Title: General Logic Design


1
General Logic Design
  • Dr. Nagesh Tamarapalli, PMTS, AMD India
  • August 22, 2009

2
Sequential Circuits
  • Output depends on current input and past history
    of inputs
  • Circuit holds state that represents memory of
    past inputs
  • State is used to generate current output based on
    current input
  • State variables, one or more bits of information
    that forms the state machine

3
Describing sequential circuits
  • State table
  • For each current state specify next state as
    function of inputs
  • Next state F ( current state , input )
  • For each current state specify outputs as
    function of inputs
  • Output G ( current state , input )
  • State Diagram
  • Graphical version of state table

4
Clocked synchronous seq. circuits
  • Also called state machines of finite state
    machines FSM
  • Use edge triggered flip-flops
  • All flip-flops are triggered from the same master
    clock signal and therefore all change state
    together

5
State machine structure ( Moore )
6
State machine structure ( Mealy )
7
State machine structure ( pipelined )
  • Often used in PLD based state machines
  • Outputs taken directly from flip-flops, valid
    sooner after clock edge
  • But the output logic must determine output value
    one clock tick sooner (pipelined)

8
Notation, characteristic equations
  • Q means the next value of Q.
  • Excitation is the input applied to a device
    that determines the next state.
  • Characteristic equation specifies the next
    state of a device as a function of its
    excitation.
  • S-R latch Q S R Q
  • Edge-triggered D flip-flop Q D

9
Characteristic Equations of latches and flipflops
10
Concept of a State Machine
  • Depends on history
  • State diagram
  • State Transition Table
  • Next State
  • O/P Function
  • Timing in State Machines
  • State Time
  • O/P Validity
  • Output is 1 when ever odd sequence of 1s are
    detected

11
Concept of a State Machine
  • Basic Design Approach
  • Understand the problem
  • Obtain a representation of the FSM
  • Perform State Minimization
  • Perform state assignment
  • Choose FFs
  • Important the FSM

State Time
clk
Input
Output
12
Example
  • To detect a sequence 110011 is a serial bit
    stream.
  • Overlapping sequences are allowed
  • Approach
  • Think in terms of functionality, not in terms of
    Hardware
  • Get the functionality right, then think about
    HardWare
  • Functionality captured through a state diagram
  • Sequence of events important, A FSM can remember
    the sequence due to presence of memory.
  • Combinational circuits cannot remember sequence

13
Concept of the Synchronous Sequential Circuit
Example Odd Parity Checker
Assert output whenever input bit stream has odd
of 1's
Reset
0
Even
0
1
Symbolic State Transition Table
1
Odd
1
0
State Diagram
Encoded State Transition Table
14
Concept of the Synchronous Sequential Circuit
Example Odd Parity Checker
Next State/Output Functions
NS PS xor PI OUT PS
Input
Output
NS
T
Q
Input
CLK
D
Q
PS/Output
CLK
Q
R
Q
R
\Reset
\Reset
T FF Implementation
D FF Implementation
Timing Behavior Input 1 0 0 1 1 0 1 0 1 1 1 0
15
Diagram
1
0
0
S1
S2
S3
S4
S5
S6
I
0
1
1
1
1
1
1
1
0
0
0
16
Example
  • In a serial communication channel (X-
    transmiting)
  • all seq of 1s are of odd length,
  • all seq of zero are of even length under normal
    operation
  • Problem
  • To design a circuit that outputs a 1 whenever
    there is a violation of above rule, i.e.
    discrepancy is observed.
  • Approach
  • Required o/p 1 when sequence of even 1s or
    odd Øs

17
Example
  • In a serial communication channel (X-
    transmiting)
  • all seq of 1s are of odd length,
  • all seq of zero are of even length under normal
    operation
  • Problem
  • To design a circuit that outputs a 1 whenever
    there is a violation of above rule, i.e.
    discrepancy is observed.
  • Approach
  • Required o/p 1 when sequence of even 1s or
    odd Øs
  • 4 possible states (min)
  • ----- Odd 1 ?---- Odd Ø
  • ?------ Even 1 ?---- Even Ø

18
Diagram
Reset
Odd 1
Even 1
Odd Ø
Even Ø
