Core JSP Components

1
Core JSP Components Directives

• CMT3332
• Lecture 4a

2
Built-in JSP Objects

• JSPs create a simplified layer on top of the
  Servlet.
• JSP API provides a series of built-in objects
  (implicit objects) to access the information
  provided by the Servlet objects of different
  classes
• They are created at the beginning of a page (in
  the _jspService method) and directly reference
  objects in the underlying servlet
• However, they are only available to scriptlets
  and expressions

3
Built-in JSP Objects and the Corresponding
Servlet Classes
4
Request Object

• request object represents the current request
  from the browser
• It is an instance of HttpServletRequest, a
  subclass of ServletRequest interface
• ServletRequest and HttpServletRequest
• Contains information about the request from the
  browser such as variables and the setting of the
  browser

5
Request Accessing Parameters

• Request can be used to pass String values in
  parameters from the client to server
• String getParameter(String name)
• Retrieve a single (or first) value of the
  parameter
• String getParamterValues(String name)
• Retrieve multiple values of a parameter as a
  String array
• Enumeration getParameterNames()
• Retrieve an enumeration of all parameter names in
  a request

6
Request Accessing Attributes

• On the other hand, you may want to pass other
  types of data (e.g. Objects). You can use an
  attribute to do this.
• Object getAttribute(String name)
• Similar to getParameter, retrieve the value of
  the attribute
• void setAttribute(String name, Object attr)
• Store a value attr to the named attribute
• void removeAttribute(String name)
• Delete the attribute and its value for the
  request object
• Enumeration getAttributeNames()
• Retrieve and enumeration of all attribute names
  in a request

7
Request Server Request Information

• String getServerName(), int getServerPort()
• Return the hostname/port number which received a
  request (esp. in multi-homed server)
• String getRemoteHost(), String getRemoteAddr(),
  int getRemotePort()
• Return the hostname/IP address/port number which
  sent the request
• String getProtocol()
• Return the protocol used (e.g. http/1.0)
• boolean isSecure()
• Determine whether the request is using a secured
  protocol
• String getMethod()
• Find out what method was used to make the request
  (e.g. get/post)

8
Request Request Data

• Most of the time, request contains a list of
  variables. However, the request content can be
  any other type of data (such as an image).
• int getContentLength(), String getContentType()
• Return the length (in byte) and the content type
  of the request content
• -1 is returned if length is unknown, null is
  returned is content type is unknown
• String getCharacterEncoding()
• Return the encoding type of the content
• BufferedReader getReader(), ServletInputStream
  getInputStream()
• Retrieve a buffered reader (for text) / stream
  (for other binary data) to read the request
  content
• You can only get either one of the reader and the
  stream at one time. If you try use both, an
  IllegalStateException occurs

9
Request Request Header Values

• You sometimes need to examine header values sent
  in the request
• Enumeration getHeaderNames()
• Returns an enumeration of all header names
• String getHeader(String name), Enumeration
  getHeaders(String name)
• Gets a single value / all the values of a
  particular header
• int getIntHeader(String name), long
  getDateHeader(String name)
• Sometimes, the header contains a number or a
  date. You can directly call the above method to
  parse the value to the desired type.
• For getDateHeader(), it returns a long int
  counting the number of millisecond since 1-1-70.
  You can use the value to create a new Date
  instance using the Date class

10
Request About Request URI

• You can separate the URL from the request to
  different parts
• String getRequestURI()
• Returns the URI (resource location) of the
  request URL
• String getContextPath()
• Returns the context path (e.g. path in the server
  under the public_html director) of the request
  URL
• String getPathInfo(), String getPathTranslated()
• Returns any extra path information associated
  with the request URL.
• The extra path information follows the servlet
  path but precedes the query string.
• The latter method will also translate the path to
  a real path
• StringBuffer getRequestURL()
• Returns the whole request URL except the query
  string
• String getQueryString()
• Returns the list of parameters at the end of a
  URL
• Cookie getCookies()
• Returns an array of cookie objects passed in from
  the client

