Analysis of Computer Algorithm

1
Analysis of Computer Algorithm

• Pradondet Nilagupta
• (pom_at_ku.ac.th)
• Department of Computer Engineering
• Kasetsart University

2
What is algorithm? (1/2)

• Algorithm
• Recipe for getting things done successfully
• "Recipe" - well defined sequence of computational
  steps
• "things" - computational problems specifying an
  input/output relation
• "done" - in finite steps and time
• "successfully" - correctly
• a step-by-step procedure for solving a problem in
  a finite amount of time.

3
What is algorithm? (2/2)

• Any special method of solving a certain kind of
  problem (Webster Dictionary)
• An algorithm is "a process, or rules, for
  mechanical calculation" (Oxford Concise).

4
Example What is an Algorithm?
Problem Input is a sequence of integers stored
in an array. Output the
minimum.
Algorithm
INPUT
OUTPUT
instance
m a1 for I2 to size of input if m gt
aI then maI return s
11
25, 90, 53, 23, 11, 34
Data-Structure
m
5
What is a program?

• A program is the expression of an algorithm in a
  programming language
• a set of instructions which the computer will
  follow to solve a problem

6
Why do we analyze about them?

• understand their behavior, and (Job -- Selection,
  performance, modify)
• improve them. (Research)

7
What do we analyze about them?

• Correctness
• Does the input/output relation match algorithm
  requirement?
• Amount of work done (aka complexity)
• Basic operations to do task
• Amount of space used
• Memory used

8
What do we analyze about them?

• Simplicity, clarity
• Verification and implementation.
• Optimality
• Is it impossible to do better?

9
Importance of Analyze Algorithm

• Need to recognize limitations of various
  algorithms for solving a problem
• Need to understand relationship between problem
  size and running time
• When is a running program not good enough?
• Need to learn how to analyze an algorithm's
  running time without coding it

10
Importance of Analyze Algorithm

• Need to learn techniques for writing more
  efficient code
• Need to recognize bottlenecks in code as well as
  which parts of code are easiest to optimize

11
Complexity

• The complexity of an algorithm is simply the
  amount of work the algorithm performs to complete
  its task.

12
RAM model

• has one processor
• executes one instruction at a time
• each instruction takes "unit time
• has fixed-size operands, and
• has fixed size storage (RAM and disk).

13
What is the running time of this algorithm?

• PUZZLE(x)
• while x ! 1     if x is even      then  x x
  / 2      else x 3x 1
• Sample run  7, 22, 11, 34, 17, 52, 26, 13, 40,
  20, 10, 5, 16, 8, 4, 2, 1

14
The Selection Problem (1/2)

• Problem given a group of n numbers, determine
  the kth largest
• Algorithm 1
• Store numbers in an array
• Sort the array in descending order
• Return the number in position k

15
The Selection Problem(2/2)

• Algorithm 2
• Store first k numbers in an array
• Sort the array in descending order
• For each remaining number, if the number is
  larger than the kth number, insert the number in
  the correct position of the array
• Return the number in position k
• Which algorithm is better?

16
Define Problem

• Problem Description of Input-Output
  relationship
• Algorithm A sequence of computational step
  that transform the input into the output.
• Data Structure An organized method of
  storing and retrieving data.
• Our task Given a problem, design a correct
  and good algorithm that solves it.

17
Example Algorithm A
Problem The input is a sequence of integers
stored in array. Output the minimum.
Algorithm A
18
Example Algorithm B
This algorithm uses two temporary arrays.

• copy the input a to array t1
• assign n ? size of input
• While n gt 1
• For i ? 1 to n /2
• t2 i ? min (t1 2i , t1 2i
  1 )
• copy array t2 to t1
• n ?n/2
• 3. Output t21

19
Visualize Algorithm B
7
8
9
5
6
11
34
20
Loop 1
5
8
7
6
Loop 2
7
5
Loop 3
5
20
Example Algorithm C
Sort the input in increasing order. Return
the first element of the sorted data.
black box
Sorting
21
Example Algorithm D
For each element, test whether it is the minimum.
22
Which algorithm is better?

• The algorithms are correct, but which is the
  best?
• Measure the running time (number of operations
  needed).
• Measure the amount of memory used.
• Note that the running time of the algorithms
  increase as the size of the input increases.

23
What do we need?

• Correctness Whether the algorithm computes
  the correct solution for all instances.
• Efficiency Resources needed by the algorithm
• 1. Time Number of steps.
• 2. Space amount of memory used.
• Measurement model Worst case, Average case
  and Best case.

