are still good
• Compare to previous value

40
Checksums

• Careful selection of the checksum algorithm can
  increase the probability of reducing specific
  types of errors
• Simplest
• Add up all the data bytes (or words for a 16 bit
  checksum)
• Discard the carries
• If all data (including stored checksum) is
  overwritten with 0s, this data corruption will
  be hard to detect

41
Checksums

• Overcome this weakness by inverting the result as
  a final step
• This approach still cannot detect many of the
  common data errors
• If one bit changed from 0 to 1 and another bit in
  the same column changed from 1 to 0, the
  algorithm would still compute the same checksum

42
Checksums

• Where to store checksums?
• Define it as a constant in the routine that
  verifies the data (must compute ahead of time)
• Good for the programmer
• May change many times
• Store in a fixed checksum in memory (like the
  very last location of the memory device being
  verified)
• Store in another non-volatile device

43
Cyclic redundancy check

• A specific checksum algorithm designed to detect
  the most common data errors
• Has mathematical origins
• Used often in embedded applications that require
  storage or transmission of large blocks of data

44
Cyclic redundancy check

• Some math
• Consider the data to be a long string of 1s and
  0s (called the message)
• Binary string is divided by a smaller string
  called the generator polynomial
• The remainder is the CRC checksum
• Careful selection of the generator polynomial
  will produce a checksum that can detect most
  errors within a message, including up to 99.99
  of all burst errors

45
Cyclic redundancy check

• Best generator polynomials are adapted as
  international standards
• Parameters of a CRC standard
• Width (in bits)
• Generator polynomial
• Divisor (binary representation of the polynomial)
• Initial value for the remainder
• Value to XOR with the final remainder

46
Cyclic redundancy check

• Example standard CCITT
• Checksum size (width) 16 bits
• Generator polynomial x16 x12 x5 1
• Divisor (polynomial) 0x1021
• Initial remainder 0xFFFF
• Final XOR value 0x0000

47
Flash memory

• Complicated from the programmers point of view
• Reading is the same as reading from any other
  device (for the most part)
• Flash devices enter a read mode during
  initialization
• Writing is harder
• Each memory location must be erased before it is
  written
• If not, result is some logical combo

48
Flash memory

• Only one sector, or block, can be erased at a
  time
• Cannot erase a single byte
• Size of sector varies by device (16Kbytes)
• Process of erasing varies by device
• Usually best to add a layer (API)
• Called the Flash driver

49
Flash driver

• Purpose is to hide the details of the chip from
  the software
• Simple API
• erase
• Write
• S/W calls the API
• More portable (if flash devices change)

50

• include tgt188eb.h
• /
• Features of the AMD 29F010 flash memory device
• /
• define FLASH_SIZE 0x20000
• define FLASH_BLOCK_SIZE 0x04000
• define UNLOCK1_OFFSET 0x5555
• define UNLOCK2_OFFSET 0x2AAA
• define COMMAND_OFFSET 0x5555
• define FLASH_CMD_UNLOCK1 0xAA
• define FLASH_CMD_UNLOCK2 0x55
• define FLASH_CMD_READ_RESET 0xF0
• define FLASH_CMD_AUTOSELECT 0x90
• define FLASH_CMD_BYTE_PROGRAM 0xA0
• define FLASH_CMD_ERASE_SETUP 0x80
• define FLASH_CMD_CHIP ERASE 0x30
• define FLASH_CMD_SECTOR_ERASE 0x30

51

• /

• Function flashWrite()
• Description write data to consecutive
  locations in the flash
• Notes This function is specific to the AMD
  29F1020 Flash
• memory. In that device, a byte that
  has been
• previously written must be erased
  before it can be
• rewritten successfully
• Returns Number of bytes successfully written
•
  /
• int
• flashWrite(unsigned char baseAddress,
• const unsigned char data
• unsigned int nBYtes)
• unsigned char flashBase FLASH_BASE

52
/ issue the command
sequence for byte program /
flashBaseUNLOCK1_OFFSET FLASH_CMD_UNLOCK1
flashBaseUNLOCK2_OFFSET
FLASH_CMD_UNLOCK2 flashBaseCOMMAND_O
FFSET FLASH_CMD_BYTE_PROGRAM /
perform the actual write operation
/ baseAddressoffeset
dataoffset /
wait for the operation to complete or time
out / while
((baseAddressoffset DQ7 ! (dataoffset
DQ7)) !
(baseAddressoffset DQ5)) if
((baseAddressoffset DQ7) ! dataoffset
DQ7)) break
return(offset) /
flashWrite() /
53
Flash driver

• There are more robust implementations that handle
  errors
• The point is this can be complicated!
• Flash can also be used as a small file system
  because of nonvolatility
• API can handle this as well
• Open
• Close
• Read
• write

54
SE 746-NT Embedded Software Systems
Development Robert Oshana End of
Lecture For more information, please
contact NTU Tape Orders NTU Media
Services [phone]
oshana_at_airmail.net
tapeorders_at_ntu.edu
