Measurement

1
Measurement
2
(No Transcript)
3
(No Transcript)
4
CHAPTER 1 MEASUREMENTObjectives

• 1. Be able to list some examples of measurement
  and discuss their importance to man.
• 2. List the five senses with which we examine
  our environment and identify the one from which
  most of our information comes.
• 3. List the four fundamental properties of
  nature which we seek to measure.
• 4. Be able to list standard units for each of
  the four fundamental properties.
• 5. Distinguish between fundamental units and
  derived units.
• 6. Define and write the formula for density.

5
Objectives

• 7. Be able to write conversion factors for
  mass, length, and volume.
• 8. Define the following terms degree,
  circumference, diameter, pi, radius
• 9. Distinguish between the terms accuracy and
• precision.
• 10. Be able to express numbers in powers of ten.
• 11. Be able to define, write the equation for,
  and calculate percentage error.
• 12 Be able to change numbers from standard
  notation to powers of ten notation.
• 13. Write the values of prefixes and
  abbreviations.

6
LIST FIVE SENSES

• SIGHT
• HEARING
• TOUCH
• SMELL
• TASTE

7
Figure 1.1aSome Optical Illusions
8
Figure 1.1bSome Optical Illusions (continued)
9
Figure 1.1cSome Optical Illusions (continued)
10
Figure 1.1dSome Optical Illusions (continued)
11
Concepts

• A meaningful idea used to describe phenomena that
  happen in our environment.
• It can be stated in words, symbols or formulas.

12
Galileo

• S c i e n t i f i c M e t h o d

13
S c i e n t i f i c Method
Hypothesis

• A Tentative explanation of an observed event.

14
Scientific MethodExperimentation

• Experiment is designed to test hypothesis.
• Independent variable vs. dependent variable
• Results must be reproducible
• Conclusion must accept or reject hypothesis

15
S c i e n t i f i c Theory

• A tested explanation of a hypothesis which
  stands up to testing over a period of time.

16
M e a s u r e m e n t S y s t e m
s

• in order to collect data we need to measure
  accurately. We need a measurement system.


17
List Examples Of Measurement

• Making accurate and precise measurements helps us
  to improve our understanding of the world and
  enables us to predict how future events will turn
  out under similar circumstances.

18
(No Transcript)
19
FUNDAMENTAL PROPERTIES OF NATURE

• LENGTH-measurement of space in any direction
• MASS-amount of matter an object contains
• TIME-continuous forward flowing of events
• ELECTRIC CHARGE

20
Mass is a Fundamental Quantity and Remains
Constant Weight Varies
Section 1.4
21
MEASUREMENT TOOLS
22
FUNDAMENTAL UNITS VSDERIVED UNITS

• AREA L X W
• VOLUME L x W x H
• SPEED D / T
• DENSITY M / V

• LENGTH
• MASS
• TIME
• CHARGE

23
FORMULA FOR DENSITY

• DENSITY MASS
• VOLUME
• DENSITY OF WATER 1

24
(No Transcript)
25
Standard units

• A fixed and reproducible value for the purpose of
  taking measurements.
• Measurement is a comparison of physical quantity
  with a standard unit

26
A Second of Time
Originally defined as a fraction of the average
solar day.
Section 1.4
27
A Second of Time
Defined by the radiation frequency of the Cs133
atom
Section 1.4
28
Figure 1.4aThe Meter
29
Figure 1.4bThe Meter (continued)
30
Figure 1.4cThe Meter (continued)
31
Kilogram Standard
U.S. Prototype 20 Kilogram, at NIST in
Washington, D.C. Actually 0.999 999 961 kg of
the standard in Paris
Section 1.4
32
Figure 1.9The Kilogram
33
STANDARD UNITS
34
S I T h e I n t e r n a t i o n a l
S y s t e m

• U n i t o f l e n g t h . . . M e t e r
• U n i t o f m a s s . . . K i l o g r a m
• U n i t o f v o l u m e . . . L i t e r
• U n i t o f t e m p . . . 0 C e l s i u s
• U n i t o f t i m e . . . S e c o n d

35
Standard Units

• British system foot pound sec
• fps
• Metric system meter kilogram
• mks
• centimeter gram second
• cgs

36
Figure 1.10bLiter and Quart
37
PREFIXES
38
COMMON SI UNITS
39
Metric Unit Chart

• Kilo-hecto-deka-basic-deci-centi-milli
• 1 10 100 1000

• .005 .05 .5
  5

40
CONVERSION FACTORS

• LENGTH 1 in 2.54 cm
• MASS 2.2 lbs 1 kg
• VOLUME 1.O6 qts 1 liter
• 1 in 2.54 cm
• 2.54 cm 1 in

41
Give them 2.54 cm and theyll take 1.61 km.
42
30 grams of prevention is worth 0.454 kg of cure!
43
F a c t o r - L a b e l
M e t h o d

• W h a t i s i t ?

44
F a c t o r - L a b e l

• T h e m o s t i m p o r t a n t
  m a t h e m a t i c a l p r o
  c e s s i n c h e m i s
  t r y .
• T r e a t s n u m b e r s a n d
  u n i t s e q u a l l y .
• M u l t i p l y w h a t i s g i v e n b y
  f r a c t i o n s e q u a l t o o n e
  t o c o n v e r t u n i t s .