24
Many important problems have no useful,
algorithmic solution

• intractable computation known algorithms for the
  problem require too much time and/or memory to be
  useful (example finding an optimal route)
• noncomputable problem a problem which no
  algorithm can solve (example determining whether
  two programs are equivalent)
• unknown algorithm a problem for which no one
  knows an algorithm (example understanding
  English)

25
Algorithms vary in efficiency
example sum the numbers from 1 to n
efficiency space 3 memory cells time
t(step1) t(step 2)
n t(step 4) n t(step 5)

• space requirement is constant (i.e. independent
  of n)
• time requirement is linear (i.e. grows linearly
  with n). This is written O(n)

to see this graphically...
26
Algorithm Is time requirements
The exact equation for the line is unknown
because we lack precise values for the constants
m and b. But, we can say time is a linear
function of the size of the problem time O(n)
27
Algorithm II for summation
First, consider a specific case n 100.
The key insight, due to Gauss the numbers can
be grouped into 50 pairs of the form 1 100
101 2 99 101 . . . 50
51 101
Second, generalize the formula for any (even) n
sum (n / 2) (n 1)
Time requirement is constant. time O(1)
28
Sequential Search of a student database
What is this algorithms time requirements? Hint
focus on the loop body
29
Time requirements for sequential search
because the amount of work is a constant multiple
of n, the time requirement is O(n) in the worst
case and the average case.
30
O(n) searching is too slow
Consider searching UTs student database using
sequential search on a computer capable of
20,000 integer comparisons per second n
150,000 (students registered during past 10
years) average case 150,000 comparisons
1 seconds 3.75
seconds 2
20,000 comparisons
x
31
Searching an ordered list is faster an example
of binary search
32
The binary search algorithm
assuming that the entries in student are sorted
in increasing order,
1. ask user to input studentNum to search for 2.
set found to no 3. while not done searching
and found no 4. set middle to the
index counter at the middle of the student
list 5. if studentNum studentmiddle then set
found to yes 6. if studentNum lt
studentmiddle then chop off the last half of
the student list 7. If studentNum gt
studentmiddle then chop off the first half of
the student list 8. if found no then print
no such student else ltstudentNum found at
array index middlegt
33
The binary search algorithm
assuming that the entries in student are sorted
in increasing order,
1. ask user to input studentNum to search for 2.
set beginning to 1 3. set end to n 4. set found
to no 5. while beginning lt end and found
no 6. set middle to (beginning end) / 2
round down to nearest integer 7. if
studentNum studentmiddle then set found to
yes 8. if studentNum lt studentmiddle then
set end to middle - 1 9. if studentNum gt
studentmiddle then set beginning to middle
1 10.if found no then print no such
student else ltstudentNum found at array
index middlegt
34
Time requirements for binary search
At each iteration of the loop, the algorithm cuts
the list (i.e. the list called student) in
half. In the worst case (i.e. when studentNum
is not in the list called student) how many times
will this happen?
n 16 1st iteration 16/2
8 2nd iteration 8/2 4 3rd iteration 4/2
2 4th iteration 2/2 1
the number of times a number n can be cut in half
and not go below 1 is log2 n. Said another way
log2 n m is equivalent to 2m n
In the average case and the worst case, binary
search is O(log2 n)
35
This is a major improvement
36
Conclusions

• The design of an algorithm can make the
  difference between useful and impractical.
• Efficient algorithms for searching require lists
  that are sorted.

37
Time vs. Size of Input

• Measurement parameterized by the size of the
  input.
• The algorihtms A,B,C are implemented and run in a
  PC.
• Algorithms D is implemented and run in a
  supercomputer.
• Let Tk( n ) be the amount of time taken by the
  Algorithm 2(k).

