Periodic Trends

1
Periodic Trends

• Chem 441 Inorganic Chemistry
• Dr. Jeff Seyler

2
Electron Configuration

• based on H-orbitals (Schrödinger wave function)
• contraction of orbitals as Z increases
• PT rows relate to n QN (energy level)
• (n-1)d and (n-2)f
• PT l-blocks, columns
• number of columns depend on max number of
  electrons
• exceptions to Aufbau principle
• Cr Ar4s13d5, DEn and Hunds rule
• valence electrons, control reactivity
• highest n and partially filled (n-1)d electrons

3
Electron Shielding

• Core electrons shield valence electrons
• Valence electrons exchanged/shared in reactions
• s-orbital electrons shield more effectively
• Due to penetration (see radial distribution
  plots)
• Zeff (effective nuclear charge)
• Slaters rules offer quick approximation
• Zeff increases across a PT row
• Additional protons, same level (n QN)

4
Ionization Energy

• energy required to remove an electron
• M (g) energy ? M(g) e-
• decreases as n QN increases
• easier to remove e- as distance from nucleus
  increases
• increases from left to right across a row
• Zeff increase outweighs shielding for given l
• deviations from trends
• stability for half-full and full sublevels

5
Electron Affinity

• energy associated with gain of electron
• M (g) e- ? M-1 (g), (- DH), historical
• M-1 (g) ? M (g) e- (DH), Miessler text
• endotherms and exotherms
• most elements have DH
• generally, nonmetals favor gain of electron
• trends in EA
• similar to IE, offset one atomic number
• deviations from trends
• stability for half-full and full sublevels

6
Atomic Radii

• Determined from crystal data
• atomic, ionic, and covalent radii
• Depends on n QN
• size increases down column
• Depends on Zeff
• size decreases left to right
• Deviations from trends
• Lanthanide contraction

7
Ionic Radii

• cations
• radius decrease with increasing charge
• anions
• radius increase with increasing - charge
• values in pm

8
Electronegativity

• power of an electron to attract electrons to
  itself in a covalent bond
• Pauling (1930s) used BDE (eV units)
• Mulliken used avg of IE and EA
• Allen used energy of valence shell electrons
• Jaffe determined orbital electronegativities
• trends
• increase left to right
• decrease down a column

9
figures
The following slides contain figures linked
within the presentation.
10
Z and Radial Distribution
rmax radial distribution decreases as Z increases
for a given energy level, n (size decreases from
left to right across a row)
H 3p
back
11
Periodic Table l-blocks
back
12
Aufbau exceptions
V - 4s23d3 to Cr - 4s13d5 Ni - 4s23d8 to Cu -
4s13d10
3d
4s
Fe to Zn, the 4s electrons are highest energy (3d
drops lower than 4s with increasing charge)
back
13
Orbital Penetration
back
14
Ionization Energies
15
IE1 Trends
16
IE Trends
back
17
Electron Affinities
- DH
18
Electron Affinities cont.
back
19
Transition Metal radii
Lanthanide contraction 5d row same size as 4d
back
20
Pauling Electronegativities
2.1 (H)
4.0
0.7
back
