Data Types

1
Data Types
2
What is a type system?

• A mechanism for defining types and associating
  with language constructs
• Rules for
• Type equivalence (whether two values have same
  type)
• Type compatibility (whether a value can be used
  in a certain context)
• Type inference (type of expression based on parts)

3
Types in a language

• Strongly typed prohibits (enforceably)
  application of an op to any object not supporting
  the operation
• Statically typed strongly typed and compiler can
  check types (Pascal, C, ...)
• Dynamically typed operands of operations checked
  at run time (Lisp, Smalltalk)
• Programmer does not specify types, compiler
  infers types from context (ML).

4
Definition of types

• Declaration introduces name, scope
• Definition describes type of value to which name
  is bound.
• Viewpoints
• Denotational type is set of values
• Constructive type is either built-in, or
  composite
• Abstraction type is interface, ie set of ops
  with well-defined semantics.

5
Composite types

• Records
• Variant records (one variant valid at any given
  time)
• Arrays (index, component type)
• Sets
• Pointers (references)
• Lists (recursive def)
• Files

6
Records

• Nested record definitions
• Memory layout (alignment with word boundaries for
  efficient access, packed for space)

packed
naive
compromise
7
Arrays

• Time at which array shape is bound is important
• global lifetime, static shape (static memory)
• local lifetime, static shape (stack frame)
• local lifetime, shape bound at elaboration/binding
  creation time (variable-size part of the stack
  frame. Fixed-size part is for objects whose size
  is statically known). E.g Ada.
• arbitrary lifetime, shape bound at elaboration
  time (heap). E.g. Java.
• arbitrary lifetime, dynamic shape (heap)

8
Memory layout for arrays
9
Memory layout (2)
contiguous array
row pointers
Memory layout determines nature and efficiency of
address calculations
10
Pointers

• Reference model of variables (Lisp, ML, CLU,
  Java)
• Value model of variables (C, Pascal, Ada)
• requires pointers for recursive types
• pointers are not addresses, but higher level
• Explicit storage reclamation
• memory leak
• dangling pointers

11
Dangling references

• Reclaiming space of non-live objects
• Explicit reclamation (free, dispose, delete )
• Garbage collection
• Dangling reference a live pointer to a reclaimed
  object.
• Mechanisms to avoid dangling references
• Tombstones
• Locks and keys

12
Tombstones

• Invalid tombstone set to outside address
  space(cause hardware interrupt)
• Space overhead
• Easy to change locationof object in heap (just
  change tombstone address)
• For both heap and stackobjects

13
Locks and keys
Pointer address key Object has lock When
reclaiming object, Change the lock Tombstones
vs. locks/keys Efficiency comparison
unclear Both incur significant time and
space Overhead.
14
Garbage collection

• Automatic reclamation of objects
• Essential for functional languages
• Popular in imperative languages (Clu, Ada,
  Modula-3, Java)
• Difficult to implement
• Slower than manual reclamation

15
Reference counts

• Associate reference count with each object.
• set to 1 when object is allocated.
• adjust
• when one pointer assigned to another.
• on subroutine return.
• requires type descriptors to identify pointers
• In stack frames
• In objects
• circular lists present a problem.

16
Mark-and-sweep collection

• Mark all blocks of the heap as unreachable.
• Beginning with all pointers outside heap,
  recursively visit each block and mark it
  reachable.
• Move each unreachable block into the free list.

17
Issues with mark-and-sweep

• In steps 1,3 tell where every block begins and
  ends. gt block begins with its size
• In step 2 find all pointers within a block.
• Stop-the-world phenomenon awkward pauses for
  garbage collection, bad especially for
  interactive programs.

18
Variation stop-and-copy

• Divide heap in half.
• All allocation happens in first half.
• When first half is nearly full, GC starts
• Recursively explores reachable data
• Reachable data is copied to second half
  (compactly).
• When done, all useful data in second half
• Swap use of first and second half, continue

19
Variation Generational technique

• Idea Garbage collected only among recently
  allocated objects.
• Heap divided into two halves
• allocation only in first
• permanent only in second
• Blocks that survive a small number of collections
  become permanent, copied over to the permanent
  half.