1000
500
38
Methods of Proof

• Proof by Contradiction
• Assume a theorem is false show that this
  assumption implies a property known to be true is
  false -- therefore original hypothesis must be
  true
• Proof by Counterexample
• Use a concrete example to show an inequality
  cannot hold
• Mathematical Induction
• Prove a trivial base case, assume true for k,
  then show hypothesis is true for k1
• Used to prove recursive algorithms

39
Review Induction

• Suppose
• S(k) is true for fixed constant k
• Often k 0
• S(n) ? S(n1) for all n gt k
• Then S(n) is true for all n gt k

40
Proof By Induction

• ClaimS(n) is true for all n gt k
• Basis
• Show formula is true when n k
• Inductive hypothesis
• Assume formula is true for an arbitrary n
• Step
• Show that formula is then true for n1

41
Induction Example Gaussian Closed Form

• Prove 1 2 3 n n(n1) / 2
• Basis
• If n 0, then 0 0(01) / 2
• Inductive hypothesis
• Assume 1 2 3 n n(n1) / 2
• Step (show true for n1)
• 1 2 n n1 (1 2 n) (n1)
• n(n1)/2 n1 n(n1) 2(n1)/2
• (n1)(n2)/2 (n1)(n1 1) / 2

42
Induction ExampleGeometric Closed Form

• Prove a0 a1 an (an1 - 1)/(a - 1) for
  all a ? 1
• Basis show that a0 (a01 - 1)/(a - 1)
• a0 1 (a1 - 1)/(a - 1)
• Inductive hypothesis
• Assume a0 a1 an (an1 - 1)/(a - 1)
• Step (show true for n1)
• a0 a1 an1 a0 a1 an an1
• (an1 - 1)/(a - 1) an1 (an11 - 1)/(a -
  1)

43
What is Algorithm Analysis?

• How to estimate the time required for an
  algorithm
• Techniques that drastically reduce the running
  time of an algorithm
• A mathemactical framwork that more rigorously
  describes the running time of an algorithm

44
Running time for small inputs
45
Running time for moderate inputs
46
Important Question

• Is it always important to be on the most
  preferred curve?
• How much better is one curve than another?
• How do we decide which curve a particular
  algorithm lies on?
• How do we design algorithms that avoid being on
  the bad curves?

47
Algorithm Analysis(1/5)

• Measures the efficiency of an algorithm or its
  implementation as a program as the input size
  becomes very large
• We evaluate a new algorithm by comparing its
  performance with that of previous approaches
• Comparisons are asymtotic analyze of classes of
  algorithms
• We usually analyze the time required for an
  algorithm and the space required for a data
  structure

48
Algorithm Analysis (2/5)

• Many criteria affect the running time of an
  algorithm, including
• speed of CPU, bus and peripheral hardware
• design think time, programming time and debugging
  time
• language used and coding efficiency of the
  programmer
• quality of input (good, bad or average)

49
Algorithm Analysis (3/5)

• Programs derived from two algorithms for solving
  the same problem should both be
• Machine independent
• Language independent
• Environment independent (load on the system,...)
• Amenable to mathematical study
• Realistic

50
Algorithm Analysis (4/5)

• In lieu of some standard benchmark conditions
  under which two programs can be run, we estimate
  the algorithm's performance based on the number
  of key and basic operations it requires to
  process an input of a given size
• For a given input size n we express the time T to
  run the algorithm as a function T(n)
• Concept of growth rate allows us to compare
  running time of two algorithms without writing
  two programs and running them on the same computer

51
Algorithm Analysis (5/5)

• Formally, let T(A,L,M) be total run time for
  algorithm A if it were implemented with language
  L on machine M. Then the complexity class of
  algorithm A is O(T(A,L1,M1) U O(T(A,L2,M2)) U
  O(T(A,L3,M3)) U ...
• Call the complexity class V then the complexity
  of A is said to be f if V O(f)
• The class of algorithms to which A belongs is
  said to be of at most linear/quadratic/ etc.
  growth in best case if the function TA best(n) is
  such (the same also for average and worst case).

52
Asymptotic Performance

• How does the algorithm behave as the problem size
  gets very large?
• Running time
• Memory/storage requirements
• Bandwidth/power requirements/logic gates/etc.

53
Asymptotic Notation

• By now you should have an intuitive feel for
  asymptotic (big-O) notation
• What does O(n) running time mean? O(n2)?O(n lg
  n)?
• How does asymptotic running time relate to
  asymptotic memory usage?
• Our first task is to define this notation more
  formally and completely

54
Analysis of Algorithms

• Analysis is performed with respect to a
  computational model
• We will usually use a generic uniprocessor
  random-access machine (RAM)
• All memory equally expensive to access
• No concurrent operations
• All reasonable instructions take unit time
• Except, of course, function calls
• Constant word size
• Unless we are explicitly manipulating bits

55
Input Size

• Time and space complexity
• This is generally a function of the input size
• E.g., sorting, multiplication
• How we characterize input size depends
• Sorting number of input items
• Multiplication total number of bits
• Graph algorithms number of nodes edges
• Etc

