FV6020 Brochure

1
High Performance/price ratio IP Phone

• FV6020 Brochure

2
FV6020 IP Phone

• Exterior Features
• Functionality Features
• Technological Features
• user-friendly.

3
Exterior Features

• LCD supports English, Spanish and Czech LCD can
  clear display the Ethernet mode and even connect
  state, SIP registration state
• Reliable quality and ingenious structure can be
  fixed securely on wall with certain angle, or can
  be put on flat desk, to make dialing more
  comfortable.

4
Functionality Features

• HotlineMaking call directly as soon as picking
  up the handset or pressing the Speaker key,
  applied to bank branch , where only old men live
  and so on

Hotline
5
Functionality Features

• Limitation of calling out and Black list
• (Limitation can be set up to forbid dialing
  some special numbers The blacklist can refuse
  some incoming calls you hate.)

Limitation of calling
Blacklist
6
Technological Features

• INCA IP PSB 21553 E from INFINEON as main chip to
  ensure hi-quality voice and offer crystal voice
  of hearing and speaker, working with special
  mould?hearing and speaker designed according to
  acoustic regulation
• Unique DSP processing technology to enable
  hands-free echo cancellation reach 96 ms.

7
Technological Features

• Realize Router and Bridge mode via VLAN
  technology

Route Model
Bridge Model
8
Technological Features

• Multi-Lines
• FV6020 can get default 2SIP accounts , that is,
  can register into 2 different ISP at the same
  time

a. Can register into 2 different servers
(different countries or areas) at the same time
and get 2 different phone numbers b. Can accept
call from any server and do HOLD?CONFERENCE
between the different lines etc.
9
Technological Features

• Multi-Protocols
• Supporting SIP and IAX2 at the same time.

a.A can make call to B?C?D via Asterisk server
with IAX2 b.FV6020 can make call to PSTN phones
through SOFTSWITCH with SIP .
10
Technological Features

• Unique dial plan feature can set various of
  dial-up rules flexibly
• Unique bandwidth control technology can restrict
  bandwidth data to ensure hi-quality voice and
  offer crystal voice of hearing and speaker.
• Similarly, 802.1 P / Q and Diffserv give voice
  transmission in internet priority.

11
User-Friendly

• User can select DHCP?PPPoE or Static to make
  configuration.
• can make configure through HTTP and TFTP, and
  download configuration files automatically,
  working with IPPBX or server. user do not need
  to set account and password by hand any more
• Syslog can offer diary information of end users
  to ISP at any time.

12
Thank you!

• FANVIL ELECTRONICS Co., Ltd.
