Automated Parameter Setting Based on Runtime
Prediction

• Towards an Instance-Aware Problem Solver

Frank Hutter, Univ. of British Columbia,
Vancouver, Canada Youssef Hamadi, Microsoft
Research, Cambridge, UK
2
Motivation(1) Why automated parameter setting ?

• We want to use the best available heuristic for a
  problem
• Strong domain-specific heuristics in tree search
• Domain knowledge helps to pick good heuristics
• But maybe you dont know the domain ahead of time
  ...
• Local search parameters must be tuned
• Performance depends crucially on parameter
  setting
• New application/algorithm
• Restart parameter tuning from scratch
• Waste of time both for researchers and
  practicioners
• Comparability
• Is algorithm A faster than algorithm B because
  they spent more time tuning it ? ?

3
Motivation(2) operational scenario

• CP solver has to solve instances from a variety
  of domains
• Domains not known a priori
• Solver should automatically use best strategy for
  each instance
• Want to learn from instances we solve

Frank Hutter
Frank Hutter
4
Overview

• Previous work on runtime prediction we base
  onLeyton-Brown, Nudelman et al. 02 04
• Part I Automated parameter setting based on
  runtime prediction
• Part II Incremental learning for runtime
  prediction in a priori unknown domains
• Experiments
• Conclusions

5
Previous work on runtime prediction for algorithm
selection

• General approach
• Portfolio of algorithms
• For each instance, choose the algorithm that
  promises to be fastest
• Examples
• Lobjois and Lemaître, AAAI98 CSP
• Mostly propagations of different complexity
• Leyton-Brown et al., CP02 Combinatorial
  auctions
• CPLEX 2 other algorithms (which were thought
  incompetitive)
• Nudelman et al., CP04 SAT
• Many tree-search algorithms from last SAT
  competition
• On average considerably faster than each single
  algorithm

6
Runtime prediction Basics (1 algorithm)
Leyton-Brown, Nudelman et al. 02 04

• Training Given a set of t instances z1,...,zt
• For each instance zi
• Compute features xi (xi1,...,xim)
• Run algorithm to get its runtime yi
• Collect (xi ,yi) pairs
• Learn function f X ! R (features ! runtime), yi
  ? f (xi)
• Test Given a new instance zt1
• Compute features xt1
• Predict runtime yt1 f(xt1)

Expensive
Cheap
7
Runtime prediction Linear regression
Leyton-Brown, Nudelman et al. 02 04

• The learned function f has to be linear in the
  features xi (xi1,...,xim)
• yi ¼ f(xi) ?j1..m (xij wj) xi w
• The learning problem thus reduces to fitting the
  weights w w1,...,wm
• To grasp the vast different in runtime better,
  estimate the logarithm of runtime e.g. yi 5 ?
  runtime is 105 sec

8
Runtime prediction Feature engineering
Leyton-Brown, Nudelman et al. 02 04

• Features can be computed quickly (in seconds)
• Basic properties like vars, clauses, ratio
• Estimates of search space size
• Linear programming bounds
• Local search probes
• Linear functions are not very powerful
• But you can use the same methodology to learn
  more complex functions
• Let ? (?1,...,?q) be arbitrary combinations of
  the features x1,...,xm (so-called basis
  functions)
• Learn linear function of basis functions f(?)
  ? w
• Basis functions used in Nudelman et al. 04
• Original features xi
• Pairwise products of features xi xj
• Only subset of these (drop useless basis
  functions)

9
Algorithm selection based on runtime
predictionLeyton-Brown, Nudelman et al. 02
04

• Given n different algorithms A1,...,An
• Training
• Learn n separate functions fj? ! R, j1...n
• Test
• Predict runtime yjt1 fj(?t1) for each of the
  algorithms
• Choose algorithm Aj with minimal yjt1

Really Expensive
Cheap
10
Overview

• Previous work on runtime prediction we base on
  Leyton-Brown, Nudelman et al. 02 04
• Part I Automated parameter setting based on
  runtime prediction
• Part II Incremental learning for runtime
  prediction in a priori unknown domains
• Experiments
• Conclusions

11
Parameter setting based on runtime prediction
Finding the best default parameter setting for a
problem class Generate special purpose code
Minton 93 Minimize estimated error Kohavi
John 95 Racing algorithm Birattari et al.
02 Local search Hutter 04 Experimental
design Adenso-Daz Laguna 05 Decision trees
Srivastava Mediratta, 05
Runtime prediction for algorithm selection on a
per-instance base Predict runtime for each
algorithm and pick the best Leyton-Brown,
Nudelman et al. 02 04
Runtime prediction for setting parameters on a
per-instance base
12
Naive application of runtime prediction for
parameter setting