11
Upload Files through HTTP

• It is possible to upload a file to a JSP/Servlet
  through an HTTP POST request
• The difficulty is that the request content is of
  the type multipart/form-data, which is usually
  something like
• multipart/form-data boundary--------------------
  7d02d0343304ce
• The actual content also starts with an additional
  header
• --------------------7d02d0343304ceContent-Disposi
  tion form-data namefoo filenameC\temp\upl
  oadFile\myUpload.txtContent-Type
  application/octet-stream
• The boundary is used to separate the parts in the
  multiple part content
• A blank line following the boundary terminates
  the additional header
• A boundary will also be placed after the content

12
HTML File for File Upload

• lthtmlgt
• ltbody bgcolor"ffffff"gt
• lth1gtFile Uploaderlt/h1gt
• ltform action"upload.jsp" method"post" enctype
  "multipart/form-data"gt
• Please select a file to upload
• ltinput type"file" name"foo"gt ltpgt
• ltinput type"submit" value"Upload File!"gt
• lt/formgt
• lt/bodygt
• lt/htmlgt

13
File Receiver Servlet

• package examples
• import javax.servlet.
• import javax.servlet.http.
• import java.io.
• / Receives a file uploaded via a HTTP POST
  request /
• public class FileReceiverServlet extends
  HttpServlet
• public void service(HttpServletRequest
  request, HttpServletResponse response) throws
  java.io.IOException, ServletException
• // Get the input stream for reading the file
• InputStream in request.getInputStream()
• // The file is always saved to this file
• OutputStream fileOut new BufferedOutputStream(
  new FileOutputStream("uploaded-file"))
• // Create a buffer for reading bytes from
  inputstream
• byte buff new byte4096
• int len
• // Read bytes from the stream and write to the
  file
• while ((len in.read(buff)) gt 0)
• fileOut.write(buff, 0, len)
• fileOut.close()

14
Handling Uploaded File

• In this example, we do not specify the path for
  storing the file. The servlet container will
  decide where it will be stored
• In Tomcat, it supposed to be stored in Tomcats
  bin/ folder
• However, I found the file in Windows system32
  folder
• If you want to store the file in your Web
  applications directory, you can obtain the path
  using
• String path getServletContext().getRealPath(/)

• For JSP, you can use implicit object application
  insteadString path application.getRealPath(/
  )
• You may also use a JSP to receive the file
• Place the code in the service method to a
  scriptlet
• Remember to add an import statement usinglt_at_
  page import java.io. gt
• You can use the implicit object out instead of
  creating a new PrintWriter

15
Handling Uploaded File (contd)

• The file saved from the HTTP request still
  contains the additional header
• To remove the additional header, we need to add
  the some codes to the JSP/Servlet
• Read the content type to extract the boundary
  format and find out its length
• Skip the first lines (additional header) from the
  content until a blank link is read
• Write the rest of the content into a file except
  skipping the last few bytes that represents the
  ending boundary
• In the following example, we have used a
  ByteArrayOutputStream to simplify the task of
  extracting the ending boundary
• You can also extract the file name from the
  additional header using the methods in String

16
File Upload Handler (JSP) (1)

• lt_at_ page import "java.io." gt
• lt // Get the content type
• String contentType request.getContentType()
• // Find out where the boundary string starts
• int boundaryIndex contentType.indexOf("boundary
  ")
• // Get the boundary string
• String boundary contentType.substring(boundaryI
  ndex9)
• // Set a default for the boundary string length
• int boundaryStrLength boundary.length()
• // Get the input stream to read the uploaded
  file
• ServletInputStream servIn request.getInputStrea
  m()
• DataInputStream in new DataInputStream(servIn)

• // Lop off the headers from the content
• //(read until you get a blank line)
• String line
• while ((line in.readLine()) ! null)
• application.log("Got line "line)
• if (line.trim().length() 0) break

17
File Upload Handler (JSP) (2)

• // Create a ByteArrayOutputStream to store the
  bytes read
• ByteArrayOutputStream byteOut new
  ByteArrayOutputStream( request.getContentLength
  ())
• byte buffer new byte4096
• int len
• // Copy the uploaded file to a byte array
• while ((len in.read(buffer)) gt 0)
• byteOut.write(buffer, 0, len)
• byte outBytes byteOut.toByteArray()
• FileOutputStream fileOut new FileOutputStream(
• application.getRealPath("/") "/upload")
• // Write the byteArray to the file, trim the
  closing boundary
• fileOut.write(outBytes,0,outBytes.length-boundary
  StrLength-8)
• fileOut.close()
• // Tell the Web server that the response is HTML
• response.setContentType("text/html")
• // Write the HTML back to the browser
• out.println("lthtmlgtltbodygt")
• out.println("File Accepted, thank you.")

