Software Packaging with DAR

1
Software Packaging with DAR

• Natalia Ratnikova, Anzar Afaq, Greg Graham
• Fermilab
• Tony Wildish, Veronique Lefebure
• CERN

2
Introduction ? Motivation

• Compact Muon Solenoid CMS HEP experiment will run
  on the LHC accelerator at CERN.
• CMS is using GRID technologies to utilize
  available computing resources for the worldwide
  distributed Monte Carlo event production.
• To make this possible CMS software applications
  must be brought to the production sites.

3
Introduction ? Scope

• CMS software includes a wide range of
  inter-related projects and external tools managed
  by the Software Configuration Release and
  Management tool SCRAM.
• Complete installation of the CMS software and
  environment on the remote sites is uneasy task,
  and actually it is not necessarily required in
  order to run ready applications.

4
Introduction ? Goal

• The USCMS software and computing project goal was
  to move CMS MC production in the US completely
  onto the GRID computing resources.
• We wanted to have an automated way to create
  self-consistent distributions of the
  applications, based on the software released at
  CERN.
• The Distribution After Release DAR tool was
  developed at Fermilab for quick-an-easy
  deployment of the CMS software applications,
  which can run on the systems that do not have
  pre-existing CMS environment.

5
DAR concept

• DAR automatically creates and installs software
  applications based on the runtime environment .
• Application is a complete, self-contained
  software program, including all required shared
  libraries and other files, that can be executed
  in a particular environment to accomplish a
  particular computing task.
• Runtime environment is a set of UNIX shell
  environment variables used by the program during
  the runtime.

6
Concept ? Choices, Decisions

• There is a class of tools and utilities, such as
  operating system kernel, loader, that though
  needed for the applications, are usually present
  on the remote computing node.
• Its hard to define a clear border between the
  application and the operating system, so one
  sometimes has to decide what to include into the
  distribution, and what must be pre-installed by
  the local system administrator
• In CMS software these issues are controlled
  through the projects configuration, which
  specifies the required tools and corresponding
  environment

7
Concept ? Conditionals

• Application software must be relocatable.
• This is most important and natural requirement.
  Most of real quality software products are
  relocatable, and the location is usually
  controlled through the shell environment
  variable.
• No hard-coded absolute paths in the program or in
  the shared libraries (except those referred to
  the system area).
• All executables are found in the PATH.
• DAR distributions rely on the system
  compatibility

8
DAR Implementation

• DAR is implemented in scripting languages, no
  compilation is required.
• Core of DAR code is written in PERL.
• Interfaces and extensions are written in Python.
• DAR code can be simply download from the CVS
  repository or from the web, and can be used
  immediately. In the CMS environment
• dar -c lttop release directorygt lttemporary
  directorygt
• On the remote site
• Dar -i ltdistribution darballgt ltinstallation
  directorygt

9
Implementation ?Shared Libraries

• DAR will walk through the directories specified
  in the LD_LIBRARY_PATH environment variable and
  package all found libraries into the
  distribution. It will insure that upon
  installation the runtime environment scripts will
  set proper LD_LIBRARY_PATH in correct order.
• DAR does not rely on the output of the
• ldd ltexecutablegt
• command, as this is considered unsafe in case
  of dynamically loaded libraries.

10
Implementation ? Executables

• By default DAR will walk through the directories
  in the PATH environment variable (only the
  portion added for this particular application)
  and include the contents of directories into
  DARball.
• This behavior can be overwritten by setting the
  DAR_runtime_PATH environment variable, in which
  case the associated files and directories will be
  included into the distribution, and will be added
  to the PATH in the DAR runtime environment
  scripts.

11
Implementation ? Other Variables

• DAR distinguishes between three types of the
  runtime environment variables
• Simple values (flags)
• Variables associated with some path to existing
  file or directory in the local file system
• Variables associated with several paths in the
  local file system (PATH-like variables, were
  entries are separated by the colon delimiter)
• All physical files and directories found in
  specified paths are included preserving the
  underlying directory structure.

12
General Practices, Tests

• All sophisticated work is done by DAR while
  creating the distribution
• The installation procedure is extremely simple.
• Friendly user interface simple commands,
  built-in help, backward compatibility.

