Semantic Web Interaction

1
Semantic Web Interaction
Wireless Agent-based

• Heikki Helin ltHeikki.j.Helin_at_teliasonera.comgt
• Principal Researcher, PhD
• Emerging Technologies and Innovations,
  TeliaSonera Finland

2
Presentation Outline

• About TeliaSonera
• Motivation
• In which field we are playing
• What we are trying to achieve
• Agent-based architecture for nomadic environments
• Agents architecture for such environments
• Communication framework for wireless
  communication
• Ontologies for nomadic environments
• On-going (or soon-to-be-started) research
  projects
• National, EU/FP6
• Summary

3
TeliaSonera

• The Nordic and Baltic leader in
  telecommunications
• The merger between Telia and Sonera became a
  reality on December 9, 2002
• Listed on the Stockholm Exchange, the Helsinki
  Exchange and Nasdaq Stock Market in the USA
• Net sales (pro forma) in 2003 amounted to SEK
  81,772 million (EUR 9,010 million)
• The number of employees was 26,000 on December
  31, 2003
• RD personnel 1000

4
The markets of TeliaSonera International
1
1
2
1
1
4
1
1
5
Motivation

• New wireless Internet services for our mobile
  (and fixed) customers
• Not only new services, but also enhance old
  ones to give better user experience
• And do that
• faster,
• easier,
• cheaper, ...

gt To attract new customers, but more
importantly keep the old customers (and at the
same time do some academic research)
6
Background

• Multi-agent system implementing a middleware
  providing (agent-based) applications with tools
  for adaptation in a nomadic environment
• Nomadic environments enable new ways to access
  services
• ? anywhere, at any time, and using any device
• Challenges that need to be addressed
• Varying QoS of the wireless networks
• Limitations of mobile devices
• Contextual variability (location, time, user
  preferences, ...)
• Adaptation to environment is the key issue

7
Mobile/Wireless Environment

• Typical characteristics
• Low throughput, long delays, unreliable, ...
• Variability
• Disconnected mode of operation is the most common
  state
• Different kind of (wireless) networks
• Seamless roaming will be important in the future
• Actors (agents) in nomadic environments should be
  aware of these issues
• Context-awareness (not only location)
• Currently we are mainly considering long thin
  networks
• GSM, HSCSD, GPRS, UMTS, ...
• But not excluding WLANs, BT, LAN, xDSL, ...

8
Agents in Nomadic Environments

• Suitable for complex environments
• Internet is a complex environment...
• Wireless Internet is even more complex...
• Invisible Internet...

Ambient networks
Semantic Web
QoS
Peer-to-peer
Intelligent P2P
Pervasive Computing
Ubiquitous Computing
Ontologies
Ad hoc networks
Distributed Artificial Intelligence
9
FIPA Agent Platform
DF Directory Facilitator AMS Agent Management
System ACC Agent Communication Channel
10
(FIPA) Nomadic Application Support
Knowlegde Sharing
Controlling monitoring
11
(FIPA) Nomadic Application Support
12
Agent Communication Wireless World
13
Layered model of agent communication
14
Message Transport
15
Message Transport

• How messages are transferred between agents
• Desiderata
• Reliability
• Efficiency
• Dynamic adaptation
• Issues
• Performance problems
• Terminal mobility
• Thin clients

16
MTP Results 11 9600bps (300ms)
17
MTP Results 11 115200bps (300ms)
18
Message Envelope
19
Message Envelope

• FIPA specific layer
• Defines how messages are delivered
• independent of message transport protocols
• Encoding options
• XML, Bit-efficient, IIOP/IDL, Binary-XML, Java
  Objects,
• Bit-efficient encoding similar to bit-efficient
  ACL

20
Message Envelope
21
ACL Layer
22
ACL Encoding

• Options
• String (s-expression), XML, Bit-efficient
• Binary-XML (w/ special encoding tokens), Java
  Objects
• Bit-Efficient encoding is the most efficient
• Space-efficient
• ...by definition
• Time-efficient
• much faster
• nice for every application not only for wireless
• necessity for
• high performance applications
• highly utilized servers
• simple parser ? appropriate for thin clients

23
ACL Encoding (request conversation)
24
ACL Encoding
25
Content Language Layer
26
Content Languages

• FIPA-SL
• All-purpose content language
• S-expression (w/ deflate), XML, Binary-XML (w/
  special tokens)
• FIPA-CCL
• Language for constraint satisfaction problems
• XML Binary-XML
• Results similar to those of message envelope and
  ACL

27
Conversation Layer
28
Conversation Layer

• Optimizing/modifying existing conversation
  protocols?
• Developing new conversation protocols?
• Selecting conversation protocol based on current
  environment
• low bandwidth ? simple protocol
• ? not so good end result
• more bandwidth ? more complicated protocol
• ? better end result

29
Ontologies in Wireless World
30
Ontologies

• An ontology is an explicit description of a
  domain
• Concepts
• Wireless network, GSM, GPRS,
• Properties and attributes of concepts
• Each Network will have Operator, Location,
  Properties,
• Every IEEE802.11a is a WLAN
• Constraints on properties and attributes
• The name of an Operator is a string
• GSM network code consist of CountryCode and
  NetworkID
• Individuals (often, but not always)
• The GSM network operated by TeliaSonera in
  Finland
• An ontology defines
• a common vocabulary
• a shared understanding

31
Cant we just use XML?
For machines, a typical web page looks like this

• XML is not enough
• Ontological modeling primitives missing
• RDF/RDFS is better, but
• Only a weak semantic interpretation
• No inference model
• OWL (Web Ontology Language)
• Extends RDFS
• Additional vocabulary along with a formal
  semantics
• More vocabulary for describing properties and
  classes
• Relations between classes (e.g. disjointness)
• Cardinality (e.g. "exactly one")
• Equality
• Richer typing of properties
• Characteristics of properties (e.g. symmetry)
• Enumerated classes