18
Response Object

• When a JSP needs to send data back to the
  browser, it uses the built-in response object
• You can also set the content type, length, and
  character encoding of the file
• void setContentType(String contentType)
• void setContentLength(int contentLength)
• ServletOutputStream getOutputStream()
• Return a servlet output stream for outputing data
  other than characters
• PrintWriter getWriter()
• You can use the built-in object out and send
  the output directly
• String getCharacterEncoding()

19
Response Buffer

• Usually, the JSP response is buffered. There are
  methods for you to control the buffer as you want
• int getBufferSize(), void setBufferSize(int
  bufferSize)get/set the buffer size you cannot
  change the buffer size once you have written
  something out
• void flushBuffer()send the current buffer
  contents to the browser immediately
• void reset()clear the buffer contents
• boolean isCommitted()Once you have send the
  response status to the borwser, the response is
  committed and you cannot modify the header
  value. This method is to check if the response
  object is committed

20
Response Header

• Most header variables can be set through the
  response object using corresponding methods
• You can set the headers directly if the
  corresponding methods are not found
• void setHeader(String header, String value)
• void setIntHeader(String header, int value)
• void setDateHeader(String header, Date value)
• For multiple header values, you use the add
  methods instead of the set methods
• void addHeader(String header, String value)
• void addIntHeader(String header, int value)
• void addDateHeader(String header, Date value)
• You can also check if a header value is already
  existed
• Boolean containsHeader(String header)

21
Response Other Methods

• Redirection void sendRedirect(String URL)
• A forward action (will be taught later) is more
  efficient than using a redirection
• Return Status
• void setStatus(int statusCode)
• void setError(int statusCode)
• void setError(int statusCode, String
  errorMessage)
• URL Encoding
• When you want to send a URL to the browser, you
  need to call encodeURL/encodeRedirectURL.
• The methods will append a session ID parameter to
  the URL if the browser does not support cookies
• String encodeURL(String url)
• String encodeRedirectURL (String url)
• Sending Cookies
• void addCookie(Cookie cookie) will be discussed
  later in this chapter

22
JSP I/O Streams out Object

• ServletInputStream and ServletOutputStream is
  normally used to handle binary data other than
  text
• ServletInputStream extends InputStream with a
  readLine method added
• ServletOutputStreasm extends OutputStream with
  all print and println methods as in PrintStream
  class
• out is a JspWriter object acts like a PrintWriter
• out supports almost all print, println and write
  (for char arrays with offset and length) methods
• You can control the buffer of JspWriter, but you
  are advised to use the default setting

23
Session Object

• session object stores information between browser
  requests. You can also control the session expiry
  time through the session object
• Methods for storing and retrieving session
  information
• Object getAttribute(String name)
• void setAttribute(String name, Object value)
• void removeAttribute(String name)
• Enumeration getAttributeNames() this return an
  enumeration containing all attributes stored in
  the session
• Methods controlling session termination
• void invalidate() useful for invalidating the
  users session when the user logs out
• void setMaxInactiveInterval(int interval) / int
  getMaxInactiveInterval() change/retrieve the
  session timeout (in minutes)

24
Session Status

• Each session object has an unique identifier
  (unique in your servlet engine)
• String getId()
• boolean isNew() check if a session is just
  created
• long getCreationTime()
• long getLastAccessedTime()
• Access time is counted only if the access is from
  the request (browser)

25
pageContext Object

• A central repository for information that a JSP
  might need to obtain
• Create at the beginning of the servlet for the
  JSP and destroy at the end of it
• Use to intialize / retrieve the objects for the
  built-in variables
• Capable to scan for attributes and attribute
  names among all scope (page, request, session and
  application)
• Facilitate forward and include of servlet or JSP

26
pageContext Accessing Own Attributes

• An attribute stored in pageContext has a scope of
  page only
• JavaBeans with a page scope are also stored as
  attributes in pageContext
• Methods for storing, retrieving and removing
  attributes in pageContext
• Object getAttribute(String name)
• void setAttribute(String name, Object o)
• void removeAttribute(String name)