13
Tests

• Run same application in the native environment
• Install DARball and run on the same node
• Install and run application on remote host
  without pre-installed CMS environment
• Same output in all three cases means success.
• Second type of tests is optional, and can be used
• to identify any discrepancies in the operating
• system configuration.

14
Using DAR in Production

• DAR created distributions have been used as a
  mandatory way to install software for the
  official CMS Monte Carlo production.
• Using the same set of applications and consistent
  software distribution mechanisms insured stable
  performance and trustworthy results.
• The RefDB2DAR interface has been developed to
  formalize the requests for applications and
• provide bookkeeping of the available
  distributions.

15
CMS production over GRID (fall 2002)
The CMS Integration GRID Testbed produced 1.2
million CMS Monte Carlo events from generation
with PYTHIA physics generator through simulation
with GEANT and digitization with Objectivity
based applications.All results shown here were
run on Red Hat 6 systems, though some GEANT-only
production was also run on newer Red Hat 7
systems.
16
Next steps ? Bookkeepiing

• The RefDB2DAR interface allows to download
  request file from the RefDB.
• Refdbdar utility is then used to
• parse and validate the RefDB request file
• call Packager CMSIM_packager, CMKIN_packager, or
  DAR_packager for scram managed projects,
• packager builds executables as requested and
  creates distribution

17
Next steps ? Optimizations

• runtime environment contains some superfluous
  directories and files. However for detection of
  files, that could be safely excluded, expert's
  knowledge of the software application is
  required.
• a number of new expert options allow to filter
  the contents, but it may take several iterations
  to figure out what can be removed, and whether it
  is efficient and safe.

18
Next steps ? Optimizations

• Space optimizations
• Avoid duplications (all duplicated files are
  replaced by symbolic links)
• Introduced experts options
• Runtime environment contains some superfluous
  directories and files.
• However for detection of files, that could be
  safely excluded, expert's knowledge of the
  software application is required
• Time optimizations
• Automating tests

19
Distribution process

1. Production Coordinator fills web form to create
   DARball request. Generated request is stored in
   the RefDB, notification is sent by e-mail.
2. DARball is created then created using refdbdar
   and request file, based on software release
   installation at CERN.
3. Application is installed and tested in DAR
   runtime environment.

20
Distribution process

1. DARball is put into SRB for distribution and is
   ready for the production assignments.
2. Production sites get the assignments with the
   indication of the DARball (by name). DARball is
   then downloaded from the SRB and installed, using
   DAR, on the worker nodes.
3. McRunJob tool creates job based on application
   and submitts it to the production GRID.

21
Using DAR in MOP

• MOP is a system for distributing CMS Monte-Carlo
  production jobs over the GRID.
• MOP has capability of running any type of scripts
  (jobs) at remote GRID sites, called Worker Sites.
• MOP run jobs as DAGs (Decyclic Acrylic Graph)
  which could be combined together to create
  complex workflows.

22
Using DAR in MOP

• In general every DAG contain 04 stages.
• Stage-in Bring in the required input files (from
  several sources) to worker site.
• Run Execute the job itself, producing results,
  logs, data.
• Stage-out Send out produced results/data/logs.
• Clean-up clean the left over files/directories
  at worker site.

23
Using DAR with MOP

• DAR installation at a worker site is achieved by
• creating a special MOP job
• that first pull DAR tool and Application DAR
  distribution in stage-in,
• runs installation by invoking DAR in run-stage,
• Bring back the results of installation to
  submission site in stage-out
• and then performs a clean up operations at worker
  site.

24
Summary

• DAR-based distribution scheme is successfully
  used in the CMS event production for an extended
  period of time.
• It allows to keep the pace with the
  software developments and deliver software
  applications to the productions sites with ease
  and in a timely fashion.
• Being re-packaged into RPM files, applications
  can be re-used within different distribution
  approaches (e.g. LCFG).

25
Acknowledgements

• Main credit in this work should be addressed to
  the core CMS software developers, architects and
  release managers for the constant care about
  software quality.
• We would like to thank CMS and USCMS software and
  computing managers for their attention paid to
  this project, CMS Production Team for providing
  excellent working environment, and all CMS
  colleagues from many counties and institutions
  for their useful feedback.
• My special thanks to Dr. Yujun Wu for presenting
  this talk to You, and numerous fruitful
  discussions.

THANK YOU