32
XML Helps...
XML allows meaningful tags to be added to parts
of the text

• ltnamegt
• XML is not enough
• Ontological modeling primitives missing
• lt/namegt
• ltaddressgt
• RDF/RDFS is better, but
• Only a weak semantic interpretation
• No inference model
• lt/addressgt
• ltcvgt
• OWL (Web Ontology Language)
• Extends RDFS
• Additional vocabulary along with a formal
  semantics
• More vocabulary for describing properties and
  classes
• Relations between classes (e.g. disjointness)
• Cardinality (e.g. "exactly one")
• Equality
• Richer typing of properties
• Characteristics of properties (e.g. symmetry)

33
XML ? Machine Accessible Meaning
To machines, the tags looks like this

• ltnamegt
• XML is not enough
• Ontological modeling primitives missing
• lt/namegt
• ltaddressgt
• RDF/RDFS is better, but
• Only a weak semantic interpretation
• No inference model
• lt/addressgt
• ltcvgt
• OWL (Web Ontology Language)
• Extends RDFS
• Additional vocabulary along with a formal
  semantics
• More vocabulary for describing properties and
  classes
• Relations between classes (e.g. disjointness)
• Cardinality (e.g. "exactly one")
• Equality
• Richer typing of properties
• Characteristics of properties (e.g. symmetry)

34
Web Ontology Languages

• Ontologies have been active research area for a
  long time
• Web ontology languages
• Provide web-friendly representation language
• Typically based on RDF Schema
• OWL is currently W3C Recommendation

35
Web Ontology Languages (cont.)

• XML is not enough
• Ontological modeling primitives missing
• RDF/RDFS is better, but
• Only a weak semantic interpretation
• No inference model
• OWL (Web Ontology Language)
• Extends RDFS
• Additional vocabulary along with a formal
  semantics
• More vocabulary for describing properties and
  classes
• Relations between classes (e.g. disjointness)
• Cardinality (e.g. "exactly one")
• Equality
• Richer typing of properties
• Characteristics of properties (e.g. symmetry)
• Enumerated classes

36
Need for Ontologies in Wireless World
37
Wireless Network Ontology - Motivation

• Machine-readable ( understandable) descriptions
  of networks
• Currently available only for humans
• 3rd party service providers
• Available networks at Gent?
• Available networks at this Hotel?
• Future applications
• Context-aware
• Available networks near here?
• Best available network?
• Available networks near my friend?
• Any application requiring information about
  (wireless) networks or their properties
• Almost all wireless world applications?

38
Wireless Network Ontology Overview

• Core Concepts
• Network -gt Wireless Network -gt GSM Network -gt ...
• Operator
• (Location)
• ...
• QoS Concepts
• Throughput, delay, rtt,
• Services
• GSM Services
• Supplementary services, Tele services,
• WLAN Services
• ...

39
Wireless Network Ontology Core Concepts
40
Wireless Network Ontology Services
41
Wireless Network Ontology QoS Concepts
42
Related Projects _at_ TeliaSonera
43
Related projects _at_ TeliaSonera

• EU/FP6 projects
• Ambient Networks (IP), Magnet (IP)
• CASCOM (Strep)
• National projects
• CAPNET
• Fuego Core
• Intelligent Web Services

44
CASCOM Overview

• Context-Aware Business Application Service
  Co-ordination In Mobile Computing Environments
• FP6/2 Strep project
• 414 PM/3 years
• 8 partners
• Project goal
• Develop, implement, validate, and trial of
• Agent-based service coordination infrastructure
  for
• Innovative semantic Web service discovery,
  composition, execution
• Across mobile and fixed Peer-To-Peer service
  networks

45
CASCOM Main ST Innovations

• Generic Service Agent Architecture and Prototype
  Demonstrator
• CASCOM Service Coordination Means
• Declarative Service Description
• Flexible Service Matching
• Dynamic Service Composition
• Secure Service Execution Monitoring
• CASCOM Intelligent Service Agents
• Service Agent Platform for Nomadic Computing and
  Ad-Hoc P2P Communication
• Context-Aware Service Provisioning
• Dynamic Service Agent Coalitions

46
CASCOM Use Case Scenario

• Ad-Hoc Emergency Medical Care and Transport
• Medical information
• Patient transport
• Insurance coverage

47
Intelligent Web Services (IWebS)

• Semantic yellow page services
• How the user finds correct service(s)?
• How the service provider advertises the service
  it provides?
• Dynamic content
• Service composition
• Support for different terminals
• Desktop, mobile, ...
• http//www.cs.helsinki.fi/group/iwebs/

48
IWebS Sample Scenario
49
Summary

• Nomadic environments introduce challenges, such
  as varying QoS, variations and limitations of the
  mobile devices, as compared to desktop
  environments
• Device independence and adaptation are key issues
  when designing and implementing services for such
  environments
• Agent architecture with efficient communication
• Ontologies
• (Wireless) networks
• QoS
• Other domains need conceptualization as well
• Services
• Users
• Preferences, etc.
• Devices

50
More information

• Heikki Helin and Mikko Laukkanen Performance
  Analysis of Software Agent Communication in Slow
  Wireless Networks. In Proceedings of the 11th
  International Conference on Computer
  Communications and Networks (ICCCN'02), October
  2002
• Heikki Helin and Mikko Laukkanen Wireless
  Network Ontology. In WWRF9, July 2003
• Heikki Helin Supporting Nomadic Agent-based
  Applications in FIPA Agent Architecture. PhD
  Thesis. University of Helsinki, Finland. February
  2003.
