Title: The MEG Software Project


1
The MEG Software Project
  • Offline Architecture
  • Computing Model
  • Status of the Software
  • Organization

PSI 9/2/2005
Corrado Gatto
2
The Offline Architecture
3
Dataflow and Reconstruction Requirements
  • 100 Hz L3 trigger
  • evt size 1.2 MB
  • Raw Data throughput
  • (1010)Hz1.2Mb/Phys evt 0.1 80Hz0.01Mb/bkg
    evt 3.5Mb/s
  • ltevt sizegt 35 kB
  • Total raw data storage 3.5Mb/s 107s 35 TB/yr

4
Requirements for Software Architecture
  • Geant3 compatible (at least at the beginning)
  • Easy interface with existing packages
  • Geant3 , Geant4, external (fortran) event
    generators
  • Scalability
  • Simple structure to be used by non-computing
    experts
  • Written and maintained by few people
  • Portability
  • Use a world-wide accepted framework

Use ROOT An existing Offline Package as
starting point
5
Expected Raw Performance
Pure Linux setup 20 data sources FastEthernet
local connection
6
MC Data Processing Scheme
Simu sig
Simu bkg 1
Simu bkg 2
Fortran G3 Or C G3/G4/Fluka
hits files sig
hits files bkg 1
hits files bkg 2
SDigitizer
SDigitizer
SDigitizer
Fortran G3 Or C
SDigits files sig
SDigits files bkg
SDigits files bkg
Digitizer
Merged Digits files
Raw Data
Reconstruct
Reconstruct
C
ESD
ESD
7
General Architecture Guidelines
  • Ensure high level of modularity (for easy of
    maintenance)
  • Absence of code dependencies between different
    detector modules (to C header problems)
  • The structure of every detector package is
    designed so that static parameters (like geometry
    and detector response parameters) are stored in
    distinct objects
  • The data structure is build up as ROOT
    TTree-objects
  • Access is possible to either the full set of
    correlated data (i.e., the event) or only one or
    more sub-sample, stored in different branches of
    the data structure (TBranch class) and
    corresponding to one or more detector.

8
Computing Model
9
Elements of a Computing Model
  • Components
  • Data Model
  • Event data sizes, formats, streaming
  • Data Tiers (DST/ESD/AOD etc)
  • Roles, accessibility, distribution,
  • Calibration/Conditions data
  • Flow, latencies, update freq
  • Simulation, Sizes, distribution
  • File size
  • Analysis Model
  • Canonical group needs in terms of data, streams,
    re-processing, calibrations
  • Data Movement, Job Movement, Priority management
  • Interactive analysis
  • Implementation
  • Computing Strategy and Deployment
  • Roles of Computing Tiers
  • Data Distribution between Tiers
  • Data Management Architecture
  • Databases
  • Masters, Updates, Hierarchy
  • Active/Passive Experiment Policy
  • Computing Specifications
  • Profiles (Tier N Time)
  • Processors,
  • Storage,
  • Network (Wide/Local),
  • DataBase services,
  • Specialized servers
  • Middleware requirements

10
CPU Needed
  • Very rough estimate
  • Assume
  • Trigger rate 20 Hz
  • Beam Duty Cycle 50
  • MC data
  • Calibration 1Hz
  • Estimates by scaling existing code and a C
    framework
  • Calibration 1 - 7 CPUs
  • MC Production 11 - 33 CPUs
  • MC Reconstruction 3 - 14 CPU/repr.
  • Raw data reconstruction 3 14 CPU/repr.
  • Alignment to be estimated
  • Optimal solution for reconstructiontake Beam
    Duty Cycle 100 and use no-beam time for
    reprocessing. -gt Double the CPU for
    reconstruction.

11
Storage Needed
  • Very rough estimate
  • Assume
  • Raw data (compressed) event size 120 kB
  • Hits (from MC) 9 kB/evt
  • SdigitDigit size (from MC) 30kB 120kB
  • Track reference (from MC) 15 kByte
  • Kinematics (from MC) 4 kByte
  • ESD size (data or MC) 30 kByte

From Alice data model
  • Storage required yearly (L3 trigger 20Hz and DC
    50)
  • Raw data 12 Tbyte ( calib)
  • Hits (from MC) 0.9 TByte
  • Digit size (from MC) 15 TByte
  • Track reference (from MC) 1.5 TByte
  • Kinematics (from MC) 0.4 TByte
  • ESD size (data or MC) 3/Tbyte /reproc.

12
A Computing Model for MEG
  • The crucial decisions are being taken at the
    collaboration level
  • Very dependent on CPU and storage requirement
  • Two degrees of complexity are being considered
  • INFN has requested a CM design by Nov 2005.