27
pageContext Accessing Attributes of Other Scopes

• Accessing attributes in any other scope
• Object getAttribute(String name, int scope)
• void setAttribute(String name, Object o, int
  scope)
• void removeAttribute(String name, int scope)
• Scope are defined by constants PAGE_SCOPE,
  REQUEST_SCOPE, SESSION_SCOPE and
  APPLICATION_SCOPE in pageContext.
• Enumeration getAttributeNamesInScope(int scope)
  retrieves all attribute names in the given scope
• Object findAttribute(String name) searches for
  an attribute value through all scopes

28
Forwarding and Including

• Normally we use action tags (will be taught
  later) ltjspincludegt and ltjspforwardgt to do the
  tasks
• If forward and include services are needed inside
  a scriptlet, you can call the following methods
  from pageContext
• void forward (String url)
• void include (String url)
• void include (String url, boolean flush) you
  can prevent the buffer being flushed prior to the
  include statement by setting flush to false

29
Cookie

• A cookie is a value stored on the browser
• The value is sent to the server whenever the
  browser requests a page
• Data such as username and session ID are usually
  stored in the browser and sent as a cookie
• Not all cookies are sent to a server. Only the
  cookies that match the server's domain and path
  will be sent
• Constructor Cookie(String name, String value)
• String getName(), String getValue() returns the
  name and value of a cookie
• void setValue(String newValue) changes the cookie
  value
• String getDomain(), void setDomain(newDomain)
  gets/sets the domain of the cookie
• String getPath(), void setPath(String newPath)
  gets/sets the server path of the cookie
• int getMaxAge(), void setMaxAge(int maxAge)
  gets/sets the expire time for a cookie (in
  seconds)

30
Other JSP Objects

• config object
• gives you access to configuration information for
  your JSP
• page object
• a reference to the current JSP, seldom used
• exception object
• gives you access to the exception that caused the
  error page

31
JSP Directives

• lt_at_ gt is a directive tag. There are three
  directives in JSP specification
• page directives for different page options
• include directives enables you to include other
  files at compile time
• taglib directives enables you to include an
  external custom JSP tag library

32
Page Directive

• Setting page option in the form of namevalue,
  e.g. lt_at_ page info"First JSP" gt
• You cannot have two page directives with the same
  option in the same page except import and
  pageEncoding option
• Common page directives
• contentType specifies the kind of data that is
  returned. Default type is text/html. Can also be
  combined with the character encoding for the
  response. Example lt_at_ page contentType"text/htm
  lcharsetISO-8859-1" gt
• pageEncoding specifies the character encoding
  used in the JSP. Default value is ISO-8859-1
  (Latin 1)

33
Page Directive (cont'd)

• language default is java, which is the only
  language in the current specification
• import imports the necessary packages. Can be
  used to import multiple packageslt_at_ page
  import"java.sql.,java.util.,java.math." gt
• info provides a description of the servlet
• session denotes if session is used, default is
  true
• buffer control the JSP buffer. Turn off buffer
  by setting the buffer option to "none"E.g.,
  lt_at_page buffer"16" gt sets buffer to 16 KBOnly
  the minimum size is set. A larger size may be
  used by the JSP engine

34
Page Directive (cont'd)

• autoFlush automatically flushes the buffer when
  it fills. Default value is true. If set false,
  JSP Engine will throw an exception
• errorPage denotes the page used to display
  error during the current page is runlt_at_ page
  errorPage"handleError.jsp" gt
• isErrorPage indicates if the current JSP is
  used as the error Page of another JSP
• extends enables you to specify the superclass
  for your JSP. Usually HttpServlet class is
  extended Two methods must be added to the
  superclass jspInit() and jspDestory().In your
  service method, you must invoke _jspService
  method in the JSP

35
isThreadSafe Option in Page Directive

• By default, all JSPs are considered thread-safe
• i.e., the servlet container allows multiple
  threads to use the same JSP instance at the same
  time.
• You may set this option to false to acknowledge
  the servlet container that your page can be
  accessed by one thread at one time
• However, the checking method has been deprecated
  in Servlet 2.4 (current) specification
• You should in fact try to guarantee your JSPs are
  thread-safe