45
F a c t o r - L a b e l
A f r a c t i o n e q u a l t o o n e
W h a t i s g i v e n
46
F a c t o r - L a b e l
C o n v e r t 1 0 0 0 g r a m s t o p o u
n d s
47
F a c t o r - L a b e l
C o n v e r t 1 0 0 0 g r a m s t o p o u
n d s
1 p o u n d
1 0 0 0 g

2 . 2 p o u n d s
4 5 4 g
48
F a c t o r - L a b e l
C o n v e r t 6 5 m i l e s / h o u r t
o m e t e r s / s e c o n d



49
F a c t o r - L a b e l
C o n v e r t 6 5 m i l e s / h o u r t
o m e t e r s / s e c o n d
h o u r s e c o n d
6 5 m i l e s h o u r
m e t e r s m i l e s

50
Experimental Error

• Uncertainty-measurement is a comparison of the
  unknown quantity with the standard unit
• systematic error-always in the same direction
  improperly calibrated watch thats too slow
  speedometer or bad vision

51
Error

• Random error- unknown and unpredictable in either
  direction
• temperature
• pressure
• normal variations

52
ACCURACY VS PRECISION

• ACCURACY - HOW CLOSE A MEASUREMENT COMES TO THE
  TRUE VALUE (ACCEPTED VALUE)
• PRECISION- AGREEMENT AMONG REPEATED MEASUREMENTS
  (SPREAD) REPRODUCIBILITY

53
PERCENTAGE ERROR

• ACC VALUE - EXP VALUE X 100
• ACC VALUE

54

• When we use hand calculators we may end up with
  results like 6.8/1.67 4.0718563
• Are all these numbers significant?

Section 1.7
55
Significant Figures

• General Rule Report only as many significant
  figures in the result as there are in the
  quantity with the least.
• 6.8 cm/1.67 cm 4.1(round off 4.0718563)
• 6.8 is the limiting term with two SF
• 5.687 11.11 16.80 (round up 16.797)
• 11.11 is the limiting term with four SF

Section 1.7
56
Significant Digits

• Digits other than zero are always significant.
• 96 2 significant digits
• 61.4 3 significant digits
• 0.52 2 significant digits

57
Significant digits

• One or more final zeros used after the decimal
  point are always significant.
• 4.72 3 significant digits
• 4.7200 5 significant digits
• 82.0 3 significant digits

58
Significant digits

• Zeros between two other significant digits are
  always significant.
• 5.029 4 significant digits
• 306 3 significant digits

59
Significant digits

• Zeros used for spacing the decimal point are not
  significant. The zeros are placeholders only.
• 7000 1 significant digit
• 0.00783 3 significant digits

60
POWERS OF TEN

• TABLE 1.3 PAGE 21
• 100 1
• 101 10
• 102 100
• 103 1000
• 104 10000

61
POWERS OF TEN NOTATION

• 186 000 1.86 x 105
• .025 2.5 x 10-2

62
Examples of Numbers Expressed in Powers-of-10
Notation
Section 1.7
63
Scientific Notation

• .0001
• 1 x 10-4
• .00000197
• 1 x 10-6
• 98750
• 1 x 104

64
Rules for Scientific Notation

• The exponent, or power-of-10, is increased by one
  for every place the decimal point is shifted to
  the left.
• 360,000 3.6 x 105
• The exponent, or power-of-10, is decreased by one
  for every place the decimal point is shifted to
  the right.
• 0.0694 6.94 x 10-2

Section 1.7
65
Scientific Notation

• 2.5 x 10-7
• .00000025
• 9.3 x 106
• 9 300 000

66
Chapter 1Practice problems
67
What is the volume of a liter in m3 and mm3

• 1 Liter ____ m3
• 1 liter1000ml1000cm3
• 1m100cm
• 1m3106cm3
• 1000cm3 x 1m3 .001m3
• 1L 106cm3

68

• 1m1000mm
• 1m3109mm3
• .001m3 x 109mm3 106mm3
• 1 1m3

69
2. Show that one cubic meter contains 1000 L

• 1cm31ml
• 1000cm31000ml
• 1m100cm
• 1m3106cm3
• 1m3 x 106cm3 x 1ml x 1L
• 1 1m3 1cm3 1000ml

70
4. What is the mass of this volume of water in
kilograms and in grams?

• 20cm x 20cm 30cm 12 000cm3
• 12 000cm312 000ml
• 12 000ml12 000g
• 12 000g12kg

71
5. What would the volume of water be?

• 1ml1cm31g
• .085kg85g
• 1000
• 85g85ml

72
9. Justify you answer40 MPH60km/h

• 40mph x 1.609km/h 64 mph
• 1 1mph

73
11. It took 300 L of gasoline to fill up the
cars tank.

• 300L x 1g 79 gal
• 1 3.79L
• Will your tank hold 79 gallons of gas!

74
14. Which is faster 90km/h or 60mph

• 60 mph x 1.609km/h 96.54km/h
• 1 1mph

75
15. What is the density in g/cm3

• D m/v
• D.500kg500g
• D500g 7.9g/cm3
• 63cm3

76
18. rounding

• A. 1.1 x 102
• B. 2.1 x 10-3
• C. 9.4 x 103
• D. 3.4 x 10-4

77
19. Round

• (3.2m x 1.04m) /0.015 m2.2 x 102 m
• 220 m

78
20. Round 6.7544242

• 2.15 x 3.146.7544242
• Round to 3 significant digits
• 6.75

79
21

• A. 7.3 x 104 73 000
• B. 3.25 x 10-4.000325
• C. 0.399 x 103399
• D. 0.234 x 10-20.00234

80
24.

• A. 40 megabytes40x 106 bytes
• B. 150ml 150 x 10-3 L
• C. 250mg 250 x 103g
• D. 500kilobucks500 x 103 bucks

81
27. pizza

• 154 in
• Apie r2
• A3.14 x 3.5238.5 in2
• A3.14 x 72154 in2
• 154/38.54 times larger