56
Running Time

• Number of primitive steps that are executed
• Except for time of executing a function call most
  statements roughly require the same amount of
  time
• y m x b
• c 5 / 9 (t - 32 )
• z f(x) g(y)
• We can be more exact if need be

57
Analysis

• Worst case
• Provides an upper bound on running time
• An absolute guarantee
• Average case
• Provides the expected running time
• Very useful, but treat with care what is
  average?
• Random (equally likely) inputs
• Real-life inputs

58
Function of Growth rate
59
Asymptotic Analysis
60
Asymptotic Notation (1/2)

• Think of n as the number of records we wish to
  sort with an algorithm that takes f(n) to run.
  How long will it take to sort n records?
• What if n is big?
• We are interested in the range of a function as n
  gets large.

61
Asymptotic Notation (2/2)

• Will f stay bounded?
• Will f grow linearly?
• Will f grow exponentially?
• Our goal is to find out just how fast f grows
  with respect to n.

62
3 major notations

• O(g(n)), Big-Oh of g of n, the Asymptotic Upper
  Bound
• Q(g(n)), Theta of g of n, the Asymptotic Tight
  Bound and
• W(g(n)), Omega of g of n, the Asymptotic Lower
  Bound.

63
Example (1/2)

• Example f(n) n2 - 5n 13.
• The constant 13 doesn't change as n grows, so it
  is not crucial. The low order term, -5n, doesn't
  have much effect on f compared to the quadratic
  term, n2.
• We will show that f(n) Q(n2) .
• Q What does it mean to say f(n) Q(g(n)) ?
• A Intuitively, it means that function f is the
  same order of magnitude as g.

64
Example (2/2)

• Q What does it mean to say f1(n) Q(1)?
• A f1(n) Q(1) means after a few n, f1 is
  bounded above below by a constant.
• Q What does it mean to say f2(n) Q(n lg n)?
• A f2(n) Q(n lg n) means that after a few n, f2
  is bounded above and below by a constant times
  nlg n. In other words, f2 is the same order of
  magnitude as nlg n.

65
Big-Oh

• The O symbol was introduced in 1927 to indicate
  relative growth of two functions based on
  asymptotic behavior of the functions now used to
  classify functions and families of functions

66
Upper Bound Notation

• We say Insertion Sorts run time is O(n2)
• Properly we should say run time is in O(n2)
• Read O as Big-O (youll also hear it as
  order)
• In general a function
• f(n) is O(g(n)) if ? positive constants c and n0
  such that f(n) ? c ? g(n) ? n ? n0
• e.g. if f(n)1000n and g(n)n2, n0 gt 1000 and c
  1 then f(n0) lt 1.g(n0) and we say that f(n)
  O(g(n))
• The O notation indicates 'bounded above by a
  constant multiple of.'

67
Example 1
for all ngt6, g(n) gt 1 f(n). Thus the
function f is in the big-O of g. that is, f(n)
in (g(n)).
68
Example 2
There exists a n0 s.t. for all ngtn0, f(n) lt 1
g(n). Thus, f(n) is in O(g(n)).
69
Example 3
There exists a n05, c3.5, s.t. for all ngtn0,
f(n) lt c h(n). Thus, f(n) is in O(h(n)).
70
Classification of Function BIG O (1/2)

• A function f(n) is said to be of at most
  logarithmic growth if f(n) O(log n)
• A function f(n) is said to be of at most
  quadratic growth if f(n) O(n2)
• A function f(n) is said to be of at most
  polynomial growth if f(n) O(nk), for some
  natural number k gt 1
• A function f(n) is said to be of at most
  exponential growth if there is a constant c, such
  that f(n) O(cn), and c gt 1

71
Classification of Function BIG O (2/2)

• A function f(n) is said to be of at most
  factorial growth if f(n) O(n!).
• A function f(n) is said to have constant running
  time if the size of the input n has no effect on
  the running time of the algorithm (e.g.,
  assignment of a value to a variable). The
  equation for this algorithm is f(n) c
• Other logarithmic classifications
• f(n) O(n log n)
• f(n) O(log log n)

72
Big O Fact

• A polynomial of degree k is O(nk)
• Proof
• Suppose f(n) bknk bk-1nk-1 b1n b0
• Let ai bi
• f(n) ? aknk ak-1nk-1 a1n a0