36
Example on Error Page Related Options

• This is the JSP error page handling the error
• lt_at_ page isErrorPage"true" gt
• lthtmlgt ltbodygt
• lth1gtErrorlt/h1gt
• An error occurred while processing your request.
  ltpgt
• The error message is lt exception.getMessage()
  gt.
• lt/bodygt lt/htmlgt

• This is a page that generate an exception
• lt_at_ page errorPage "ErrorPage.jsp" gt
• lthtmlgt ltbodygt
• You shouldn't see this because an exception will
  be thrown soon.
• lt if (true) throw new RuntimeException(
  "You've got an error!")
• gt
• lt/bodygt
• lt/htmlgt

37
Example on JSP superclass

• import javax.servlet.
• import javax.servlet.http.
• import javax.servlet.jsp.
• public abstract class JSPSuperclass extends
  HttpServlet
• implements HttpJspPage
• // methods must be declared final
• // for the class is a superclass for JSP
• public final void init(ServletConfig c) throws
  ServletException
• super.init(config) // Superclass do its
  initialization
• jspInit() // Initialize the JSP
• public final void destroy()
• super.destroy()
• jspDestroy()
• public final ServletConfig getServletConfig()
• return super.getServletConfig()
• public final void service(ServletRequest req,
  ServletResponse res) throws ServletException,
  java.io.IOException

38
Example on JSP superclass (cont'd)

• public final void service(HttpServletRequest
  req, HttpServletResponse res) throws
  ServletException, java.io.IOException
• // DEMO ALERT! Put a dummy data item in here to
  show
• // how the subclassing works
• request.setAttribute("Demo", "Hello from your
  superclass")
• // Now call the _jspService method to run the
  JSP
• _jspService(request, response)
• // Provide a dummy jspInit method
• public void jspInit()
• // Provide a dummy jspDestroy method
• public void jspDestroy()
• // The _jspService method is implemented by
• // the servlet generated from the JSP page
  source
• public abstract void _jspService(HttpServletReque
  st request, HttpServletResponse
  response) throws ServletException,
  java.io.IOException

39
Include Directive

• Using include tag can make your JSPs more
  readable
• To include another file at compile time, we use
  the include directive
• lt_at_ include file"include_file" flush"true" gt
• flush option will indicate the output buffer to
  flush before the file is included
• You can use an identical file for the common
  feature in all pages in your application.
• When you want to change the common feature, you
  need to change one file (the one that stores that
  common feature) only
• Only Tomcat will detect if your included file has
  been changed. Other servlet container does not
  guarantee the checking

40
JSP Standard Action

• JSP action tags ltjspXXX /gt cause programmatic
  behavior to occur
• These actions are also known as JSP standard
  action

41
Including Files in Runtime

• If you want to include a servlet/JSP during
  runtime, you can use include action tag
• ltjspinclude page"include_file" flush"true" /gt
• flush attribute indicates whether the output
  buffer should be flushed before the file is
  included. Default value is false
• Passing parameters to an included file
• ltjspinclude page"somePage" flush"true"gt ltjspp
  aram name"parameter" value"value"
  /gtlt/jspincludegt
• Note that the closing tag can be in a line
  different from opening tag
• Only the including page can use the parameter

42
Including JSP into a Servlet

• In servlet, we need to obtain a request
  dispatcher to include a JSP/text file and pass
  the current request and response to the the
  dispatcher
• RequestDispatcher d request.getRequestDispatche
  r("destinationURL")d.include(request,
  response)
• The output from the included resource is written
  to the stream of the response object
• The parameter needed by the JSP should be
  attached to the URL as a query string

43
Example of Include Directive

• The main page
• lthtmlgt
• ltbodygt
• lt_at_ include file"Header.html" gt
• ltpgt
• Welcome to ltigtIt's a Crazy Worldlt/igt
• ltpgt
• lt/bodygt
• lt/htmlgt

• The included header
• lttable bgcolor"0000ff"gt
• lttrgtlttdgtltimg src"face.jpg" alignleftgt
• lttdgtlth1gtltfont color"ffff00"gtIt's a Crazy
  World lt/fontgtlt/h1gt
• lttdgtltimg src"face.jpg" alignrightgt
• lt/tablegt

