Distributed Databases

1
Distributed Databases

• CS 95 Advanced Database Systems
• Handout 4

2
Definitions

• "... a collection of data which belong logically
  to the same system but are spread over the sites
  of a computer network." (Ceri, 1984)
• "A distributed database is a collection of
  logically related data distributed across several
  machines interconnected by a computer network. An
  application program operating on a distributed
  database may access data stored at more than one
  machine." (Gardarin Valduriez)
• "A set of cooperating databases, each resident at
  a different site, that the user views and
  manipulates as a centralized database." (Gardarin
  Valduriez)
• ".. a kind of virtual object, ... physically
  stored in a number of distinct real databases at
  a number of distinct sites." (Date)

3
Concept

• Can have many sites, each with their own database
  management system (DBMS).
• Local data stored at each site.
• Sites connected by communications network.
• To a user (application program) all sites
  together appear as one big database.
• Needs simple structures --gt relational databases
• e.g., Ingres/Star

4
General structure of a DDBMS
5
Another diagram of a DDBMS

• DC Data Communications component
• DBMS local DBMS
• DDBMS Distributed DBMS component
• GDD Global data Dictionary

Note that although site 3 has access to the DDB,
the local DB at site 3 is not part of the DDD
6
Fragmentation

• Horizontal partitioning
• Rows of the one table are stored across different
  sites.
• Vertical partitioning
• Each table stored at a single site but different
  tables are stored at different sites or columns
  of a table are stored across different sites
• Basic principle is that data is stored at the
  site where it is mostly accessed
• network traffic is reduced
• improves performance

7
Replication

• Data may be stored at more than one site. (i.e.,
  a copy of the data)
• Whole relations may be replicated, or just
  fragments of relations
• Faster retrieval as the network communications
  link is not used as often because data logically
  belonging to another site may have a local copy.
• Provides backup
• Problems with updating records.

8
12 Objectives for DDBMS (Date)

• 1. Local autonomy
• 'Local data is locally owned and managed ...'
• Each site must be able to control and process its
  local data independent of any other site.
• Need to store the Global Data Dictionary at each
  site
• Some aspects of data security and data integrity
  are managed at the global level.

9
12 Objectives for DDBMS (Date)

• 2. No reliance on a central site
• Following from (1) 'all sites must be treated as
  equals there must not be any reliance on a
  central "master" site for some central service
  ...'
• Advantages
• system is less vulnerable
• less chance of a bottleneck

10
12 Objectives for DDBMS (Date)

• 3. Continuous operation
• DDBMS are not an all or nothing proposition, in
  that if one site fails the other sites can still
  operate, even if at a reduced level.
• If one site is down then that sites data may
  still be available if it is replicated.
• Hence, disruptions are minimised

11
12 Objectives for DDBMS (Date)

• 4. Location independence (transparency)
• 'Users ... should be able to behave ... as if the
  data was all stored at their own local site.'
• A primary objective
• User is not aware if data is being retrieved
  locally or from another site.
• Even if data is moved from one site to another,
  users of the data are not affected.
• Easy for retrieval, harder for updates.

12
12 Objectives for DDBMS (Date)

• 5. Fragmentation independence
• '... users should be able to behave ... as if the
  data were ... not fragmented at all.'
• location of data is kept (somehow) in the system
  catalog
• DDBMS uses catalog to retrieve data from the
  relevant site
• A query may select data from a table that is
  horizontally fragmented, and the query may not be
  restricted to a single site
• The query engine would have to do something like
  split the query into separate subqueries, one for
  each involved site
• Send each subquery to the relevant site
• UNION the results of the subqueries into a final
  answer
• All this is hidden from the user that submits the
  query
• Advantage
• '... simplifies user programs and terminal
  activities.'

13
12 Objectives for DDBMS (Date)

• 6. Replication independence (transparency)
• Similar to fragmentation independence.
• Some data may be stored at multiple sites.
• DDBMS determines closest for retrieval.
• DDBMS alters all sites when updating.
• involves some interesting algorithms
• Have replication because
• cut communication costs
• dupl. of essential data allows processing to
  continue when communication cut.
• enables quick easy recover after failure.
• Replication is used to improve performance and
  data availability.