73
Some Rules

• Transitivity
• f(n) O(g(n)) and g(n) O(h(n)) gt f(n)
  O(h(n))
• Addition
• f(n) g(n) O(max f(n) ,g(n))
• Polynomials
• a0 a1n adnd O(nd)
• Heirachy of functions
• n log n O(n) 2n n3 O(2n)

74
Some Rules

• Base of Logs ignored
• logan O(logbn)
• Power inside logs ignored
• log(n2) O(log n)
• Base and powers in exponents not ignored
• 3n is not O(2n)
• 2
• a(n ) is not O(an)

75
Lower Bound Notation

• We say InsertionSorts run time is ?(n)
• In general a function
• f(n) is ?(g(n)) if ? positive constants c and n0
  such that 0 ? c?g(n) ? f(n) ? n ? n0
• Proof
• Suppose run time is an b
• Assume a and b are positive (what if b is
  negative?)
• an ? an b

76
Example Omega

• Example n 1/2 W( lg n) .
• Use the definition with c 1 and n0 16.
  Checks OK.
• Let n gt 16 n 1/2 (1) lg n if and only if n
  ( lg n )2 by squaring both sides.
• This is an example of polynomial vs. log.

77
Theta, the Asymptotic Tight Bound

• Theta means that f is bounded above and below by
  g BigTheta implies the "best fit".
• f(n) does not have to be linear itself in order
  to be of linear growth it just has to be between
  two linear functions,

78
Examples

• 1. 2n3 3n2 n 2n3 3n2 O(n)
• 2n3 O( n2
  n) 2n3 O( n2 )
• O(n3 ) O(n4)
• 2. 2n3 3n2 n 2n3 3n2 O(n)
• 2n3 Q(n2 n)
• 2n3 Q(n2)
  Q(n3)

79
Examples

• 0.5n2 - 5n 2 W( n2). Let c 0.25 and n0 25
• 0.5 n2 - 5n 2 0.25( n2) for all n 25
• 0.5 n2 - 5n 2 O( n2). Let c 0.5 and n0 1.
• 0.5( n2) 0.5 n2 - 5n 2 for all n 1
• 0.5 n2 - 5n 2 Q( n2) from (a) and (b) above.
• Use n0 25, c1 0.25, c2 0.5 in the
  definition.

80
Examples

• log 100/97 n O(n) . (Notation lg n log2 n)
• Try this one on your own.
• It is okay to say that 2 n2 3n - 1 2 n2
  Q(n).
• Recall the mergesort work with T(n)
  2T(n/2) Q(n).
• 6 2n n2 W(2n). Let c 1 and n0 1.

81
Practical Complexity t lt 250
82
Practical Complexity t lt 500
83
Practical Complexity t lt 1000
84
Practical Complexity t lt 5000
85
Practical Complexity
86
Things To Remember in Analysis

• Constants or low-order terms are ignore
• e.g. if f(n) 2n2 then f(n) O(n2)
• Most important resource to analyze is running
  time other factors are algorithm used and input
  to the algorithm
• Parameter N, usually referring to number of data
  items processed, affects running time most
  significantly.
• N may be degree of polynomial, size of file
  to be sorted or searched, number of nodes in a
  graph, etc.

87
Things To Remember in Analysis

• Worst case is amount of time program would take
  with worst possible input configuration
• worst case is bound for input and easier to find
  usually the metric chosen
• Average case is amount of time a program is
  expected to take using "typical" input data
• definition of "average" can affect results
• average case is much harder to compute

88
GENERAL RULES FOR ANALYSIS(1/5)

• 1. Consecutive statements
• Maximum statement is the one counted
• e.g. a fragment with single for-loop followed by
  double for- loop is O(n2).

t1t2 max(t1,t2)
89
GENERAL RULES FOR ANALYSIS(2/5)

• 2. If/Else
• if cond then
• S1
• else
• S2

Max(t1,t2)
90
GENERAL RULES FOR ANALYSIS(3/5)

• 3. For Loops
• Running time of a for-loop is at most the running
  time of the statements inside the for-loop times
  number of iterations
• for (i sum 0 i lt n
  i)
• sum ai
• for loop iterates n times, executes 2 assignment
  statements each iteration gt asymptotic
  complexity of O(n)

91
GENERAL RULES FOR ANALYSIS(4/5)

• 4. Nested For-Loops
• Analyze inside-out. Total running time is running
  time of the statement multiplied by product of
  the sizes of all the for-loops
• e.g. for (i 0 i lt n i)
• for (j 0, sum a0 j lt i j)
• sum aj
• printf("sum for subarray - through d is d\n",
  i, sum)