13
Data Access ROOT RDBMS Model
ROOT files
Oracle MySQL
Calibrations
Event Store
histograms
Run/File Catalog
Trees
Geometries
14
Computing Deployment Implementation 1
  • Concentrated computing
  • Will be considered only in the case the CPUs
    needed would exceed PSIs capabilities
  • Easiest implementation
  • It requires the least manpower for maintenance
  • PROOF is essential for Analysis and DQM

15
Computing Deployment Implementation 2
  • Distributed computing
  • Posting of the data/Catalog synchronization
  • Data distribution dependent upon connection speed
  • PSI -gt INFN OK (3 MB/sec)
  • PSI -gt Japan needs GRID

?
"Transparent" user access to applications and all
data
16
Processing Flow
ESD
Reco Reproc MC
AOD
Tag
  • Tier1-2

17
Computing Model Configuration
18
How We Will Proceed
  1. Decide for single-Tier or multi-Tier CM (depends
    heavily on CPUStorage needed)
  2. PSI is OK for Tier-0 (existing infrastructure
    Horizon Cluster)
  3. Find the candidate sites for Tier-1
  • Requirement for a Tier-1
  • 1 FTE for job running, control
  • 0.5-1 FTE for data export, catalog maintenance
    and DQM
  • If GRID is needed, 0.3-0.5 FTE for GRID
    maintenance
  • Software installation would be responsibility of
    the Offline group (after startup)

19
Computing Model Status
  • Started interaction with PSIs Computing Center
    (J. Baschnagel and coll.)
  • PSI CC survey was very encouraging
  • Physical space and electrical power not a
    limitation
  • However, CC is running near 80 of Cooling and
    Clean Power capabilities
  • Relevant services (backup, connection to exp.
    Area) are OK
  • Alternative options are being considered (setup
    the farm in the experimental area and use the CC
    only for backup)
  • Horizon Cluster
  • PSI stand well as Tier-0 candidate (in a
    MultiTier CM.
  • It might have enough resources to fulfill all
    MEGs computing requirement

20
Status of the Software
21
Software Organization
  • Development of Montecarlo (G3Fortran) and
    Calibration/Reconstruction (VMCROOT) will
    initially proceed in parallel
  • Migration will eventually occur later (end 2005)
  • Montecarlo group is in charge of the simulation
    (GeometryEvent Generator)
  • Offline group in charge of the rest
    (architecture, framework, reconstruction,
    computing, etc.)
  • Detector specific code developed along with
    Detector Experts
  • Present analyses for RD within the ROME
    environment (same as Online)

22
Status of the Montecarlo DCH(P. Cattaneo)
  • Progress
  • Implementation of cable duct and various
    mechanical supports
  • Reorganization of the GEANT volume inside the
    chambers
  • First integration of the time to distance profile
    from GARFIELD
  • Next
  • Completing integration of GARFIELD profiles
  • Calculation of time profiles for signals
  • Effect on signals of electrode patterns
  • Electronic simulation
  • Signal digitization
  • Improving details cards, cables

23
Status of the Montecarlo EMCAL
  • Progress
  • Pisa model implement new geometry
  • Pisa model new tracking model (not based on
    GTNEXT)
  • Tokio model GEANT based (GNEXT) photon tracking
    including
  • Refraction PMT quartz window
  • Refraction PMT holder
  • Tokio model absorption
  • Tokio model scattering
  • Tokio model ZEBRA output
  • Number of p.e. in each PMT
  • PMT position (to be replaced by MySQL/ XML)
  • Tokio model ZEBRA2NTuple converter
  • Next
  • Update geometry and complete integration between
    Pisa and Tokio
  • Signal digitization
  • ZEBRA output for hit timing

24
Status of the Montecarlo TOF
  • Progress
  • Implementation of the actual geometry tapered
    slanted bar, square fibers
  • Addition of phototubes, photodiodes and related
    mechanics
  • Next
  • Generation of photons in the bars/fiber
  • Propagation of photons to the PMT photodiodes
  • Electronics and PMT/ photodiodes simulation
  • Improving details of material distribution, e.g.
    better PMT,
  • cables
  • Add mechanical support
  • Signal digitization

25
Status of the Montecarlo more
  • Graphics display of geometry only (no event)
  • Some zooming capability
  • Possibility of displaying a single volume
  • Addition of phototubes, photodiodes and related
    mechanics
  • Beam, Target and Trigger
  • Preliminary approach outside GEM

26
Softwares used in LP beam test(R. Sawada)
Midas Data taking Slow control Data logging Run control
ROME ROOT Online monitoring Offline analysis
MySQL Channel information Geometry information Calibration constants
27
Proceedure of data take
calibration
calibration
data
run number time trigger mode Configuration ID
data
data
trigger mode channel info. geometry info.
Histogram Tree (Ntuple)
time of events
28
Proceedure of Offline Analysis
data
trigger mode channel info. geometry
info. calibration
processed data
calibration run number
calibration
29
Status of the Offline Project
  • Preliminary Offline architecture approved by MEG
    (June 2004)
  • INFN CSN1 also approved the Project (Sept.
    2004)
  • Funds have been provided for installing a
    minifarm in Lecce (22 kEUR)
  • Real work started November 2004