• Given one algorithm with n different parameter
  settings P1,...,Pn
• Training
• Learn n separate functions fj? ! R, j1...n
• Test
• Predict runtime yjt1 fj(?t1) for each of the
  parameter settings
• Run algorithm with setting Pj with minimal yjt1

Too expensive
Fairly Cheap

• If there are too many parameter configurations
• Cannot run each parameter setting on each
  instance
• Need to generalize (cf. human parameter tuning)
• With separate functions there is no way to
  generalize

13
Generalization by parameter sharing

• Naive approach n separate functions.
• Information on theruntime of setting icannot
  inform predictions for setting j ? i

• Our approach 1 single function.
• Information on theruntime of setting ican
  inform predictions for setting i ? j

14
Application of runtime prediction for parameter
setting

• View the parameters as additional features, learn
  a single function
• Training Given a set of instances z1,...,zt
• For each instance zi
• Compute features xi
• Pick some parameter settings p1,...,pn
• Run algorithm with settings p1,...,pn to get
  runtimes y1i ,...,yni
• Basic functions ?1i, ..., ?ni include the
  parameter settings
• Collect pairs (?ji,yji) (n data points per
  instance)
• Only learn a single function g? ! R
• Test Given a new instance zt1
• Compute features xt1
• Search over parameter settings pj. Evaluation
  compute ?jt1, check g(?jt1)
• Run with best predicted parameter setting p

Moderately Expensive
Cheap
15
Summary of automated parameter setting based on
runtime prediction

• Learn a single function that maps features and
  parameter settings to runtime
• Given a new instance
• Compute the features (they are fix)
• Search for the parameter setting that minimizes
  predicted runtime for these features

16
Overview

• Previous work on runtime prediction we base on
  Leyton-Brown, Nudelman et al. 02 04
• Part I Automated parameter setting based on
  runtime prediction
• Part II Incremental learning for runtime
  prediction in a priori unknown domains
• Experiments
• Conclusions

17
Problem setting Incremental learning for
multiple domains
Frank Hutter
Frank Hutter
18
Solution Sequential Bayesian Linear Regression

• Update knowledge as new data arrivesprobabilit
  y distribution over weights w
• Incremental (one (xi, yi) pair at a time)
• Seemlessly integrate this new data
• Optimal yields same result as a batch approach
• Efficient
• Computation 1 matrix inversion per update
• Memory can drop data we integrated
• Robust
• Simple to implement (3 lines of Matlab)
• Provides estimates of uncertainty in prediction

19
What are uncertainty estimates?
20
Sequential Bayesian linear regression intuition

• Instead of predicting a single runtime y, use a
  probability distribution P(Y)
• The mean of P(Y) is exactly the prediction of the
  non-Bayesian approach, but we get uncertainty
  estimates

Uncertainty of prediction
P(Y)
Log. runtime Y
Mean predicted runtime
21
Sequential Bayesian linear regression technical

• Standard linear regression
• Training given training data ?1n, y1n, fit the
  weights w such that y1n ¼ ?1n w
• Prediction yn1 ?n1 w
• Bayesian linear regression
• Training Given training data ?1n, y1n, infer
  probability distribution P(w?1n, y1n) / P(w)
  ?i P(yi?i, w)

• Prediction P(yn1?n1, ?1n, y1n) s
  P(yn1w, ?n1) P(w?1n, y1n) dw

• Knowledge about the weights Gaussian (?w, ?w)

22
Sequential Bayesian linear regression visualized
P(wi)

• Start with a prior P(w) with very high
  uncertainty
• First data point (?1,y1)
• P(w?1, y1) / P(w) P(y1?1,w)

Weight wi
P(y1?1,w)
Weight wi
P(wi?1, y1)
23
Summary of incremental learning for runtime
prediction

• Have a probability distribution over the weights
• Start with a Gaussian prior, incremetally update
  it with more data
• Given the Gaussian weight distribution, the
  predictions are also Gaussians
• We know how uncertain our predictions are
• For new domains, we will be very uncertain and
  only grow more confident after having seen a
  couple of data points

Frank Hutter
Frank Hutter
24
Overview

• Previous work on runtime prediction we base on
  Leyton-Brown, Nudelman et al. 02 04
• Part I Automated parameter setting based on
  runtime prediction
• Part II Incremental learning for runtime
  prediction in a priori unknown domains
• Experiments
• Conclusions

25
Domain for our experiments

• SAT
• Best studied NP-hard problem
• Good features already exist Nudelman et al.04
• Lots of benchmarks
• Stochastic Local Search (SLS)
• Runtime prediction has never been done for SLS
  before
• Parameter tuning is very important for SLS
• Parameters are often continuous
• SAPS algorithm Hutter, Tompkins, Hoos 02
• Still amongst the state-of-the-art
• Default setting not always best
• Well, I also know it well -)
• But the approach is applicable to about anything
  whenever we can compute features!!