92
GENERAL RULES FOR ANALYSIS(5/5)
93
General Rule for Analysis

• Strategy for analysis
• analyze from inside out
• analyze function calls first
• if recursion behaves like a for-loop, analysis is
  trivial otherwise, use recurrence relation to
  solve

94
Asymptotic Analysis Example
95
Analysis of Algorithm A

• Number of assignments is 1 (n-1) (dont
  know but less than n)
• Number of comparisons is (n-1)
• Thus, the number of assigncomp is less than
  3n-1.Note that (3n-1) is in O(n).
• So we say that the worst case running time of
  Algorithm A is in O(n).

assignment
comparison
96
Analysis of Algorithm B

• This algorithm uses two temporary arrays.

Step 1 O(n). Step 2 n n/2 n/4 .
1 2n-1. Step 3 O(1). Thus, Algorithm B is
in O(n).
97
Analysis of Algorithm C

• For each element, test whether it is the minimum.
• Correctness
• Is this algorithm correct?
• Will it enter the infinite loop (within )?

98
Complexity

• Worst case occurred when the minimum is the last
  element.
• For convenient, we could consider step and
  ignore other steps.
• Number of elements need to be tested on is n.
• Each testing takes n steps of .
• Thus, the worst case running time is in O(n2).
• the best case running time is in
  O(n) .
• Asuming that the minimum is equally likely to
  appear in every location of the array,
• the average case running time is
• (1/n)n (1/n)n .... (1/n)n n 2
  which is in O(n2).

99
Worst-case Running times

• An algorithm may take different amounts of time
  on inputs of the same size.
• For example, Algorithm B,C

Worst-case analysis The performance of the
algorithm is measured by its running time on the
worst input instance.
Average-case analysis The performance of the
algorihtm is measured by the average running time
of all the possible input instances.
Best-case analysis The performance of the
algorithm is measured by its running time on the
best input instance.
100
Example

• Example 1 calculate 12333 ... n3
• unsigned int sum(n)
• unsigned int i,partial_sum
• (1) partial_sum 0 // Lines 14 1 unit
  each
• (2) for (i 1 ilt n i) // Init 1, test
  n1, incr n
• (3) partial_sum iii // 4 units per
  execution 4n
• (4) return partial_sum
• No cost to call function or return value
• Total cost 24n1n1n 6n 4 gt O(n)

101
Example 2 Analyze the code fragment

• (1) assignment statement takes constant time c1
• (5) for loop like ex.1 takes c2n Q(n) time
• line (4) takes constant time c3
• inner loop (3) executes j times --gt cost c3j
• outer loop (2) executes n times, but cost of each
  inner loop is different with each j --gt c3
  summation of j from 1 to n
• cost c1 c2n c3 (n(n1) / 2)
• O(c1c2nc3 n2) Q(n2)

• (1) sum 0
• (2) for (j1 jltn j)
• (3) for (i1 iltj i)
• (4) sum
• (5) for (k1 kltn k)
• (6) Ak k-1

102
Example 3. Compare asymptotic Analysis for
following

• In (1) the inner loop executes n times for each
  of n executions made by outer loop --gt sum1
  executes Q(n2) times
• In (2) the inner loop executes with cost
  (summation from 1 to n of j), which is about
  n2/2.
• Hence, both loops cost Q(n2), but the second
  requires about half the time of the first

(1) sum1 0 for (i1 iltn i)
for (j1 jltn j)
sum1 (2) sum2 0 for
(i1 iltn i) for (j1 jlti
j) sum2
103
Example 4. A for-loop that does not run in Q (n2)
time
sum0 for (k1 kltn k2) for (j1
jltn j) sum

• Outer loop executes log n times since k is
  multiplied by 2 on each iteration up to n
• The inner loop executes n times
• total cost --gt S i1..log n n n log n

104
MAXIMUM SUBSEQUENCE SUM PROBLEM

• Given (possibly negative) integers a1,a2,...,an,
  find the maximum value of S ak.
• Ex. for input -2, 11, -4, 13, -5, -2, answer is
  20 (a2 through a4)

105
ALGORITHM 1 Obvious O(N3)

• int MaxSubsequenceSum( const int A , int N )
• int ThisSum, MaxSum, i, j, k
• / 1/ MaxSum 0
• / 2/ for( i 0 i lt N i )
• / 3/ for( j i j lt N j )
• / 4/ ThisSum 0
• / 5/ for( k i k lt j k )
• / 6/ ThisSum A k
• / 7/ if (ThisSumgtMaxSum )
• / 8/ MaxSum ThisSum
• / 9/ return MaxSum
• / END /