30
Immediate Tasks and Objectives
  • Setup a system to test the Offline code

Test functionalities performance
RDBMS
  • Prototype the Main Program
  • Modules Classes
  • Steering program
  • FastMC

Core Offline System Development
31
Manpower Estimate
Available (FTE)
  • 1 waiting for funds

32
The People Involved
  • Core Offline
  • Coordinator Gatto
  • Steering Program Di Benedetto, Gatto
  • FastMC Mazzacane, Tassielli
  • TS Implementation Chiri
  • Interface to raw data Chiri, Di Benedetto,
    Tassielli
  • Calibration Classes Interface to RDBMS
    Barbareschi
  • Trigger Siragusa
  • Will start on Mar. 2005
  • Detector experts
  • LXe Signorelli, Yamada, Savada
  • TS Schneebeli (hit), Hajime (Pattern), Lecce
    (Pattern)
  • TOF Pavia/Genova
  • Trigger Nicolo (Pisa)
  • Magnet Ootani
  • All lt100
  • Montecarlo
  • LXe Cattaneo, Cei, Yamada
  • All 100 (except for Chiri)
  • All lt100

33
Milestones
  • Offline
  • Start-up October 2004
  • Start deploying the minifarm January 2005
  • First working version of the framework (FastMC
    Reconstruction) April 2005 (badly needed to
    proceed with the Computing Model)
  • Initial estimate of CPU/storage needed June 2005
  • Computing Model November 2005
  • MDC 4th quarter 2005
  • Montecarlo
  • Include the calorimeter in gem
  • Keep the existing MC in the Geant3 framework.
    Form a panel to decide if and how to migrate to
    ROOT 4th quarter 2005

34
Milestones
  • Offline
  • Start-up October 2004
  • Start deploying the minifarm January 2005
  • First working version of the framework (FastMC
    Reconstruction) April 2005 (badly needed to
    proceed with the Computing Model)
  • Initial estimate of CPU/storage needed June 2005
  • Computing Model November 2005
  • MDC 4th quarter 2005
  • Montecarlo
  • Include the calorimeter in gem
  • Keep the existing MC in the Geant3 framework.
    Form a panel to decide if and how to migrate to
    ROOT 4th quarter 2005

35
Conclusions
  • Offline project approved by MEG and the INFN
  • Offline group has consolidated (mostly in Lecce)
  • Work has started
  • Minifarm for testing the software is being setup
  • Definition of the Computing Model is under way
  • Montecarlo is on its way to a detailed
    description of the detector

36
Backup Slides
37
Compare to the others
38
Data Model (Monarc)
  • ESD (Event Summary Data)
  • contain the reconstructed tracks (for example,
    track pt, particle Id, pseudorapidity and phi,
    and the like), the covariance matrix of the
    tacks, the list of track segments making a track
    etc
  • AOD (Analysis Object Data)
  • contain information on the event that will
    facilitate the analysis (for example, centrality,
    multiplicity, number of positrons, number of EM
    showers, and the like).
  • Tag objects
  • identify the event by its physics signature (for
    example, a cosmic ray) and is much smaller than
    the other objects. Tag data would likely be
    stored into a database and be used as the source
    for the event selection.
  • DPD ( Derived Physics Data)
  • are constructed from the physics analysis of AOD
    and Tag objects.
  • They will be specific to the selected type of
    physics analysis (ex mu-gte gamma)
  • Typically consist of histograms or nt-uple-like
    objects.
  • These objects will in general be stored locally
    on the workstation performing the analysis, thus
    not add any constraint to the overall
    data-storage resources

39
Recostruction Structure
The Run manager executes the detector objects in
the order of the list
Global Reco
Run Manager
MC Run Manager
One or more Global Objects execute a list of
tasks involving objects from several detectors
Run Class
Detector Class
Run Class
Detector tasks
Each detector executes a list of detector tasks
ROOT Data Base Tree Branches
On demand actions are possible but not the default
40
Responsibilities Tasks (all software)
  • Detector experts
  • LXe Signorelli, Yamada, Savada
  • DC Schneebeli (hit), Hajime (Pattern), Lecce
    (Pattern)
  • TC Pavia/Genova
  • Trigger Nicolo (Pisa)
  • Magnet Ootani

41
Manpower Estimate (framework only)
  • ?

Available at Lecce
  • Job posted apply now
  • 4 from Naples 2.2 from Lecce
  • 1 waiting for funds

42
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