44
Example of Including JSP at Runtime

• Support.jsp, with Menu.jspf shown in next page
• lthtmlgt ltbody bgcolor"ffffff"gt
• lt_at_ include file"Header2.html"gt
• ltjspinclude page"Menu.jspf" flush"true"gt
• ltjspparam name"highlighted"
  value"aboutUs"/gt
• lt/jspincludegt
• ltpgt
• We are just humble zither players who want to
  let the world know about these wonderful
  instruments. Plus, the amalgamatedzithers.com
  domain was still available.
• lt/bodygt lt/htmlgt

45
Example of Including JSP at Runtime

• lt // See which menu item should be highlighted
• String hl request.getParameter("highlighted")
• // Set the names for the individual menu items
• String welcome "welcome.jpg"
• if (hl.equalsIgnoreCase("welcome")) welcome
  "welcomeS.jpg"
• String products "products.jpg"
• if (hl.equalsIgnoreCase("products")) products
  "productsS.jpg"
• String services "services.jpg"
• if (hl.equalsIgnoreCase("services")) services
  "servicesS.jpg"
• String support "support.jpg"
• if (hl.equalsIgnoreCase("support")) support
  "supportS.jpg"
• String aboutUs "aboutUs.jpg"
• if (hl.equalsIgnoreCase("aboutUs")) aboutUs
  "aboutUsS.jpg"
• gt
• lttable cellpadding"0" cellspacing"0"gt lttrgt
• lttdgtlta href"welcome.jsp"gtltimg src"ltwelcomegt"
  border"0"gtlt/agt
• lttdgtlta href"products.jsp"gtltimg
  src"ltproductsgt" border"0"gtlt/agt
• lttdgtlta href"services.jsp"gtltimg
  src"ltservicesgt" border"0"gtlt/agt
• lttdgtlta href"support.jsp"gtltimg src"ltsupportgt"
  border"0"gtlt/agt

46
Example of Passing Parameters to an Included JSP

• MainForm.jsp
• lthtmlgt
• ltbody bgcolor"ffffff"gt
• ltjspinclude page"IncludedForm.jspf"
  flush"true"gt
• ltjspparam name"myVar" value"Passed from main"
  /gt
• lt/jspincludegt
• lt/bodygt
• lt/htmlgt

• IncludedForm.jspf
• ltpregt
• lt String myVar request.getParameter("myVar")
• String myVars request.getParameterValues("my
  Var")
• out.println("myVar"myVar)out.println("The
  values of myVar are")
• for (int i0 i lt myVars.length i)
• out.println(myVarsi)
• gt
• lt/pregt

47
Forwarding Using forward Action Tag

• JSP action tag for forwarding is very similar to
  the including syntax
• ltjspforward page"destination" /gt
• Your original page is replaced with the new page
  even any output you might have to sent to the
  buffer will be cleared
• You may get an IllegalStateException when you
  forward a page this may be because your buffer
  has been flushed to the client before the file is
  forwarded
• You can also pass your parameters to a forward
  page using ltjspparamgt tag

48
Forwarding from a Servlet

• Similar to including a file into a servlet,
  forward to a JSP can be done in a servlet using a
  request dispatcher
• RequestDispatcher d request.getRequestDispatche
  r("destURL")d.forward(request, response)
• Similarly, you can pass your parameters through a
  query string appended to the destination URL

49
Example of JSP Forwading

• lthtmlgt
• ltbodygt
• You should never see me because my output is
  erased before forwarding.
• ltjspforward page"ForwardedPage.jsp"/gt
• lt/bodygt
• lt/htmlgt

50
Example of Forwarding from a Servlet

• import javax.servlet.
• import java.io.
• public class ForwarderServlet extends
  GenericServlet
• public void service(ServletRequest req,
  ServletResponse resp) throws IOException,
  ServletException
• // Tell the web server that the response is HTML
• response.setContentType("text/html")
• // Get the PrintWriter for writing out the
  response
• PrintWriter out response.getWriter()
• // Write the HTML back to the browser
• out.println("lthtmlgt ltbodygt")
• out.println("You should never see this")
• out.println("because my output buffer gets
  erased")
• // Get the request dispatcher for the JSP to
  include
• RequestDispatcher dispatcher
• request.getRequestDispatcher("/ForwardedPage.jsp
  ")
• dispatcher.forward(request, response)
• out.println("lt/bodygt lt/htmlgt")