106
Algorithm 1

• Line 1 is O(1)
• Loop line 2 is size n
• Loop line 3 could be small or could be size n as
  well (worst case)
• Loop line 5 is size n
• Lines 7 to 10 take O(n2)
• Total Running time is O(n3). More precisely, Q(n3)

107
Algorithm 2 Improve O(N2)

• int MaxSubsequenceSum( const int A , int N )
• int ThisSum, MaxSum, i, j, k
• / 1/ MaxSum 0
• / 2/ for( i 0 i lt N i )
• / 3/ ThisSum 0
• / 4/ for( j i j lt N j )
• / 5/ ThisSum A j
• / 6/ if (ThisSumgtMaxSum )
• / 7/ MaxSum ThisSum
• / 8/ return MaxSum
• / END /

108
Algorithm 3 Divide and Conquer (n log n)

• Step 1 Break a big problem into two small sub
• problems
• Step 2 Solve each of them efficiently.
• Step 3 Combine the sub solutions

109
Maximum subsequence sum by divide and conquer
Step 1 Divide the array into two parts left
part, right part
Max. subsequence lies completely in left, or
completely in right or spans the middle.
If it spans the middle, then it includes the max
subsequence in the left ending at the center and
the max subsequence in the right starting from
the center!
110
Example

• 4 3 5 2 -1 2 6 -2
• Max subsequence sum for first half 6 (4,
  -3, 5)
• second
  half 8 (2, 6)
• Max subsequence sum for first half ending at the
  last
• element is 4 (4, -3, 5, -2)
• Max subsequence sum for sum second half starting
  at the
• first element is 7 (-1, 2, 6)
• Max subsequence sum spanning the middle is 11?
• Max subsequence spans the middle 4, -3, 5, -2,
  -1, 2, 6

111
Maxsubsum(A, left, right) if left
right, maxsum max(Aleft, 0) Center ?
(left right)/2? maxleftsum Maxsubsum(A
,left, center) maxrightsum Maxsubsum(A
,center1,right) maxleftbordersum 0
leftbordersum 0 for (icenter igtleft
i--) leftbordersumAi
Maxleftbordersummax(maxleftbordersum,
leftbordersum) Find maxrightbordersum..
return(max(maxleftsum, maxrightsum,
maxrightbordersum maxleftbordersum)
112
Complexity Analysis
T(1)1 T(n) 2T(n/2) cn
2(2T(n/4)cn/2)cn22T(n/22)2cn 22(2T(n/23
)cn/22)2cn 23T(n/23)3cn
(2k)T(n/2k) kcn (let n2k, then klog
n) T(n) nT(1)kcn n1cnlog n O(n log n)
113
Algorithm 4 Linear O(N)

• int MaxSubsequenceSum( const int A , int N )
• int ThisSum, MaxSum, j
• / 1/ ThisSum MaxSum 0
• / 2/ for ( j 0 j lt N j )
• / 3/ ThisSum A j
• / 4/ if (ThisSum gt MaxSum )
• / 5/ MaxSum ThisSum
• / 6/ else if ( ThisSum lt 0)
• / 7/ ThisSum 0
• / 8/ return MaxSum
• / END /

114
Insertion Sort Analysis (1/4)

• // A is an array of n elements with an order (lt).
• // n length(A).
• // Pseudocode uses liberal amounts of English.
• // Instead of begin - end or combinations use
  indentation for block structure.
• // Omission of error handling and other such
  things needed in real programs.
• // To do each step is machine dependent, constant
  time per step (i.e. c1, c2,..., c10).

115
Insertion Sort Analysis (2/4)

• line pseudocode
  cost
  times
• 1 // At start, the singleton sequence
  A1 is trivially sorted c1 0
• 2 for j 2 to n

  c2 n
• 3 // Insert Aj into the sorted
  sequence A1..(j-1) c3 0
• 4 do key Aj
  c4
  n - 1
• 5 i j - 1

  c5 n - 1
• 6 // let tj be the
  number of times the following
• //while-loop is
  tested for the value j c6 0
• n
• 7 while (i gt 0 and Aj gt key)
  c7 S tj
• j 2
• n
• 8 do Ai1 Ai c8
  S (tj-1)
• j 2
• n
• 9 i i - 1 c9
  S (tj-1)
• j 2
• 10 Ai 1 key
  c10 n - 1

116
Insertion Sort Analysis (3/4)

• // c1 c3 c6 0 since comments are ignored and
  take no time.
• // c2 time to increment and compare the
  for-loop variable.
• // c4 c8 c10 time to make an array element
  assignment.
• // c5 c9 time to decrement an integer
• // c7 time to evaluate the while-loop Boolean
  condition.