26
Stochastic Local Search for SATScaling and
Probabilistic Smoothing (SAPS)Hutter, Tompkins,
Hoos 02

• Clause weighting algorithm for SAT, was
  state-of-the-art in 2002
• Start with all clause weights set to 1
• Hillclimbing until you hit a local minimum
• In local minima
• Scaling scale weights of unsatisfied clauses wc
  Ã ? wc
• Probabilistic smoothing with probability
  Psmooth, smooth all clause weights wc à ? wc
  (1-?) average wc
• Default parameter setting (?, ?, Psmooth)
  (1.3,0.8,0.05)
• Psmooth and ? are very closely related

27
Benchmark instances

• Only satisfiable instances!
• SAT04rand SAT 04 competition instances
• mix mix of lots of different domains from
  SATLIB random, graph colouring, blocksworld,
  inductive inference, logistics, ...

28
Adaptive parameter setting vs. SAPS default on
SAT04rand

• Trained on mix and used to choose parameters for
  SAT04rand
• ? 2 0.5,0.6,0.7,0.8
• ? 2 1.1,1.2,1.3
• For SAPS steps ? time
• Adaptive variant on average 2.5 times faster than
  default
• But default is not strong here

29
Where uncertainty helps in practice qualitative
differences in training test set

• Trained on mix, tested on SAT04rand

Estimates of uncertaintyof prediction
Optimal prediction
30
Where uncertainty helps in practice (2)Zoomed
to predictions with low uncertainty
Optimal prediction
31
Overview

• Previous work on runtime prediction we base on
  Leyton-Brown, Nudelman et al. 02 04
• Part I Automated parameter setting based on
  runtime prediction
• Part II Incremental learning for runtime
  prediction in a priori unknown domains
• Experiments
• Conclusions

32
Conclusions

• Automated parameter tuning is needed and feasible
• Algorithm experts waste their time on it
• Solver can automatically choose appropriate
  heuristics based on instance characteristics
• Such a solver could be used in practice
• Learns incrementally from the instances it solves
• Uncertainty estimates prevent catastrophic errors
  in estimates for new domains

33
Future work along these lines

• Increase predictive performance
• Better features
• More powerful ML algorithms
• Active learning
• Run most informative probes for new domains (need
  the uncertainty estimates)
• Use uncertainty
• Pick algorithm with maximal probability of
  success (not the one with minimal expected
  runtime!)
• More domains
• Tree search algorithms
• CP

34
Future work along related lines

• If there are no features
• Local search in parameter space to find the best
  default parameter setting Hutter 04
• If we can change strategies while running the
  algorithm
• Reinforment learning for algorithm
  selectionLagoudakis Littman 00
• Low knowledge algorithm control Carchrae and
  Beck 05

35
The End

• Thanks to
• Youssef Hamadi
• Kevin Leyton-Brown
• Eugene Nudelman
• You for your attention ?

36
Related work (1)Finding the best default
parameters

• Find single parameter setting that minimizes
  expected runtime for a whole class of problems
• Generate special purpose code Minton 93
• Minimize estimated error Kohavi John 95
• Racing algorithm Birattari et al. 02
• Local search Hutter 04
• Experimental design Adenso-Daz Laguna 05
• Decision trees Srivastava Mediratta, 05

37
Related work (2) Algorithm selection on a
per-instance base

• Examine instance, choose algorithm that will work
  well for it
• Estimate size of DPLL search tree for each
  algorithm Lobjois and Lemaître, 98
• Sillito 00
• Predict runtime for each algorithmLeyton-Brown,
  Nudelman et al. 02 04

38
Predictive accuracy

• Trained and validated on 100 uf100 instances,
  1000 runs each
• Tested on 100 different uf100 instances, 1000
  runs each

39
My research so far

• Stochastic Local Search
• SAT (SAPS algorithm)
• RNA Secondary Structure Design
• Most Probable Explanation in Graphical Models
• Particle Filtering
• Model-based diagnosis for Mars Rovers
• Automated Parameter Tuning
• Already during MSc for tuning ILS algorithm
• Employing Machine Learning

This talk
