Radiance, reflection and the atmosphere

1
Radiance, reflection and the atmosphere

• January 27, 2003

2
Definition of Remote Sensing

• Remote sensing is the use of the electromagnetic
  spectrum to acquire information about the planet
  without being in physical contact with it.

3
Specifically, we measure radiation produced in
three ways1. Emitted from the surface (thermal
IR)2. Reflected from the surface (solar)3.
Reflected from energy pulses directed at the
surface (RADAR)
4
Coordinate system used with satellite sensors
qZ Zenith angle q Look or incidence angle
qS Solar zenith angle
5
Three kinds of scanners

• Whisk-broom (cross-track)
• Push-broom (along-track)
• Hybrid cross-track

6
Whisk-broom or cross-track scanner Examples
AVHRR, SeaWiFS. Notice how field-of-view (FOV)
changes with look angle.
Advantages single detector scans across the
entire path, can be calibrated on each rotation.
7
Because of off-nadir look angle and Earths
curvature, field-of-view increases with zenith
angle.
8
Push-broom or along-track scanner examples
include Landsat-7, MERIS
Advantages longer dwell time, better
resolution Disadvantages unwieldy number of
sensors for wide swaths
9
Hybrid cross-track MODIS, VIIRS
Advantages multiple sensors in along-track
direction increase dwell time by allowing for a
slower rotation rate. MODIS has 10 such sensors
per channel. But wide swath width leads to a
phenomena called the bowtie effect.
10
Im going to describe radiation in four ways 1.
Radiant flux 2. Plane irradiance 3. Radiant
intensity 4. Radiance.
11
(No Transcript)
12
Irradiance
13
(No Transcript)
14
Black and graybody emission
15
Blackbody emission Plancks law
16
Solar blackbody comparison
5900 Kelvin
Solar irradiance above the Atmosphere
Solar irradiance at the surface (solar zenith 60o)
17
Comparison of the intensity and radiance emitted
by a black and gray body
18
MODIS Sea Surface Temperature
19
Kinds of reflection
20
Water properties, especially in the visible
Real and Imaginary parts of the index of
refraction for water
21
(No Transcript)
22
Two kinds of solar reflection in the visible
Direct surface reflection, diffuse sub-surface
backscatter
23
(No Transcript)
24
(No Transcript)
25
Scatter angle as a function of wind speed (Mobley)
26
Daily MODIS
27
Vertical structure of the Atmosphere
28
Atmospheric constituents
Columnar water equivalents Ocean
4 km
Atmosphere
10 m Water vapor
10 cm
Non-raining cloud liquid water
0.25 mm
29
Ocean and atmospheric properties
Atmospheric water vapor and liquid water
distribution
30
(No Transcript)
31
UV
Visible
Near IR
32
(No Transcript)
33
(No Transcript)
34
SeaWifs Individual Bands
35
End
36
True Color SeaWifs
Processed SeaWifs
37
(No Transcript)