117
Insertion Sort Analysis (4/4)

• Example 1 2 3 4 5
  6
• A 50 20 40 60 10
  30 Insert, j 2, key 20
• 20 50 40 60 10
  30 Insert, j 3, key 40
• 20 40 50 60 10
  30 Insert, j 4, key 60
• 20 40 50 60 10
  30 Insert, j 5, key 10
• 10 20 40 50 60
  30 Insert, j 6, key 30
• 10 20 30 40 50
  60 done

118
Analysis of the Algorithm

• The running time depends on
• the number of primitive operations or steps
  executed
• the input size (in sorting, the number of
  elements) and
• the input itself (e.g. partially sorted).
• We generally want an upper bound on the running
  time.
• Multiplying the cost of each step times the
  number of times it is run one gets

119
Best Case Analysis

• BEST CASE here is when array is already sorted.
• For each j 2, 3,..., n we find that Ai Aj
  - 1 lt key Aj since the array is presorted.
  This means that the while loop is tested (n - 1
  times) and never entered. tj 1 for each j.

120
Best Case Analysis

• The best case run time is
• Tbest(n) c2n c4(n - 1) c5(n - 1) c7(n
  - 1) c10(n - 1)
• (c2 c4 c5 c7 c10) n -
  (c4 c5 c7 c10)
• An B since the ci are machine
  dependent constants.
• a linear function of n
• Generally the best case scenario is not important
  and is seldom of interest. It is good only for
  showing a bad lower bound.

121
Worst Case Analysis (1/2)

• WORST CASE is when the array is already reverse
  sorted in decreasing order.
• For each j 2, 3, ..., n we find that Ai key
  since the array is decreasing.
• This means that the while loop is tested for
  every value of j. That is, tj j.

122
Worst Case Analysis (2/2)

• The worst case run time is Tworst(n) max time
  on any input of size n
• Tworst(n) c2n c4(n - 1) c5(n - 1)
  c7(n(n 1)/2) - 1
• c8(n(n - 1)/2) c9(n(n -
  1)/2) c10(n - 1)
• (c7 c8 c9) n2 /2 (c2
  c4 c5 c7/2 - c8/2 - c9/2 c10) n
  - (c4 c5 c7 c10)
• An2 Bn C a quadratic
  function of n
• This scenario(worst case) is what is usually
  wanted in
• analyzing an algorithm.

123
Average Case Analysis (1/2)

• AVERAGE CASE assumes a random distribution of
  data. On the average, 1/2 of all the inner loops
  are performed since 1/2 of the elements Ai will
  be greater. This means that tj j/2 and the
  above sums will yield
• Taverage(n) c2n c4(n - 1) c5(n - 1)
  c7(n(n 1)/2) - 1/2
• c8(n(n - 1)/4) c9(n(n -
  1)/4) c10(n - 1)
• (c7 c8 c9) n2 /4 (c2
  c4 c5 c7/4 - c8/4 - c9/4 c10)
  n - (c4 c5 c7/2 c10)
• An2 Bn C
• quadratic function in n

124
Average Case Analysis (2/2)

• This scenario (average case) is sometimes wanted
  in analyzing an algorithm although it is often
  difficult to determine what "average" input is.
• Running time functions are often too complex to
  derive exactly.
• In this course we use asymptotic analysis.

125
Example Q(n3) vs Q(n2)

• As n gets large Q(n2) is better (faster).

126
Average Case

• Average case assumes all permutations are equally
  likely. The inner loop is Q(j/2).
• Often the average case is not much better than
  the worst case.
• Is this a fast sorting algorithm?
• YES, for small n.
• NO, for large n.

127
Practical Complexities

• Time complexity function can be used to compare
  two programs P and Q that perform the same task.
• e.g. assume program P is Q(n) and program Q is
  Q(n2)
• Assertion program P is faster than program Q for
  sufficiently large n
• if program P actually runs in 106 n milliseconds,
  and program Q runs in n2 milliseconds, and if we
  always have n lt 106, then, other factors
  being equal, we should use program Q.

128
Function growth for various values of n