14
12 Objectives for DDBMS (Date)

• 7. Distributed query processing
• 'It is important that optimization in a
  distributed system be performed from a global
  perspective.'
• Communication time is now the slowest part of
  execution of a query, so that has to be taken
  into account when formulating a query plan

15
12 Objectives for DDBMS (Date)

• 8. Distributed transaction management
• '... recovery control and concurrency control
  ...' require 'extended treatment in the
  distributed environment.'
• eg. concurrency over multiple sites requires an
  advanced form of the two-phase commit protocol
• As transaction progresses nodes involved lock
  data that is accessed or to be updated
• At the end of the transaction the coordinating
  node (site) sends get ready requests to all other
  nodes involved in the transaction Each node
  responds whether ready or not
• If all replies are OK then coordinating node
  issues actual commit, otherwise rollback Each
  node performs update and responds to coordinating
  node when update is complete ONLY AFTER ALL
  nodes respond does the coordinating node send a
  message to release all locks.

16
12 Objectives for DDBMS (Date)

• 9. Hardware independence
• 10. Operating system independence
• In theory, it does not matter if different nodes
  in the DDBMS run on different OSs.
• eg. a Unix computer, a PC and a Mac should all be
  able to participate in the same distributed
  system.
• The standard TCP/IP communications protocol has
  facilitated this objective.
• 11. Network independence
• 12. DBMS independence
• Heterogeneous databases.

17
Why distributed databases?

• Organizational and economic structure may be
  distributed. A DDB better models this.
• One can interconnect existing DBs.
• Incremental growth is supported.
• Reduction in communications overhead - emphasis
  on local processing.
• Data is stored closer to where it is accessed, so
  access times are reduced.
• Parallel processing - improved performance.

18
Why distributed databases?

• Reliability - graceful degradation
• Loss of one site does not bring the entire system
  down
• Reduction in data processing bureaucracy.
• Gain in local autonomy
• Drops in computer costs allow more computing
  power to be purchased
• Capacity and growth potential of the system is
  increased

19
Problems with DDB

• Security
• The data is now spread over many sites, securing
  all sites is more difficult than securing one
  site.
• Authority to access data items must be
  duplicated.

20
Problems with DDB

• Catalog Management (Data Dictionary)
• May be stored (i) Centrally, (ii) Fully
  replicated on every site (iii) Fragmented over
  each site. ie. each site keeps and maintains the
  catalog for objects stored at that site. (iv)
  Combination of (i) and (iii).
• New data objects require updating each DD
  concerned.
• Note sites not aware of the new data object will
  not be able to access it.

21
Problems with DDB

• Query Processing
• Retrieving data that is fragmented over multiple
  sites requires extra consideration
• Slow component now is transferring data between
  sites
• Need to optimise a query to reduce this network
  traffic

22
Problems with DDB

• Update Propagation for Replicated Data
• One copy of any replicated data is designated the
  Primary Copy
• Primary Copy Update Strategy
• An update operation is deemed complete when the
  primary copy is updated
• the DDBMS is then responsible for propagating the
  update to the other (secondary) copies at some
  subsequent time.

23
Problems with DDB

• Recovery Control
• Typically based on the Two-Phase Commit protocol
• The coordinating resource instructs all resources
  to "get ready". The resources reply "OK" or "Not
  OK".
• If all resources reply "OK" then the commit
  directive is given to each resource, otherwise
  the rollback directive is given. Resource
  indicates success after commit/rollback

24
Problems with DDB

• Recovery Control (Example)
• ie. messages go something likePhase 1 1.
  Coord-gtResource("Get Ready") 2. Resource-gtCoord
  ("Okay")Phase 2 3. Coord-gtResource("Do It") 4.
  Resource-gtCoord ("Done It")
• More messages on the network gt more overhead
• Coordinating resource is usually the site where
  the transaction originates
• Coordinating and resource sites must write
  details of every decision into its log file in
  case a rollback or restart is required.

25
Problems with DDB

• Concurrency/Global Deadlock
• Accessing data from remote sites means extra lock
  requests/grants
• even more network overhead
• Possibility of global deadlock that cannot be
  detected at a single site.
• Administration
• With many sites may have many DBA.

26
DDBMS Fundamental Principle

• To the user, a distributed system should look
  exactly like a nondistributed system.
